Touch Revolution K15A Series Manual de usuario
Rev.A
K15A Series
Touch Screen LCD Monitors
USER’s GUIDE
The information contained in this document is subject to change without notice.
This document contains proprietary information that is protected by copyright. All rights
are reserved. No part of this document may be reproduced,translated to another language
or stored in a retrieval system, or transmitted by any means, electronic, mechanical,
photocopying, recording, or otherwise, without prior written permission. Windows is a registered
trademark of Microsoft, Inc. Other brand or product names are trademarks of their respective
holders.
The test results show that this device meets the FCC rules. Those limits are set to protect
residential areas from the devices with harmful emission. This device will produce, use and
radiate radio frequency energy. In addition, failure to follow the user’s manual to install or use
this device might produce harmful interference with radio communication. Not withstanding
the foregoing, it does not guarantee that this type of harmful interference does not occur in
some special installations. The interference caused by this device to the reception of radio
or television signals may be veried by turning it on and off. Any changes or modications to
this TFT LCD would void the user’s authority to operate this device.
Important Recycle Instruction:
Lamp(s) inside this product contains mercury. This product may contain other
electronic waste that can be hazardous if not disposed of properly. Recycle or
dispose in accordance with local, state, or federal Laws. For more information,
contact the Electronic Industries Alliance at WWW.EIAE.ORG. For lamp specic
disposal information check WWW.LAMPRECYCLE.ORG.
Table of Contents
Usage Notice
Precautions..............................................................................................................................1
Introduction
About K15A Series ..................................................................................................................2
Touch Screen for K15A-0101 ........................................................................................2
Package Overview .......................................................................................................3
Installation
Product Overview .........................................................................................................4
Front View ................................................................................................................4
Bottom View .............................................................................................................4
Attaching the L-Brackets...............................................................................................5
Side Mount for your monitor..........................................................................................6
Connecting the Display (Figure 10.1)............................................................................8
(Figure 10.1).............................................................................................................9
User Controls
Back Panel Controls ...................................................................................................10
How to Use the OSD Menus ....................................................................................... 11
On-Screen Display Menus ..........................................................................................12
Appendix
Troubleshooting..........................................................................................................13
Warning Signal ...........................................................................................................14
No Signal... .................................................................................................................14
Going to Sleep............................................................................................................14
Out of Range..............................................................................................................14
Product Dimensions ...................................................................................................15
Compatibility Modes ...................................................................................................16
Touch Screen Driver Installation .................................................................................17
K15A-0101 Install Instructions: ...............................................................................17
Usage Notice
! Warning - To prevent the risk of re or shock hazards, do not expose
this product to rain or moisture.
! Warning - Please do not open or disassemble the product as this may
cause electric shock.
Precautions
Follow all warnings, precautions and maintenance as recommended in this user’s manual to
maximize the life of your unit.
Do:
• Turn off the product before cleaning.
• Touch screen surface may be cleaned using a soft clean cloth moistened with mild
window glass commercial cleaners or 50/50 mixture of water and isopropyl alcohol.
• Use a soft cloth moistened with mild detergent to clean the display housing.
Don’t:
• Do not touch the LCD Display screen surface with sharp or hard objects.
• Do not use abrasive cleaners.
• Do not operate the product under the following conditions:
- Extremely hot, cold or humid environment.
- Areas susceptible to excessive dust and dirt.
- Near any appliance generating a strong magnetic eld.
- In direct sunlight.
1
Introduction
About K15A Series
The K15A Series is a 15" at panel screen with an active matrix, thin-lm transistor (TFT)
liquid crystal display (LCD).
Features include:
• Direct Analog signal input
• Active matrix TFT LCD technology
• 1024 x 768 XGA resolution
• 15” viewable display area
• 31.47 ~ 60.02 kHz horizontal scan
• 56 ~ 75 Hz high refresh rate
• 0.297mm x 0.297mm Pixel pitch
• Auto adjustment function
• Multilingual OSD user controls
• 75 mm VESA mount
• Bracket mount
• K15A-0101 - Projected Capactive touch screen with USB controller
Touch Screen for K15A-0101
• Projected Capactive touch screen for nger input only
• Surface: Clear glass
• Interface: USB controller
• HID: Windows® 7,VISTA, XP, 2000, ME, 98
• Driver: Linux kernel 2.6.x (32 bit & 64 bit)
2
Package Overview
LCD Display Power Cord VGA Signal Cable
3
DC Power Supply USB Cable ( A to B)
Bracket
Quick Start Guide
Remote Key
(sold separately)
Screws
Installation
Product Overview
• Front View
• Bottom View
VGA
RJ-11
USB DC IN
4
Attaching the L-Brackets
Depending on your mounting scheme, alternately, you may use the L-brackets to mount your
displays onto your wall or device.
Find a suitable location for attaching L-brackets.
A. The left and right sides
B. The Top and bottom sides
Bracket Bracket
or
Bracket
Bracket
Note:
You will need a screwdriver to attach the L-brackets.
Your kiosk touch monitor included two L-brackets (and four screws, M4x6).
This equipment is intended to be mounted in accordance with the proper hardware and the
installation instructions supplied with the product. Use of mounting brackets or screws other
than those specied in the installation instructions may cause a hazard.
5
Side Mount for your monitor
This monitor can be mounted with 4 screws and a pair brackets on the opposites.
132 mm
27.5 mm
16.5 mm
11 mm
1 mm
2-Ø5
156 mm
6
Customer panel material:
*A: The distance between the shielding surface and the bottom of the screw hole is 6.5 mm.
IMPORTANT!
! Warning!
Please select proper screws!
Please use four M4 screws of adequate length for mounting your monitor.
Please note: The mounting stand must be able to support at least 11 lbs (5kg)
7
72 mm 72 mm
365.93 mm
72 mm72 mm
144.96 mm
289.93 mm
RECOMMENDED CUSTOMER PANEL CUT-OUT
344.81 mm
268.81 mm
4-R4.29
AA
A
A
