Toyota 2009 Sequoia Manual de usuario
MN 00505-QRG09-SEQ
Printed in the USA 7/08
2009
Quick Reference Guide
33
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Push up
Seat belts-Shoulder belt anchor
Squeeze lock release to lower
Spare tire & tools
Spare tire, jack and tool location
Removing the spare tire
(1) Remove the cover.
(2) Assemble the jack handle.
(3) Insert the jack handle extension into the lowering screw. Lower the
spare tire completely to the ground.
Refer to the Owner’s Manual for tire changing and jack positioning
procedures.
Moving the lever to “LOCK” will allow the door to be opened only from
the outside.
Rear door
Doors-Child safety locks
(1) (2) (3)
Spare tire Jack and tool
2009
Sequoia
!Aword about safe vehicle operations
This Quick Reference Guide is a summary of basic vehicle
operations. It contains brief descriptions of fundamental
operations so you can locate and use the vehicle’s main
equipment quickly and easily.
The Quick Reference Guide is not intended as a substitute for
the Owner’s Manual located in your vehicle’s glove box. We
strongly encourage you to review the Owner’s Manual and
supplementary manuals so you will have a better understanding
of your vehicle’s capabilities and limitations.
Your dealership and the entire staff of Toyota Motor Sales,
U.S.A., Inc. wish you many years of satisfied driving in your
new Sequoia.
This Quick Reference Guide is not a full description of
Sequoia operations. Every Sequoia owner should review the
Owner’s Manual that accompanies this vehicle.
Pay special attention to the boxed information highlighted in
color throughout the Owner’s Manual.Each box contains safe
operating instructions to help you avoid injury or equipment
malfunction.
All information in this Quick Reference Guide is current at
the time of printing. Toyota reserves the right to make
changes at any time without notice.
1
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Engine maintenance 10
Fuel tank door release and cap 9
Hood release 9
Indicator symbols 6-7
Instrument cluster 5
Instrument panel 2-4
Keyless entry18
Light control-Instrument panel 10
Accessory meter 31
Air Conditioning/Heating 22-23
Audio 24-25
Auto lock functions112
Automatic Transmission 11
Cruise control 20
Cup holders 31
Door locks 28
Door-Power back 19
Dynamic Laser Cruise Control 27
Four-wheel drive 12
Garage door opener (HomeLink®)326
Lights1&turn signals 17
Moonroof 20
Multi-information display228
Parking brake 15
Power outlets-12V DC 30
Power outlets-115V AC 30
Rear seat entertainment system 25
Seat adjustments-Front 13
Seat adjustments-Rear 14
Seat ventilators/Heaters 23
Seats-Folding second row seats 15
Seats-Folding third row seats 16
Seats-Head restraints 13
Steering wheel switches 26
Telephone controls (Bluetooth®)29
Tilt and telescopic steering wheel 21
“TOW/HAUL” switch 11
VSC OFF button 21
Window-Back 19
Windows 18
Windshield wipers & washers 18
Doors-Child safety locks 33
Seat belts 32
Seat belts-Shoulder belt anchor 33
Spare tire & tools 33
Tire Pressure Monitoring (warning) System 32
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND
EMERGENCY FEATURES
1Visit your Toyota dealer for information on customizing this feature.
2Programmable by customer. Refer to the Owner’s Manual for instructions and
more information.
3HomeLink®is a registered trademark of Johnson Controls, Inc.
INDEX
2 3
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
OVERVIEW
Instrument panel
Steering wheel audio controls1
Voice command button1
Steering wheel climate controls1
Cruise control
Dynamic Laser Cruise Control distance switch1
Telephone controls1,2
Headlight, turn signal and front fog light1controls
Gauges and meters
Wiper and washer controls
115V AC Power outlet main switch1
Power back window switch
VSC OFF switch
Engine (ignition) switch
Tire Pressure Warning System reset
Personal/Interior light main switch
Instrument panel light control
Tilt and telescopic steering control switch1
Tilt and telescopic steering control lever1
Power back door main switch1
Roll Sensing of Curtain shield Airbag OFF switch
Headlight cleaner1
REVERSE TILT (side mirrors) switch1
Power back door button1
Power rearview mirror controls
1If equipped
2Vehicles with navigation system: for details, refer to the “Navigation
System Owner’s Manual.”
