User’s Manual

CAMILEO B10

Introduction

Welcome and thank you for choosing a TOSHIBA product.

For your convenience, your TOSHIBA product is furnished with two

guides:

a) a Quick Start Guide, and

b) this comprehensive PDF User’s Manual.

Contents

Section 1 Getting to Know Your Camcorder........................................ 6

Overview ................................................................................ 6

Check the Components........................................................ 6

Safety Instructions................................................................ 7

System Requirements .......................................................... 7

Front View ............................................................................. 8

Side View ............................................................................... 9

Bottom View .......................................................................... 9

Section 2 Getting Started..................................................................... 10

Loading the Battery ............................................................ 10

Charge your battery............................................................ 10

Inserting and Removing an SD Card (Optional)............... 11

Turning the Camcorder On and Getting Started .............. 12

Turning the Camcorder Off ................................................ 12

Section 3 Record Mode........................................................................ 13

Button Function .................................................................. 13

LCD Monitor Information.................................................... 14

Video Recording.................................................................. 16

Photo Recording ................................................................. 16

Using Digital Light or Light Function................................ 16

Using Digital Zoom ............................................................. 16

Options for Menu ................................................................ 17

Operations .......................................................................... 17

Video Setting ....................................................................... 18

Photo Setting....................................................................... 22

Effects .................................................................................. 26

Delete ................................................................................... 28

Contents

Section 4 Playback Mode..................................................................... 30

Button Function .................................................................. 30

LCD Monitor Information.................................................... 31

Operations for Playback Mode ......................................... 32

Video Playback.................................................................... 33

Photo Playback ................................................................... 33

Delete File in Playback Mode............................................. 34

Section 5 Setting Your Camcorder .................................................... 35

Setup Menu.......................................................................... 35

Section 6 Viewing Photos and Videos on TV..................................... 38

Connecting to a High-Denition 16:9(Wide) TV ............... 38

Section 7 Viewing Photos and Videos on PC .................................... 39

Installing Bundled Software............................................... 39

Transferring Photos or Videos to a Computer ................. 39

Section 8 Uploading Files to Internet ................................................. 40

Section 9 PC Camera Mode................................................................. 44

PC Camera Mode-Webcam ................................................ 44

Contents

Section 10 Specications ................................................................... 45

Section 11 Troubleshooting................................................................. 46

Section 12 Other Information .............................................................. 47

TOSHIBA Support ............................................................... 47

Operating Environment Conditions .................................. 47

Regulatory Information ...................................................... 47

Additional Information........................................................ 48

About the battery pack ....................................................... 48

Section 1

Getting to Know Your Camcorder

Overview

The camcorder equipped a 5 Mega Pixel sensor that can take H.264 format videos. The H.264 technology

allows for extended video recording with less memory. High quality images up to 16 mega-pixels can

also be delivered smoothly. With a color LCD monitor, you can view and examine the videos and photos

easily.

This compact camcorder also features video recording at HD resolution of 1920x1080. You can also

connect it to an HDTV via an HDMI cable, and easily playback the recorded high-denition videos on

the wide screen HDTV.

Moreover, the camcorder has an advanced uploading feature. With the exclusive built-in CAMILEO

UPLOADER application, you can upload the videos or photos captured by the camcorder to Internet

more effortlessly.

ISO sensitivity and color balance can either be adjusted automatically or changed manually. A 16x digital

zoom helps you to control over the videos and photos you take.

The built-in memory allows you to take photos and to record videos without a memory card. The memory

card slot allows users to increase the storage capacity.

Note

• Partialmemoryofthebuilt-inmemoryisusedforthecamcorder’sFirmwarecode.

• InstallthebundledsoftwareapplicationforviewingthevideoscorrectlyonaPC.

Check the Components

Unpack the package and make sure all standard accessories listed are included:

Note

Pleaseremovethelensprotectlmonlensbeforeuse.

AC Adapter

USB Cable HDMI Cable

Camcorder Lithium-ion

Rechargeable

Battery

Quick Start Guide

CD-ROM

(Software, User’s Manual

& Warranty Information )

Warranty LeafletCleaning Cloth

*preinstalled in camcorder device

Strap Pouch Tripod

Safety Instructions

Do not drop, puncture or disassemble the camcorder; otherwise the warranty will be voided.1.

Avoid all contact with water, and dry hands before using.2.

Do not expose the camcorder to high temperature or leave it in direct sunlight. Doing so may3.

damage the camcorder.

Use the camcorder with care. Avoid pressing hard on the camcorder body.4.

For your own safety, avoid using the camcorder when there is a storm or lightning.5.

Do not use batteries of different specications. Doing so may lead to the potential for serious 6.

damage.

Remove the battery during long periods between usage, as a deteriorated battery may affect the7.

functionality of the camcorder.

Remove the battery if it shows signs of leaking or distortion.8.

Use only the accessories supplied by the manufacturer.9.

Keep the camcorder out of the reach of infants.10.

Risk of explosion if battery is replaced by an incorrect type.11.

Dispose of used batteries according to the instructions.12.

System Requirements

OS Microsoft Windows XP, Vista, 7

Hardware

CPU Intel Pentium 4, 2.4GHz or above

512MB system memory

1GB hard disk space

4x CD-ROM

1x available USB port

16-bit Color Display

Note

The LCD screen is manufactured using extremely high-precision technology. However, some

tiny black and/or bright dots (white, red, blue or green) may appear on the LCD screen.

Thesedotsareanormalresultofthemanufacturingprocess,anddonotaffecttherecording.

Front View

LCD Screen

[Return/Exit] Button

[Playback] Button

[Tele(Up)] Button

[Thumbnail] Button

[Wide(Down)] Button

[Delete] Button

[Right] Button

[Left] Button

[Menu/OK] Button

[Video] Button

[Photo] Button

Side View

Bottom View

Strap Hook

Tripod Socket

HDMI Port

Mini USB 2.0 Port

Speaker

Lens

Power Button

Indicator light

SD card Cover

Battery Cover

[Light] Button

[Internet] Button

Light

Microphone

Section 2

Getting Started

Loading the Battery

Before using the camera, you must load the supplied Lithium-ion rechargeable

battery.

Insert the battery according to the correct polarity marks ( + or -).1.

Close the battery cover rmly.2.

Note

Pleaseremovetheinsulatoronbatteryconnectionbeforeuse.

Charge your battery

You must use the supplied AC charger or the USB cable. The camcorder must be turned OFF. The

blinking light conrms the camcorder is currently charging, and the light becomes constant after the

charging is completed. In AC charging Mode, the full charge time is about 3.5 to 4.5 hours and the light

will turn itself off automatically after 3~5 minutes when the charging is completed. (Actual charging time

may vary. It depends on the battery conditions.)

REMOVE
