Toshiba PX1267E-1G32 Manual de usuario

Hi-Speed USB 2.0

External Hard Drive

USER’S GUIDE

For Models:

PX1265E-1G16

PX1266E-1G25

PX1267E-1G32

PX1268E-1G40

PX1269E-1G50

PX1270E-1G16

PX1271E-1G25

PX1272E-1G32

PX1273E-1G40

PX1274E-1G50

Getting Started

7 Welcome

8 Precautions

9 Package contents

10 System requirements

Getting to know your Toshiba 3.5" External Hard Drive

12 Toshiba 3.5" Drive at a glance

13 Toshiba 3.5" Drive in-depth

13 About Hi-Speed USB 2.0

15 CD + Secure HDD & Password Security

16 PushButton™ Backup

18 Synchronization (Sync)

18 Hot-Pluggable

19 Fanless Design

20 Technical specifications

Drive Installation & Setup

23 Setting up the Drive

23 Choosing an orientation (vertical or horizontal)

Contents

24 Attaching the stand for vertical placement

25 Affixing the rubber feet for horizontal placement

26 Connecting the Drive to your computer

29 Password Security

29 Setting up Password Security for the first time

30 Disabling Password Security

31 Enabling Password Security

32 What if you forget your password?

34 Naming your Drive

35 Re-formatting the Drive

37 Stacking Drives

Using the Drive

39 Performing routine tasks

39 Opening files and folders

39 Copying files and folders to your Drive

40 How to unmount and turn off the Drive

PushButton™ Backup

42 About PushButton™ Backup

42 PushButton Backup Operations

43 Backup

44 Duplicate

45 Synchronization (Sync)

46 Installing Regen backup software

47 Installing Regen

47 Uninstalling Regen

48 Setting up and using PushButton Backup

49 Setting up a Backup Store

53 Setting up a Duplicate Store

56 Setting up a Sync Store

Using other Functions in Regen

61 Other Backup Operations

61 Archive

61 How to run an Archive operation

63 Disaster Recovery

64 Restore

64 About the Restore operations

65 How to Use Full Restore

67 How to Use File Restore

69 Using Find Files

73 Tools

73 Repair Catalog

74 Manage Stores

75 Selectors

Maintenance, Help & Other Information

78 Maintaining your Drive

79 Examining and Repairing a Hard Drive

80 Protecting Your Data from Viruses

80 Cleaning the Drive Case

81 Frequently Asked Questions

85 Troubleshooting

88 Following information is only for EU-member states:

88 Working environment

90 CE compliance

91 Notices

Getting Started

Welcome, and thank you for choosing

a Toshiba External Hard Drive.

Your Toshiba Drive features high-

quality construction, advanced

engineering, and state-of-the-art

data storage technology, designed

to provide years of reliable, user-

friendly performance.

This guide contains important information for the proper installation,

use, and care of your Toshiba Drive. Please read this guide carefully

and retain it for future reference.

Symbols used in this guide:

Welcome

This symbol alerTs The

reader To awarning or To

some very imporTanT

informaTion.

This symbol alerTs The

reader To helpful Tips and

oTher useful informaTion.

The usb logo alerTs

The reader To imporTanT

informaTion specifically

abouT usb-relaTed issues.

Please follow the precautions listed below. Failure to so do may result

in damage to the device, loss of data, and voiding of the warranty.

• If using this device for general-purpose storage, we strongly recommend

that you backup the files stored on the device. Toshiba is not responsible

for data loss or corruption; nor will Toshiba perform recovery of lost

data or files.

• Do not attempt to open, disassemble, or modify the device.

• Do not expose the device to damp or wet conditions.

• Never place containers of liquids on the device. This can damage

the device and increase the risk of electric shock, short-circuiting,

fire, or personal injury.

• If the device has a three-prong plug, never plug the device into

a two-prong outlet.

• Do not expose this device to temperatures outside the range of

5°C to 35°C when the device is in operation, and -20ºC to 60ºC

when not in operation.

• Do not use a third-party AC adapter or power cord.

• Do not bump, jar or drop the device.

• Do not stand the device in a way not described in this guide.

• Do not disconnect any cables, while the device is powered on,

without first unmounting the device.

Precautions

Package contents

"$POOFDUPS #$POOFDUPS

64#DBCMF

Toshiba 3.5" External Hard Drive

AC Adapter & Power Cord

Rubber Feet

(For placing the Drive

horizontally. See the User’s

Guide for instructions.)

USB Cable

QuickStart GuideSoftware CD

What you need:

• Minimum 233 MHz processor

(Pentium, Celeron, AMD, etc.)

• Windows 2000 or XP (Home Edition, Professional, Professional x64

Edition, Media Center Edition)

• Available USB 2.0 or USB 1.1 port

Windows XP users must have XP Service Pack 1 or later.

Windows 2000 users must have 2000 Service Pack 4 or later.

To get Windows updates go to www.microsoft.com and click on the

Microsoft Update link.

If connecting to a USB 1.1 port on your computer or hub, the Drive

will operate at USB 1.1 speeds (up to 12 Mbps).

System requirements