Steering wheel controls
(if equipped)
Details on the center panel
area on next page
4
Accessory meter
Theft deterrent system/Engine immobilizer indicator
Audio system2
Air Conditioning controls
Outside rearview mirrors1/Back window defogger/Windshield wiper
de-icer1button
12V DC Power outlet
Seat heater1and ventilator1controls
Cigarette lighter
AUX audio jack
Height control switch1
AVS button1
“TOW/HAUL” button1
Center differential lock/unlock switch1
Four-wheel drive control switch1
Intuitive parking assist button1
Multi-information display control button1and/or accessory meter
control button1
Emergency flasher button
1If equipped
2Vehicles with navigation system: for details, refer to the “Navigation
System Owner’s Manual.”
5
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
OVERVIEW
Instrument cluster
Tachometer
Speedometer
Service indicator and reminder
Fuel gauge
Voltmeter
Engine oil pressure gauge
Engine coolant temperature
Odometer/Trip meter and trip meter reset button
Multi-information display
Odometer and two trip meters
Automatic Transmission shift position indicator
Automatic Transmission shift range display
Automatic Transmission fluid temperature gauge
With multi-information display
Without multi-information display
Center panel area
6 7
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
Indicator symbols
Charging system warning1
Brake system warning1
AIR BAG ON indicator1
Driver seat belt reminder
(alarm will sound if speed is over 12 mph)
Front passenger seat belt reminder
(alarm will sound if speed is over 12 mph)
AIR BAG OFF indicator1
For details, refer to “Indicators and warning lights,” Section 2-2, 2009
Owner’s Manual.
Anti-lock Brake System warning
Headlight low/high beam indicator
Turn signal indicator
Slip indicator1
High/Low speed four-wheel drive indicator
Center differential lock indicator
Cruise control indicator
Low Tire Pressure Warning1
Power steering warning1
Open door warning
Airbag SRS warning1
Master warning
Theft deterrent/Engine immobilizer system indicator
Malfunction/Check Engine indicator1
Engine oil replacement reminder
Low fuel level warning
Roll Sensing of Curtain shield Airbag OFF indicator
Shift position and shift range indicators
AUTO Limited Slip Differential indicator1
Vehicle Stability Control OFF indicator1
TOW/HAUL mode indicator
Height control indicator1
Height control/MANUAL indicator1
Low windshield washer fluid level warning
OVERVIEW
1If indicator does not turn off within a few seconds of starting engine, there may
be a malfunction. Have vehicle inspected by your Toyota dealer
.
Automatic Transmission fluid temperature warning
8 9
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
OVERVIEW
Keyless entry
Push
Push ONCE: Driver door
TWICE: All doors
Locking operation
Unlocking operation
Power back door operation (if equipped)
Push and hold
NOTE: If a door is not opened within 60 seconds of unlocking, all doors will
relock for safety.
With power back door Without power back door
With power back door Without power back door
Panic button
Push and hold
Hood release
Pull up latch and
raise hood
Fuel tank door release and cap
NOTE: Tighten until one click is
heard. If the cap is not tightened
enough, Check Engine “ ”
indicator may illuminate.
Turn
Pull
Store
Pull
11
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
10
Windshield washer fluid tank
Engine oil level dipstick
Engine coolant reservoir
Engine oil filler cap
Note: Regularly scheduled maintenance, including oil changes, will
help extend the life of your vehicle and maintain performance.
Please refer to the “Owner’s Warranty Information Booklet,”
“Scheduled Maintenance Guide” or “Owner’s Manual
Supplement.”
Engine maintenance
Light control-Instrument panel
Brightness
control
-
+
OVERVIEW
4.7L 8 cylinder (2UZ-FE) engine
5.7L 8 cylinder (3UR-FE, 3UR-FBE) engine
FEATURES/OPERATIONS
Automatic Transmission
*The engine switch must be “ON” and the brake pedal depressed to shift
from Park.
