Toyota COROLLA 2010 - Manual de usuario

CUSTOMER EXPERIENCE CENTER

1-80 0 -331- 4 331

00505-QRG10-COR

Printed in U.S.A. 1/09

08-TCS-02940

413269M1.indd 2 1/9/09 1:23:38 PM

QUICK REFERENCE

GUIDE

COROLLA

2010

413269M1_r1.indd 1 1/13/09 9:18:37 AM

Information Provided by:

2010

Corolla

!Awordaboutsafevehicleoperations

This Quick Reference Guide is a summary of basic vehicle

operations. It contains brief descriptions of fundamental

operations so you can locate and use the vehicle’s main

equipment quickly and easily.

The Quick Reference Guide is not intended as a substitute for

the Owner’s Manual located in your vehicle’s glove box. We

strongly encourage you to review the Owner’s Manual and

supplementary manuals so you will have a better understanding

of your vehicle’s capabilities and limitations.

Your dealership and the entire staff of Toyota Motor Sales,

U.S.A., Inc. wish you many years of satisfied driving in your

new Corolla.

This Quick Reference Guide is not a full description of Corolla

operations. Every Corolla owner should review the Owner’s

Manual that accompanies this vehicle.

Pay special attention to the boxed information highlighted in

color throughout the Owner’s Manual. Each box contains safe

operating instructions to help you avoid injury or equipment

malfunction.

All information in this Quick Reference Guide is current at

the time of printing. Toyota reserves the right to make

changes at any time without notice.

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Spare tire & tools

To o l l o c a t i o n

Removing the spare tire

(1) Remove the luggage floor cover.

(2) Remove the tool tray.

(3) Loosen the center fastener that secures the spare tire.

Refer to the Owner’s Manual for tire changing and jack positioning

procedures.

Spare tire Jack

Tool box

(1) (2)

(3)

Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Engine maintenance 7

Fuel tank door release and cap 6

Hood release 7

Indicator symbols 5

Instrument cluster 4

Instrument panel 2-3

Keyless entry16

Air Conditioning/Heating 14

Audio 12-13

Auto lock functions29

Automatic Transmission 8

Auxiliary storage 18

Clock 16

Cruise control 15

Cup holders 18

Door locks-Power 17

Light control-Instrument panel 18

Lights&turnsignals 11

Moonroof 17

Multi-information display 15

Parking brake 8

Power outlets 14

Seat adjustments-Front 9

Seat adjustments-Rear 9

Seats-Head restraints 10

Telephone controls (Bluetooth®)16

Tilt and telescopic steering wheel 17

Windows-Power 10

Windshield wipers & washers 10

Child comfort guide 19

Doors-Child safety locks 20

Seatbelts 19

Seatbelts-Shoulder belt adjustment 19

Spare tire & tools 21

Tire Pressure Monitoring (warning) System 20

Trunk-Internal release 20

OVERVIEW

FEATURES/OPERATIONS

SAFETY AND

EMERGENCY FEATURES

1Visit your Toyota dealer for information on customizing this feature.

2Programmable by customer. Refer to the Owner’s Manual for instructions and

more information.

INDEX

Information Provided by:

OVERVIEW

Instrument panel

Steering wheel audio controls1,2

Voice command button1

Te l e p h o n e c o n t r o l s 1

Ignition switch (mechanical key)1

Cruise control1

VSC/TRAC OFF switch

Power rearview mirror control

Auxiliary storage

Headlight, turn signal and front fog light1controls

Wiper and washer controls

Emergency flasher button

Audio system2

Air Conditioning controls

Outside rearview mirror1/Rear window defogger button

Steering wheel controls

Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Front passenger seatbelt reminder light

“AIR BAG ON” and “AIR BAG OFF” indicator

Engine immobilizer indicator

AUX adapter

Tire Pressure Monitoring (warning) System reset

Tilt and telescopic steering control

Hood lock release lever

1If equipped

2Vehicles with navigation system: for details, refer to the “Navigation

System Owner’s Manual.”

Air Conditioning system

Information Provided by:

OVERVIEW

Instrument cluster

Service indicator and reminder

Tachometer

Speedometer

Fuel gauge

Trip meter reset/Instrument panel light control

Odometer and two trip meters

Automatic Transmission shift range display (if equipped)

Multi-information display

Display button

Engine coolant temperature

Optitron type meters

Non-optitron type meters

Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Indicator symbols

Charging system warning1

Brake system warning1

AIR BAG ON and AIR BAG OFF indicator1

Anti-lock Brake System warning1

Headlight low/high beam indicator

Turn signal indicator

Slip indicator1

Cruise control indicator

Low Tire Pressure Warning1

Open door warning

SRS Airbag warning1

Driver seatbelt reminder

(alarm will sound if speed is over 12 mph)

Front passenger seatbelt reminder

(alarm will sound if speed is over 12 mph)

Malfunction/Check Engine indicator1

Low fuel level warning

Fog light indicator

For details, refer to “Indicators and warning lights,” Section 2-2, 2010

Owner’s Manual.

Low engine oil pressure warning1

Vehicle Stability Control OFF indicator1

Engine oil replacement reminder1

Electric power steering warning1

1If indicator does not turn off within a few seconds of starting engine, there may

be a malfunction. Have vehicle inspected by your Toyota dealer.

Information Provided by:

OVERVIEW

Keyless entry (if equipped)

Push

Push ONCE: Driver door

TWICE: All doors

Locking operation Unlocking operation

Panic button

Push and hold

NOTE: Ifadoorisnotopenedwithin

60 seconds of unlocking, all doors will

relock for safety.

Trunk lid operation

Push and hold

Fuel tank door release and cap

NOTE: Tighten until one click is

heard. If the cap is not tightened

enough, Check Engine “”

indicator may illuminate.

Pull

Tu r n

Store

Information Provided by:

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Hood release

Pull up latch

and raise hood

Engine coolant reservoir

Engine oil filler cap

Engine oil level dipstick

Windshield washer fluid tank

Note: Regularly scheduled maintenance, including oil changes, will

help extend the life of your vehicle and maintain performance.

Please refer to the “Owner’s Warranty Information Booklet,”

“Scheduled Maintenance Guide” or “Owner’s Manual

Supplement.”

Engine maintenance

Pull

4 cylinder (2AZ-FE) engine

cylinder

(2ZR-FE) engine

Information Provided by:

FEATURES/OPERATIONS

Automatic Transmission (if equipped)

* The ignition switch must be “ON” and the brake pedal depressed to shift

from Park.

Downshifting increases power going uphill, or provides engine braking

downhill. For best fuel economy during normal driving conditions, always

drive with the shift lever in the “D” position.

Floor shift type:

+: Upshift (push and release)

-: Downshift (pull and release)

“S” (Sequential) mode

Shift the shift lever to “S” position from “D” position.

Standard type Multi-mode type

Park*

Reverse

Neutral

Drive

“S” mode

Park*

Reverse

Neutral

Drive

Third gear

Second gear

First gear

“S” “D”

Parking brake

(2) Push

Set Release

(1) Pull slightly

(3) Lower

Pull

Information Provided by:
