. LITRE

DIGITAL DUAL BASKET

AIR FRYER

USER MANUAL

MODEL: T

APPLICABLE TO ALL COLOUR VARIANTS

TABLE OF CONTENTS

THIS BOX CONTAINS 3

SPECIFICATIONS 3

IMPORTANT SAFETY INFORMATION 4

•Key Safety Points 4

•General safety 4

•Whilst Air Frying 5

•Plug and cord 6

•Wiring safety 7

GETTING TO KNOW YOUR AIR FRYER 8

•Control panel and display 8

•Structure of your appliance 9

BEFORE FIRST USE 10

•Preparing for use 10

USING YOUR AIR FRYER 10

•Air fryer cooking basket safety switch 10

•Removing the cooking basket 10

•Turning the appliance ON and OFF 10

•Selecting a cooking basket 11

•Pre-set program selection 11

•Setting the temperature 11

•Setting the cooking time 12

•The sync function 12

•After cooking 12

•Tips 13

SUGGESTED TIMES/TEMPS 14

ACCESSORIES / SPARE PARTS 15

WEIGHTS & MEASURES TABLE 16

CLEANING AND CARE 17

TROUBLESHOOTING 18

DISPOSAL OF THE UNIT / CUSTOMER SUPPORT 19

RECIPES 20-22

NOTES 23

THIS BOX CONTAINS

SPECIFICATIONS

RATED VOLTAGE AC 220 - 240V~

FREQUENCY 50-60Hz

POWER CONSUMPTION 2400W

CAPACITY 8.5 Litre

TEMPERATURE RANGE 75°C - 200°C (35°C dehydrate)

TIME RANGE up to 60 minutes

DIMENSIONS (MM) H: 320 x W: 390 x D: 380mm

WEIGHT 8Kg

Instruction Manual

8.5L Double Basket Air Fryer

2 x Crisper grill plates

Please read these safety

NOTES carefully BEFORE

using your Tower appliance.

These warnings have been

provided in the interestof

safety. Basic safety

precautions should always

be followed including the

following:

KEY SAFETY POINTS

CAUTION:

During operation:

• Surfaces are hot. DO NOT

touch the hot surfaces.

• Hot steam is released

through the air outlet

openings. Keep your

hands and face at a safe

distance from the steam

and from the air outlet

openings.

• Hot steam and air

may escape when the

appliance cooking basket

is opened.

GENERAL SAFETY

• DO NOT immerse cords,

plugs or any part of the

appliance in water or any

other liquid.

• Close supervision is

necessary when any

appliance is used by or

near children.

• Children should not play

with the appliance.

• This appliance can be

used by children aged

from 8 years and above

and persons with reduced

physical, sensory or

mental capabilities or

lack of experience and

knowledge if they have

been given supervision or

instruction concerning use

of the appliance in a safe

way and understand the

hazards involved.

• Cleaning and user

maintenance should not

be undertaken by children

without supervision.

• Take care when any

appliance is used near

pets.

• Switch off and unplug

before ﬁtting or removing

accessories, after use and

before cleaning.

• Allow the appliance

to cool down for

approximately 30 minutes

before ﬁtting or removing

accessories or cleaning.

• If the supply cord or

appliance is damaged,

stop using the appliance

immediately and

seek advice from the

manufacturer, its service

agent or a similarly

qualiﬁed person.

IMPORTANT SAFETY INFORMATION

• The use of accessory

attachments is not

recommended by the

appliance manufacturer,

apart from those supplied

with this product.

• DO NOT use the appliance

outdoors.

• DO NOT place the

appliance on or near a hot

stove top or heated oven.

• Take care when moving

the appliance, or

removing accessories

and food as hot oil or

other hot liquids may be

present.

• This appliance is for

household use only.

• DO NOT place anything

on top of the appliance.

• DO NOT clean the

appliance with

metal kitchen utensils,

caustic or abrasive

cleaning agents or

scouring sponges.

• DO NOT use this

appliance for anything

other than its intended

use.

WHILST AIR FRYING

• Please ensure that the

appliance is used on a

stable, level, and heat

resistant surface.

• DO NOT place the

appliance on or near

combustible materials

such as a tablecloth or

curtain.

• DO NOT place the

appliance against a wall or

against other appliances.

Leave at least 10cm free

space on the back and

sides and 10cm free space

above the appliance.

• DO NOT place the

appliance in the presence

of explosive and/or

ﬂammable fumes.

• DO NOT cover the air

inlet and outlet during

operation.

• Any accessories, baking

trays or oven dishes

used in the appliance

will become hot. Always

use oven gloves when

handling or removing

anything from the

appliance.

• DO NOT place food that

is still packed in plastic

wrap or plastic bags in the

appliance.

• DO NOT allow food to

come into contact with

the heating element of

the appliance.

• If the appliance begins

to emit smoke, unplug it

immediately. Only open

the door once the smoke

has cleared. Remove

burnt remnants.

• DO NOT leave this

appliance unattended

whilst operating.

PLUG AND CORD

• Check that the voltage

of the main circuit

corresponds with the

rating of the appliance

before operating.

• WARNING: DO NOT let

the cord hang over the

edge of a table or counter,

serious burns may result

from the air fryer being

pulled off the counter

where it may

be grabbed by children or

become entangled with

the user.

• DO NOT let the supply

cord touch hot surfaces.

• DO NOT carry the

appliance by the power

cord.

• DO NOT use any extension

cord with this appliance.

• The appliance is not

intended to be operated

by means of an external

timer or separate remote-

control system.

• DO NOT pull the plug out

by the cord as this may

damage the plug and/or

the cable.

• DO NOT plug and unplug

with wet hands.

It is important that this instruction

manual is retained for future

reference.

If the appliance is given to someone

else, it should always be accompanied

by these operating instructions, as

they form an integral part of the

appliance.

IMPORTANT SAFETY INFORMATION

In the unlikely event the appliance develops a fault, stop using it immediately

and seek advice from the Customer Support Team.

IMPORTANT

As the colours in the mains

lead of this appliance may not correspond

with the coloured markings identifying

the terminals in your plug, please proceed

as follows:

The wires in the mains lead are labelled in

accordance with the following code:

Blue neutral [N] Brown live [L] Green/

Yellow [EARTH]

PLUG FITTING DETAILS (WHERE

APPLICABLE).

• Plug Fitting Details (Where

Applicable). The wire labelled blue is

the neutral and must be connected to

the terminal marked [N].

• The wire labelled brown is the live

wire and must be connected to the

terminal marked [L].

• The wire labelled green/yellow must

be connected to the terminal marked

with the letter [E].

• On no account must either the brown

or the blue wire be connected to the

[EARTH] terminal.

• Always ensure that the cord grip is

fastened correctly.

• The plug must be ﬁtted with a fuse

of the same rating already ﬁtted and

conforming to BS 1362 and be ASTA

approved.

• If in doubt consult a qualiﬁed

electrician who will be pleased to do

this for you.

NON-REWIREABLE MAINS PLUG.

f your appliance is supplied with a non-

rewireable plug ﬁtted to the mains lead

and should the fuse need replacing,

you must use an ASTA approved one

(conforming to BS 1362 of the same

rating).

If in doubt, consult a qualiﬁed electrician

who will be pleased to do this for you.

If you need to remove the plug -

disconnect it from the mains - then cut

it off of the mains lead and immediately

dispose of it in a safe manner. Never

attempt to reuse the plug or insert it into

a socket outlet as there is a danger of an

electric shock.

WIRING SAFETY FOR UK USE ONLY

GETTING TO KNOW YOUR AIR FRYER

CONTROL PANEL AND DISPLAY

1. Air fry mode selection key

2. Roast mode selection key

3. Grill mode selection key

4. Bake mode selection key

5. Reheat mode selection key

6. Dehydrate mode selection key

7. Time + key

8. Time selection key

9. Time - key

10. LED display screen

11. Power ON/OFF key

12. Right cooking basket selection key

13. Dual function selection key

14. Shake indicator

15. Sync function selection key

16. Left cooking basket selection key

17. Start/Pause key

18. Temperature - key

19. Temperature selection key

20. Temperature + key

21 43 5

18 17 16 15 14 13 12 11 10 9

20 7

STRUCTURE OF YOUR APPLIANCE

Air inlet

Air outlet

Cooking

basket

Basket

handle

Control

Panel

NEED PHOTOGRAPHY

Grill plates

PREPARING FOR USE

1. Read all instructions and safety

information carefully before ﬁrst use.

Please retain this information for

future reference.

2. Remove your appliance from the

packaging.

3. Check that there is no damage to

the cord or any visible damage to the

body.

4. Dispose of the packaging in a

responsible manner.

5. Remove any stickers or labels from

the appliance. DO NOT remove the

rating label.

6. Thoroughly clean the grill plates and

cooking baskets with hot water, some

washing-up liquid and a non-abrasive

sponge. Dry thoroughly.

7. Place the grill plates in the bottom of

the cooking baskets before use.

8. Wipe the inside and outside of the

appliance with a damp cloth. Dry

thoroughly.

9. Do not ﬁll the appliance with oil or

frying fat. This appliance operates

using hot air and requires very little to

no oil.

