Toyota SEQUOIA 2007 Manual de usuario

MN 00452-PRG07-SEQ

Printed in USA 07/06

2007

Pocket Reference Guide

Customer Experience Center

1-800-331-4331

07 Sequoia PRG Cover 9/25/06 10:59 AM Page 1

Spare tire & tools

Tool location (under right side second row seat)

Removing the spare tire

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Assemble the jack handle.

Insert the jack handle end through the opening in

the bumper, and into the lowering screw.

Turn the jack handle counterclockwise.

Refer to the Owner’s Manual for tire changing and

jack positioning procedures.

!Aword about safe vehicle operations

This Pocket Reference Guide is a summary of

basic vehicle operations. It contains brief

descriptions of fundamental operations so you

can locate and use the vehicle’s main

equipment quickly and easily.

The Pocket Reference Guide is not intended

as a substitute for the Owner’s Manual

located in the vehicle’s glove box. We

strongly encourage you to review the Owner’s

Manual and supplementary manuals so you

will have a better understanding of the

vehicle’s capabilities and limitations.

Your dealership and the entire staff of Toyota

Motor Sales, U.S.A., Inc. wish you many years

of satisfied driving in your new Sequoia.

This Pocket Reference Guide is not a full

description of Sequoia operations. Every

Sequoia owner should review the Owner’s

Manual that accompanies this vehicle.

Pay special attention to the boxed

“ ” information highlighted in

this reference guide and throughout the

Owner’s Manual.Each box contains safe

operating instructions to help you avoid

injury or equipment malfunction.

All information in this Pocket Reference

Guide is current at the time of printing.

Toyota reserves the right to make changes

at any time without notice.

This utility vehicle has a significantly higher

rollover rate than other types of vehicles. Refer to

the Owner’s Manual for important rollover

information.

2007

Sequoia

Tool bag

Jack

Seat belt comfort guide

Pull out

Right front seat

Pinch edges

Rear seat outside position guides provide added

comfort for children who have outgrown child

restraints.

07 Sequoia PRG Cover 9/25/06 10:59 AM Page 2

1Programmable by customer. Refer to the Owner’s

Manual for instructions and more information.

2Visit your Toyota dealer for information on

customizing this feature.

3HomeLink®is a registered trademark of Johnson Controls, Inc.

OVERVIEW

Engine maintenance 8

Fuel tank door release and cap 7

Hood release 7

Indicator symbols 4-5

Instrument cluster 4

Instrument panel 2-3

Keyless entry26

FEATURES/OPERATIONS

Air Conditioning/Heating 15

Audio system 16-17

Auto lock functions1, 2 9

Automatic Transmission 9

Clock 22

Cruise control 21

Cup holders 19

Door locks 22

Four-wheel drive 10

Light control-Instrument panel 21

Lights2&turn signals 13

Mirrors-Power side view 12

Moonroof220

Multi-information display (HomeLink®)314

Parking brake 10

Power outlets 20

Rear seat entertainment system 18

Seat adjustments-Front 11

Seat adjustments-Rear 11

Seat heaters 14

Seats-Head restraints 12

Tilt steering wheel 22

Windows218

Window-Rear219

Windshield wiper & washer 12

SAFETY AND EMERGENCY FEATURES

Doors-Child safety locks 23

Seat belt comfort guide 25

Seat belts 23

Seat belts-Shoulder belt anchor 24

Spare tire & tools 25

Tire Pressure Warning System reset 24

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

INDEX

Item Page no.

07 Sequoia PRG Inside 9/25/06 11:01 AM Page 1

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

OVERVIEW

Power back window switch

Driving position memory switches1

Headlight, turn signal and front fog light1controls

Ignition switch

Wiper and washer controls

Automatic transmission shift lever

Emergency flasher switch

Automatic Transmission shift position “L” switch

(“SHIFT L” switch)

Audio system or navigation system1, 2

Front/Rear Air Conditioning controls

Front passenger occupant classification indicator/

Front passenger seat belt reminder light

Back window and outside rearview mirror

defogger1switch

Clock

Cup holder

Glass breakage sensor1

115V AC Power outlet ON/OFF switch1

Height control switch1

Height control mode select switch1

Ashtray

12 DC Power outlet cigarette lighter

Front drive control switches1

“TRAC OFF” (Traction Control “OFF”)1

Center differential lock switch1

Cruise control

Tire Pressure Warning System reset switch

(below steering column)

Steering wheel audio control1

Tilt steering lock release

“RSCA OFF” (Roll Sensing of Curtain shield

Airbags “OFF”) switch1

Instrument panel light control

1If equipped

2For details, refer to the “Navigation System

Owner’s Manual.”

