Toyota Avalon 2007 Manual de usuario

MN 00452-PRG07-AVA

Printed in USA 07/06

2007 Pocket Reference Guide

Customer Experience Center 1-800-331-4331

Flip over to see your

iGuide.

2007 Avalon

Open This and Really Get into

Your New Toyota

The Ultimate

Interactive Owner’s Guide

Flip over to see your

Pocket Reference Guide.

2007

Avalon

!A word about safe vehicle operations

This Pocket Reference Guide is a summary of basic vehicle

operations. It contains brief descriptions of fundamental

operations so you can locate and use the vehicle’s main

equipment quickly and easily.

The Pocket Reference Guide is not intended as a substitute for

the Owner’s Manual located in the vehicle’s glove box. We

strongly encourage you to review the Owner’s Manual and

supplementary manuals so you will have a better understanding

of the vehicle’s capabilities and limitations.

Your dealership and the entire staff of Toyota Motor Sales,

U.S.A., Inc. wish you many years of satisfied driving in your

new Avalon.

This Pocket Reference Guide is not a full description of

Avalon operations. Every Avalon owner should review the

Owner’s Manual that accompanies this vehicle.

Pay special attention to the boxed “ ” information

highlighted in this reference guide and throughout the

Owner’s Manual. Each box contains safe operating

instructions to help you avoid injury or equipment

malfunction.

All information in this Pocket Reference Guide is current at

the time of printing. Toyota reserves the right to make

changes at any time without notice.

Avalon

iGuide

WINDOWS 98

PENTIUM III 600MHZ

64MB OF RAM

800 X 600 MONITOR

16-BIT COLOR

CD-ROM DRIVE

MACINTOSH

SYSTEM 9.X,

OS X 10.2

POWERPC

64MB OF RAM

24-BIT COLOR

CD-ROM DRIVE

MINIMUM REQUIREMENTS

This iGuide is designed to be played on

any computer—PC or Macintosh.

INDEX

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

OVERVIEW

FEATURES/OPERATIONS

SAFETY AND

EMERGENCY FEATURES

Engine maintenance 8

Fuel tank door release and cap 6

Hood release 7

Indicator symbols 4-5

Instrument cluster 4

Instrument panel 2-3

Keyless entry17

Remote engine starter 8

Trunk release 6

Air Conditioning/Heating 15

Audio 16-17

Auto lock functions110

Automatic Transmission 11

Clock 10

Cruise control 19

Cup holders 21

Door locks 18

Dynamic Laser Cruise Control 20

Garage door opener (HomeLink®)211

Light control-Instrument panel 21

Lights & turn signals 14

Moonroof 19

Parking brake 10

Power outlets 21

Seat adjustments-Front 12

Seat adjustments-Rear 12

Seat ventilators/heaters 18

Seats-Head restraints 12

Smart Key19

Steering wheel switches 18

Sunshade-Rear 19

Tilt and telescopic steering wheel 10

Windows 13

Windshield wiper & washer 13

Doors-Child safety locks 22

Seat belt comfort guide 23

Seat belts 22

Seat belts-Shoulder belt anchor 22

Spare tire & tools 23

Tire Pressure Warning System reset 22

Trunk-Internal release 23

1Programmable by customer. Refer to the Owner’s Manual for instructions and

more information.

2HomeLink®is a registered trademark of Johnson Controls, Inc.

OVERVIEW

Instrument panel

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Cruise control or Dynamic Laser Cruise Control1

Dynamic Laser Cruise Control distance button1

Tilt steering lock release

Telescopic steering lock release

Glass breakage sensor1

Rear electric sunshade button1

Hood release lever

Trunk release button

Fuel tank door release button

Power rear view mirror controls

1If equipped

2For details, refer to the “Navigation System Owner’s Manual.”

Instrument panel light control

Headlight, turn signal and front fog light1controls

Steering wheel audio controls

Speech command button1, 2

Steering wheel climate controls

Wiper and washer controls

Rear window and outside rear view mirror defogger1switch

Emergency flasher switch

Audio system

Air Conditioning controls

Auxiliary box, 12V DC Power outlet/Cigarette lighter and ashtray1,

cassette player1or navigation controller1, 2

Ignition switch/Engine switch1

1For details, refer to “Service reminder indicators and warning buzzers,” Section 1-6, 2007

Owner’s Manual.

OVERVIEW

When the anti-lock brake system (ABS) function is in action, you may feel the

brake pedal pulsating and hear a noise. In this situation, to let the anti-lock

brake system work for you, just hold the brake pedal down more firmly. Do not

pump the brake as this will result in reduced braking performance.