Downshifting increases power going uphill, or provides engine braking
downhill. For best fuel economy during normal driving conditions, always
drive with the shift lever in the “D” position.
Floor shift type:
+:Upshift (push and release)
-: Downshift (pull and release)
“S” (Sequential) mode
Shift the shift lever to “S” position from “D” position.
Park*
Reverse
Neutral
Drive
“S” mode
“S” “D”
“TOW/HAUL” switch (if equipped)
“TOW/HAUL” mode can be used when carrying heavy loads. As fuel
economy is reduced while in “TOW/HAUL” mode, deactivating when
driving without a load is recommended.
Refer to the Owner‘s Manual for more details on this system before
attempting to use it.
System ON/OFF
12 13
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
FEATURES/OPERATIONS
Auto lock functions
Automatic door locks can be programmed to operate in four different
modes, or turned OFF.
-Doors lock when shifting from Park.
-Doors lock when the vehicle speed is approximately 12 mph or higher.
-Doors unlock when shifting into Park.
-Doors unlock when the driver’s door is opened within 10 seconds after
turning the engine switch to the “ACC” or “LOCK” position.
Refer to the Owner’s Manual for more details.
Lock the center differential when your vehicle’s wheels get stuck in a
ditch or when driving on a slippery or bumpy surface.
Center differential lock/unlock switch
Four-wheel drive
High speed (2WD)
High speed (4WD)
Turn to “4H” with speed below 62 mph.
Low speed (4WD)
Shift to “N” position when stopped, then push and turn to “4L.”
WD
For best fuel economy and performance under normal driving conditions,
keep in “2WD” position.
Push
and turn
Turn
Turn
Push
Four-wheel drive control switch
Seat adjustments-Front
Position
Seatback angle
Seat height
Seat cushion angle
Lumbar support (if equipped)
Position, cushion angle and height
Leg support
Manual seat
Power seat
Seats-Head restraints
Front Third row
Lock release button Lock release button
Height Angle
Second row
Height
Height
Lock release button
Height
14 15
OVERVIEW FEATURES/OPERATIONS SAFETY AND EMERGENCY FEATURES
FEATURES/OPERATIONS
Seat adjustments-Rear
Position
Seatback angle
Seatback lock release and slide
Seatback folding/returning
Refer to the Owner’s Manual for more details.
(1) Lower the head restraints.
(2) Stow the seat belt buckles.
(3) Fold down the seatback.
(4) Fold out the board (if equipped) from the seatback.
(1)
(3)
(2)
Seats-Folding second row seats
(4)
Pull
Second row
Third row
Pull
Separated seat Bench seat
Separate seat Bench seat
Manual seat Power seat
Parking brake
Set: Depress
Release: Depress again
Tabla de contenidos
Otros manuales de Automóvil de Toyota
Toyota
Toyota 2013 Highlander Hybrid Manual de usuario
Toyota
Toyota Celica 2005 Manual de usuario
Toyota
Toyota Corolla Hatchback 2019 Manual de usuario
Toyota
Toyota URBAN CRUISER Manual de usuario
Toyota
Toyota 2009 FJ Cruiser Manual de usuario
Toyota
Toyota 2009 Highlander Manual de usuario
Toyota
Toyota Tundra 2013 Manual de usuario
Toyota
Toyota 2014 Prius V Manual de usuario
Toyota
Toyota 2005 Yaris Manual de usuario
Toyota
Toyota GR Supra Manual de usuario
Toyota
Toyota 2015 4Runner Manual de usuario
Toyota
Toyota 4Runner 2021 Manual de usuario
Toyota
Toyota Avalon 1998 Manual de usuario
Toyota
Toyota Tundra 2005 Manual de usuario
Toyota
Toyota Corolla 2008 Manual de instrucciones
Toyota
Toyota 4Runner 2008 Manual de usuario
Toyota
Toyota Prius 2010 Manual de usuario
Toyota
Toyota Prius HSD 2006 Manual de usuario
Toyota
Toyota Land Cruiser 150 2014 Manual de usuario
Toyota
Toyota Corolla 2007 Manual de usuario