Instrument panel

Two-wheel drive models

Four-wheel drive models

07 Sequoia PRG Inside 9/25/06 11:01 AM Page 2

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

OVERVIEW

Headlight high beam indicator

Automatic Transmission indicator

Instrument cluster

Center differential lock indicator2

Driver seat belt reminder1

Front passenger seat belt reminder1

Charging system warning1

Low fuel level warning1

Brake system warning1

Anti-lock Brake System warning1

Malfunction/Check Engine indicator1

When the Anti-lock Brake System (ABS) function is in

action, you may feel the brake pedal pulsating and

hear a noise. In this situation, to let the Anti-lock

Brake System work for you, just hold the brake pedal

down more firmly. Do not pump the brake as this will

result in reduced braking performance.

Indicator symbols

Overdrive “OFF” indicator

High speed four-wheel drive indicator2

Low speed four-wheel drive indicator2

Slip indicator

Vehicle Stability Control “OFF” indicator

Height control indicator

Manual control mode indicator3

Cruise control indicator4

Roll Sensing of Curtain shield Airbags “OFF”

indicator

Headlight indicator

Open door warning1

Airbag SRS warning1

Automatic Transmission fluid temperature

warning1

Low Tire Pressure Warning1

Engine immobilizer/Theft deterrent system

indicator

Front passenger occupant classification indicator

•Vehicle Stability Control warning1

•Traction Control warning1

•Active Traction Control warning1

Turn signal indicator

Traction Control “OFF” indicator

1For details, refer to “Service reminder indicators and warning

buzzers,” Section 1-6, 2007 Owner’s Manual.

2If this light flashes, refer to “Four-wheel drive system,” Section

1-7, 2007 Owner’s Manual.

3If this light flashes, refer to “Rear height control air

suspension,” Section 1-7, 2007 Owner’s Manual.

4If this light flashes, refer to “Cruise control,” Section 1-7, 2007

Owner’s Manual.

Service indicator and reminder

Engine oil pressure

Tachometer

Speedometer

Fuel gauge

Engine coolant temperature

Trip meter reset

Odometer and two trip meters

Height control indicator

Voltmeter

Limited model option

Low windshield washer fluid level warning1

Engine oil replacement reminder1

07 Sequoia PRG Inside 9/25/06 11:01 AM Page 4

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

OVERVIEW

NOTE: After unlocking, if a door is not opened within

30 seconds, all doors will relock for safety.

Alarm operation

Keyless entry (if equipped)

Locking operation

Unlocking operation

Back window operation

Beep sound can be switched “ON” or “OFF.” Refer to

“Wireless remote control” in the Owner’s Manual for

more details.

Push

Push ONCE: Driver door

TWICE: All doors

Push and hold

Fuel tank door release and cap

Pull up

Turn Store

Hood release

Pull

Pull up latch

and raise hood

Driver seat

NOTE: Tighten until one click is heard. If the cap is

not tightened enough, Check Engine “ ” indicator

may illuminate.

07 Sequoia PRG Inside 9/25/06 11:02 AM Page 6

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

FEATURES/OPERATIONS

Automatic Transmission

Park1

Reverse

Neutral

Drive

Third gear

Second gear

Overdrive switch

To turn “ON” or “OFF” Depress the overdrive

switch to choose either four-speed (“OFF”) or five-

speed (“ON”) operation. During normal driving

conditions, always drive with overdrive “ON.” This

allows the transmission to shift automatically into

five-speed operation at higher speeds, improving

fuel economy. If the indicator on the instrument

cluster is illuminated, overdrive is “OFF.”

“SHIFT L”

Auto lock functions

Automatic door locks can be programmed to operate

in 4 different modes, or turned OFF.

-Doors lock when shifting from “Park.”

-Doors lock when the vehicle speed goes above

approximately 12 mph.

-Doors unlock when shifting into “Park.”

-Doors unlock when the ignition switch is turned

from ON to ACC or LOCK and driver’s door is

opened.

Downshifting increases power going uphill, or

provides engine braking downhill. For best fuel

economy during normal driving conditions, always

drive with the shift lever in the “D” position.

1Key must be in “ON” or “ACC” position, and the

brake pedal depressed to shift from “Park.”

2Shift to “2” position, then push “SHIFT L.”

Push again to upshift.

OVERVIEW

Windshield and back window washer fluid tank

Power steering fluid reservoir

Engine oil level dipstick

Engine oil filler cap

Engine coolant reservoir

Note: Regularly scheduled maintenance, including

oil changes, will help extend the life of

your vehicle and maintain performance.

Please refer to the “Owner’s Warranty

Information Booklet,” “Scheduled

Maintenance Guide” or “Owner’s Manual

Supplement.”

Engine maintenance

First gear2

07 Sequoia PRG Inside 9/25/06 11:02 AM Page 8

FEATURES/OPERATIONS

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Seat adjustments-Front

Position

Height crank (driver side only)

Seatback angle

Position, cushion angle and height

Seatback angle

Lumbar support

Manual seat Power seat

Seat adjustments-Rear

Seatback angle and fold

Seatback angle, fold and tilt

Position

Fold/remove

Second row seats

Bench type Separate type

Third row seats

4WD control switches

Four-wheel drive (if equipped)

2WD

4HI

4LO

Low speed (4WD)

Push “4LO” with shift

into “N” position.