Indicator symbols

Indicator cluster

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Anti-lock Brake System warning light1

Automatic headlight leveling system warning

Engine oil replacement reminder1

Smart Key system warning1

Headlight indicator

Headlight high beam indicator

Turn signal indicator

Cruise control indicator2or Dynamic Laser Cruise Control indicator3

Dynamic Laser Cruise Control ready mode indicator

Conventional cruise control mode indicator

Slip indicator

Automatic Transmission indicator

Airbag SRS warning1

Vehicle Stability Control/Traction Control warning

Low windshield washer fluid level warning

Engine immobilizer/Theft deterrent system indicator

Engine coolant temperature

Service indicator and reminder

Tachometer

Speedometer

Fuel gauge

Low fuel level warning light

Trip meter reset

Odometer and two trip meters

Sequential shift display

Dynamic Laser Cruise Control display

Dynamic Laser Cruise Control master warning light

Brake system warning1

Battery warning1

Malfunction/Check Engine indicator1

“AIRBAG ON” indicator

Low engine oil pressure warning1

“AIRBAG OFF” indicator

2If this light flashes, refer to “Cruise control,” Section 1-7, 2007 Owner’s Manual.

3If this light flashes, refer to “Dynamic laser cruise control,” Section 1-7, 2007 Owner’s

Manual.

Open door warning1

Driver seat belt reminder1

(alarm will sound if speed is over 9 mph)

Front passenger seat belt reminder1

(alarm will sound if speed is over 9 mph)

Low Tire Pressure Warning1

OVERVIEW

Fuel tank door release and cap

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Trunk release

Push

Tu r n

Store

Push

Push to activate/deactivate

trunk opener.

Trunk manual release

Pull down

Open Pull to

open trunk

NOTE: Tighten until one click

is heard. If the cap is not

tightened enough, Check

Engine “ ” indicator may

illuminate.

Hood release

Keyless entry

Locking operation Unlocking operation

Trunk lid operation

Beep sound can be switched “ON” or “OFF.” Refer to the Owner’s Manual

for more details.

Push ONCE: Driver door

TWICE: All doors

Push and hold Push and hold

Alarm operation

Push

NOTE: After unlocking, if a door is

not opened within 30 seconds, all

doors will relock for safety.

Pull

Pull up

latch and

raise hood

OVERVIEW FEATURES/OPERATIONS

Remote engine starter (if equipped) Smart Key* (if equipped)

Start function

Accessories such as the radio will operate.

Power ON, the engine not running.

All systems OFF.

ACC

OFF

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Start operation

Push twice, then push and hold.

Stop operation

Push “ ” or push “ ” once then push “ ” and hold.

Refer to the Remote Engine Starter Owner’s Manual for more details.

NOTE: Gear shift lever must be in Park and brake pedal depressed.

Push

Depress

Carrying

Green indicator ON

Without depressing the brake pedal, pressing the “ENGINE START STOP”

switch will change the operation mode in succession from:

Locking/Unlocking operation

Carry remote

to lock/unlock

Push Trunk open

Front door unlock

Push

Grasp

Front door lock

* Driver door unlocking function can be programmed to unlock driver door

only, or all doors. Grasping passenger handle will unlock all doors.

NOTE: Doors may also be locked/unlocked using remote.

Power (without starting engine)

Engine maintenance

Engine coolant reservoir

Power steering fluid reservoir

Engine oil filler cap

Engine oil level dipstick

Windshield washer fluid tank

Note: Regularly scheduled maintenance, including oil changes, will

help extend the life of your vehicle and maintain performance.

Please refer to the “Owner’s Warranty Information Booklet,”

“Scheduled Maintenance Guide” or “Owner’s Manual

Supplement.”

FEATURES/OPERATIONS

Auto lock functions

Parking brake

Automatic Transmission

1110

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Automatic door locks can be programmed to operate in 4 different modes,

or turned OFF.

-Doors lock when shifting from “Park.”

-Doors lock when the vehicle speed goes above approximately 12 mph.

-Doors unlock when shifting into “Park.”

-Doors unlock when the ignition switch is set from ON to ACC or OFF and

driver’s door is opened.

Refer to the Owner’s Manual for more details.

Set: Depress

Release: Depress again

Tilt and telescopic steering wheel

Clock

NOTE: Do not attempt to adjust while the vehicle is in motion.

Lock release lever

Length

H-Hour set

M-Minute set

:00-Round off minutes

Garage door openers manufactured under license from HomeLink®* can be

programmed to operate garage doors, estate gates, security lighting, etc.

Refer to the Owner’s Manual for more details.

For programming assistance, contact the Toyota Customer Experience

Center at 1-800-331-4331, or visit http://www.homelink.com.

* HomeLink®is a registered trademark of Johnson Controls, Inc.

