Toshiba 32AF62 Manual de usuario

http://www.toshiba.com/tacp Customer Service: 800.631.3811

82 Totowa Road, Wayne, NJ 07470 (05/02.01)

Product design and specification subject to change or modification without notice. All television pictures are simulated and are for illustrative

purposes only.

Direct Video Input Selection

Movie and Sports Modes

Video Lock

Closed Captioning on Mute

Key Features

Double Baffle Speaker System

Surround Sound

Sub Bass System (SBS)

32AF62

Color Television

Advantage Toshiba

32" FST PURE

flat tube eliminates unwanted reflections from room light compared to

conventional tubes designs and increases viewing angle

Invar Shadow Mask enhances color reproduction thanks to its nickel-alloy construction which

is more heat resistant than conventional iron masks

3-Line Digital Comb Filter with Vertical Contour Correction provides more accurate processing

of RF and composite video signals for a sharper, cleaner picture

Advanced Velocity Scan Modulation improves contrast and overall picture sharpness

Dynamic Quadruple Focus produces clear legible text and graphics around the outside of the

screen thanks to improved edge and corner focus

Dual Tuner MultiWindow PIP provides simplified viewing of 2 channels at once without the

use of a VCR as a second source. MultiWindow adds the ability to scan through all the

channels via 6 boxes at the bottom of the screen

Colorstream

Component Video Input provides the ultimate picture quality from interlaced

component video signals

Front Panel A/V Input for easy connection of

video games or a camcorder

Illuminated Universal Remote also controls most

manufacturers VCRs

32AF62

FST PURE®Fine Pitch Flat Picture Tube

3-Line Digital Comb Filter with Vertical Contour Correction

Black Level Expander

Color Temperature Control

Technology and Benefits

FST PURE®Fine Pitch Flat Picture Tube

This "purely flat" picture tube delivers increased viewing angle

along with the enhanced picture linearity necessary to produce

accurate life-like images.

Black Level Expander

Improves contrast which results in a sharper more 3 dimensional

picture.

Color Temperature Control (Warm, Medium, Cool

The viewer can easily adjust white balance to achieve the best pic-

ture possible regardless of room lighting.

Double Baffle Speaker System

Provides improved stereo sound reproduction without connecting

additional speakers.

Surround Sound

Allows the viewer to enjoy an enhanced home theater experience

without the connection of additional speakers.

Sub Bass System

Creates richer, deeper home theater sound.

Direct Video Input Selection

Inputs can now be directly selected from the remote's numbered

keypad without scrolling through all the inputs.

Movie and Sports Modes

Allows for instant video adjustments for optimum viewing of popu-

lar types of programming.

Video Lock

Selected inputs can be locked out to prevent viewing

Closed Captioning on Mute - This feature automatically displays

captioned information (if available) when the mute button is

pressed.

32AF62 Color Television

32AF62

Specifications

32" FST PURE®Fine Pitch Flat Picture Tube

Invar Shadow Mask

3-Line Digital Comb Filter with Vertical Contour Correction

Advanced Velocity Scan Modulation

Dynamic Quadruple Focus

Black Level Expander

Flesh Tone Correction & Color Detail Enhancer

Color Temperature Control (Warm/Medium/Cool)

MTS Stereo/SAP with dbx

Double Baffle Speaker System

Surround Sound

Sub Bass System (SBS)

10 W Audio (Total)

Dual Tuner MultiWindow (6) PIP

Tri-Lingual Icon On-Screen Display

Closed Captioning on Mute

V-Chip

Sleep Timer

Channel Return

Power Return

Noise Muting

Favorite Channel

Channel Labeling

Movie and Sports Modes

Video Labeling

Video Lock

Direct Video Input Selection

Tilt Correction

Front Panel A/V Input

Colorstream®Component Video Input

Rear A/V/S Inputs (2)

A/V Output

Illuminated Universal Remote Control

Unit: 34 ½" x 26 ½" x 22 5/8" (W,H,D)

147 lbs.

Warranty: 1 Year Parts/Labor, 2 Years Picture Tube

UPC Code: 022265231982

Optional Stand: ST3262