Center differential lock button

For best fuel economy and performance under

normal driving conditions In “2WD” position, with

center differential unlocked (center differential lock

and “VSC OFF” indicator are not illuminated).

Center differential lock/unlock

Parking brake

Set: Depress

Release: Depress again

2WD - High speed

(indicator not illuminated)

4HI - High speed (4WD)

Push “2WD/4HI” with

speed below 62 mph.

07 Sequoia PRG Inside 9/25/06 11:02 AM Page 10

FEATURES/OPERATIONS

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Windshield wiper & washer

Interval wipe

Slow

Fast

Adjust interval

Front

Rear

Wash and wipe

Wipe

Interval wipe

Wash and wipe

Mirrors-Power side view

Fold mirrors in

Return mirrors

to original

position

Limited model only

Adjust

Select left

or right

Key must be in the “ACC” or “ON” position.

Lights & turn signals

Turn signals

Headlights

AUTO*

High beam flasher

* Limited model only

Low beam

Front fog lights (if equipped)

Headlights

-Daytime Running Light system (Limited model only)

Automatically turns on the headlights at a reduced

intensity.

-Automatic light cut off system Will automatically

turn lights off after a delay of thirty (30) seconds,

or the lock switch on remote may be pushed.

Front fog lights come on only when the headlights

are on low beam.

Parking lights

High beam

Right turn

Turn

Lane change

Left turn

Pull to wash and wipe

NOTE: Rear wiper and washer operate only when rear

window is fully closed. If battery is disconnected, rear

washer will not function until rear window is

reinitialized by fully opening and closing rear window.

Seats-Head restraints

Front Second row Third row

Lock release

button Lock release

buttons Lock release

button

07 Sequoia PRG Inside 9/25/06 11:02 AM Page 12

Rear

Front

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

FEATURES/OPERATIONS

Air Conditioning/Heating

Temperature

Automatic climate control ON/OFF

Air flow vent

Fan speed

Rear defogger

Air Conditioning ON/OFF

Fresh or recirculate cabin air

Windshield air flow

Climate control OFF

Automatic climate control ON/OFF

Air flow vent

Temperature

Fan speed

Climate control OFF

Main switch

Synchronizes front and rear setting

In “ ” or “ ” mode, use fresh air (“ ”

indicator “OFF”) to reduce window fogging.

Multi-information display (if equipped)

Select standard or metric

Garage door opener buttons Garage door

openers manufactured under license from

HomeLink®*can be programmed to operate

garage doors, estate gates, security lighting, etc.

Refer to the Owner’s Manual for more details.

For programming assistance, contact the Toyota

Customer Experience Center at 1-800-331-4331, or

visit http://www.homelink.com

Change display information

Garage door opener indicator

Information display

Compass

*HomeLink® is a registered trademark of Johnson Controls, Inc.

Seat heaters

Left front seat

Right front seat

07 Sequoia PRG Inside 9/25/06 11:02 AM Page 14

Otros manuales para SEQUOIA 2007

Tabla de contenidos

Otros manuales de Automóvil de Toyota

Toyota

Toyota Highlander 2021 Manual de usuario

Toyota

Toyota LAND CRUISER Manual de usuario

Toyota

Toyota COROLLA MATRIX 2009 Manual de usuario

Toyota

Toyota HIGHLANDER 2014 Manual de funcionamiento

Toyota

Toyota Tundra 2005 Manual de usuario

Toyota

Toyota CAMRY HYBRID 2021 Manual de usuario

Toyota

Toyota AVALON HYBRID 2019 Manual de usuario

Toyota

Toyota Hi-Lux 1973 Manual de usuario

Toyota

Toyota 1997 Avalon Manual de usuario

Toyota

Toyota 2007 Highlander Manual de usuario

Toyota

Toyota AVALON 2008 Manual de usuario

Toyota

Toyota AVALON - 2011 Manual de usuario

Toyota

Toyota 2014 COROLLA Manual de usuario

Toyota

Toyota Pius 2010 Instrucciones de funcionamiento

Toyota

Toyota Tacoma 1998 Manual de usuario

Toyota

Toyota HIGLANDER - CONDENSED BROCHURE 2011 Manual de usuario

Toyota

Toyota 2016 Highlander Manual de usuario

Toyota

Toyota 2016 RAV4 Manual de usuario

Toyota

Toyota TUNDRA 2004 Manual de usuario

Toyota

Toyota Tundra 2014 Manual de usuario

Toyota

Toyota RAV4 HYBRID 2017 Manual de usuario

Toyota

Toyota AVALON HYBRID 2013 Manual de usuario

Toyota

Toyota RAV4 2003 Manual de usuario

Toyota

Toyota 2009 Land Cruiser Manual de usuario

Manuales populares de Automóvil de otras marcas

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario

Skoda

Skoda FABIA RS - ANNEXE 118 Manual de usuario