Park1

Reverse

Neutral

Drive

“S”

“D”

Garage door opener (HomeLink®)*

(if equipped)

Lock release lever

Angle

“S” position:

+: Upshift (Push and release)

-: Downshift (Pull and release)

“S” (Sequential) mode

Downshifting increases power going uphill, or provides engine braking

downhill. For best fuel economy during normal driving conditions, always

drive with the shift lever in the “D” position.

Push shift lever to the left from “D” position.

1The ignition switch must be ON, and the brake

pedal depressed to shift from “Park.”

NOTE: In Navigation System-equipped vehicles, clock settings are in

navigation setup menu.

Seat adjustments-Rear

Seat adjustments-Front

FEATURES/OPERATIONS

Windshield wiper & washer

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Windows

Seatback angle

Position

Leg support (driver side only)*

Position, cushion angle and height (driver side only)

Seatback angle

Lumbar support (driver side only)

* If equipped

Seats-Head restraints

Seatback angle lever

Lock release button Lock release buttons

Front

Manual seat Power seat

With AUTO rain-sensing wiper (if equipped)

With interval wiper

Single wipe

Interval wipe

Slow

Fast

Pull to wash and wipe

Adjust interval

Single wipe

AUTO speed

Slow

Fast

Adjust AUTO speed

Pull to wash and wipe

Window lock switch

Automatic operation (Front windows) Push the switch completely down

or pull it completely up and release to fully open or close. To stop window

mid-way, lightly push the switch in the opposite direction.

Window lock switch Deactivates all passenger windows. Driver’s window

remains operable.

NOTE: If battery is disconnected, the front windows need to be

reinitialized. Refer to the Owner’s Manual for more details.

Down

Rear

1514

FEATURES/OPERATIONS

Lights & turn signals

Headlights

OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES

Air Conditioning/Heating

AUTO

Parking lights

High beam flasher

Low beam

Headlights

DRL OFF

-Daytime Running Light system (DRL) Automatically turns on the

headlights at a reduced intensity.

-Automatic light cut off system Will automatically turn lights off after a

delay of 30 seconds, or the lock switch on remote may be pushed.

Turn signals

Right turn

Left turn

Lane change

Tu r n

Front fog lights come on only when the headlights are on low beam.

Front fog lights (if equipped)

Air Conditioning display

Windshield defogger

Temperature

Automatic climate control ON

Climate control OFF

Air Conditioning ON/OFF

Fresh or recirculate cabin air

Rear defogger

Air flow vent “MODE”

Fan speed

“DUAL” button

Indicator ON: Separate temperature settings for driver and

passenger.

Indicator OFF: Synchronize temperature settings for driver and

passenger.

High beam

In “ ” or “ ” mode, use fresh air (“ ” indicator “OFF”) to

reduce window fogging.

Otros manuales para Avalon 2007

Tabla de contenidos

Otros manuales de Automóvil de Toyota

Toyota

Toyota Avalon 2019 Manual de usuario

Toyota

Toyota 2003 COROLLA Manual de usuario

Toyota

Toyota 4RUNNER BROCHURE 2011 Manual de usuario

Toyota

Toyota 2014 FJ Cruiser Manual de usuario

Toyota

Toyota Celica Supra 1986 Manual de instalación y funcionamiento

Toyota

Toyota Land Cruiser 1986 Manual

Toyota

Toyota RAV4 HYBRID 2017 Manual de usuario

Toyota

Toyota Prius HSD 2004 Manual de usuario

Toyota

Toyota 2005 Yaris Manual de usuario

Toyota

Toyota 2007 YARIS HATCHBACK Manual de usuario

Toyota

Toyota 2012 RAV4 EV infotainment system Manual de usuario

Toyota

Toyota 2014 Prius V Manual de usuario

Toyota

Toyota COROLLA 2010 - Manual de usuario

Toyota

Toyota 2014 Sienna Guía de instalación

Toyota

Toyota Avalon Hybrid 2015 Manual de usuario

Toyota

Toyota AVENSIS 2000 Manual del propietario

Toyota

Toyota 2013 Sienna Manual

Toyota

Toyota PRIUS 2008 Manual de usuario

Toyota

Toyota 2007 Highlander Manual de usuario

Toyota

Toyota AVALON 2005 Manual de usuario

Toyota

Toyota Coaster 2015 Manual de usuario

Toyota

Toyota 4RUNNER BROCHURE 2011 Manual de usuario

Toyota

Toyota 2011 Camry Hybrid Manual de usuario

Toyota

Toyota Prius 2011 Manual de usuario

Manuales populares de Automóvil de otras marcas

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario

Skoda

Skoda FABIA RS - ANNEXE 118 Manual de usuario