10. Familiarise yourself with the control

panel shown in the Speciﬁcations

section.

11. Situate your appliance according to

the Important Safety Instructions

section.

NOTE: When using the appliance for the

ﬁrst time, a slight smoke or odour may

be emitted. This is normal and will soon

subside. Ensure that there is sucient

ventilation around the appliance.

BEFORE FIRST USE

USING YOUR AIR FRYER

AIR FRYER COOKING BASKET

SAFETY SWITCH:

For your safety, this air fryer contains a

safety switch, designed to keep if from

accidentally turning on whenever the

cooking basket is not properly situated

inside the appliance or the timer is not set.

Before using your air fryer, please ensure

that the crisper grill plate is inside the

cooking basket and the cooking basket is

fully closed.

REMOVING THE COOKING

BASKETS:

Pull the handle to remove either cooking

basket, as shown in the illustration

below.

NOTE: If either cooking basket is

removed from the main body of the

fryer when in operation, the unit will

automatically stop working.

When the cooking basket is re-inserted,

the air fryer will resume operation on

the latest selected settings.

TURNING THE APPLIANCE ON

AND OFF:

To use the appliance, begin by plugging

it into a mains socket. The unit will give

off a sound prompt and the key will

illuminate.

Once the unit is plugged in, press the

key to turn the unit on. There will be a

sound prompt and the cooking basket

selection keys will illuminate.

Press the key again when the unit is in

operation to turn it off. The LED display

will go out.

Tabla de contenidos

Otros manuales de Freidora de Tower Hobbies

Tower Hobbies

Tower Hobbies T17055GRY Manual de usuario

Tower Hobbies

Tower Hobbies Presto PT17049WHT Manual del operador

Tower Hobbies

Tower Hobbies T17039 Manual de usuario

Tower Hobbies

Tower Hobbies VORTX T17085 Manual de usuario

Tower Hobbies

Tower Hobbies T17064 Manual de usuario

Tower Hobbies

Tower Hobbies T17058 Manual del operador

Tower Hobbies

Tower Hobbies T17061BLK Manual de usuario

Tower Hobbies

Tower Hobbies T17100 Manual de usuario

Tower Hobbies

Tower Hobbies T17065 Manual del operador

Tower Hobbies

Tower Hobbies T17021 Manual de usuario

Tower Hobbies

Tower Hobbies XpressPro Combo T17076 Manual de usuario

Tower Hobbies

Tower Hobbies T17089 Manual de usuario

Tower Hobbies

Tower Hobbies T17061BLK Manual de usuario

Tower Hobbies

Tower Hobbies T17069 Manual del operador

Tower Hobbies

Tower Hobbies T17020 Manual del operador

Tower Hobbies

Tower Hobbies T17006 Manual del operador

Tower Hobbies

Tower Hobbies 337116 Manual de usuario

Tower Hobbies

Tower Hobbies T17101 Manual de usuario

Tower Hobbies

Tower Hobbies T17090 Manual de usuario

Tower Hobbies

Tower Hobbies T17008 Manual del operador

Tower Hobbies

Tower Hobbies T17055GRY Manual del operador

Tower Hobbies

Tower Hobbies VORTX T17068 Manual de usuario

Tower Hobbies

Tower Hobbies VORTX T17127 Manual de usuario

Tower Hobbies

Tower Hobbies Vortx T17052 Manual de usuario

Manuales populares de Freidora de otras marcas

Innsky

Innsky 55SA1US Manual de usuario

Falcon

Falcon G350/11 Guía del usuario

GoWISE USA

GoWISE USA GW22612 Manual de usuario

Wolf

Wolf IF15/S Manual de usuario

Electrolux

Electrolux Thermetic 9CHG583284 Guía rápida

Gourmia

Gourmia GAF799 Manual de usuario

DeLonghi

DeLonghi D677UX Manual de usuario

SEVERIN

SEVERIN DEEP FRYER - Guía del usuario

Toastmaster

Toastmaster TMFG18-NAT Manual de usuario

Domo

Domo DO465FR Manual de usuario

Henny Penny

Henny Penny PFG-691 Manual de usuario

Farberware

Farberware FBW FT 43721 B Manual de usuario

GERMANICA

GERMANICA GEAF5L3LD Manual de usuario

Roller Grill

Roller Grill MF 120 R Manual de operación

Philips

Philips HD9211 Manual de usuario

Linea 2000

Linea 2000 Domo DO536FR Manual de usuario

Lakeland

Lakeland 31796 Manual de usuario

Dash

Dash Tasti-Crisp DFAF755 Manual de usuario
