Figure7
1.Bolt,washerandnut(2)
2.Installarubbergrommetintotheholeineachheadlight
bracket(Figure8).
3.FastentheR.HandL.H.headlightbracketstothe
frontoftheoperator'splatformwiththebolts,washers
andnutspreviouslyremoved.Positionthebracketsas
showninFigure8.
Figure8
1.Wireharness5.Harnessclip
2.Headlightassembly,R.H.6.Rubbergrommet
3.Headlightbracket,R.H.7.Headlightassembly,L.H.
4.Headlightbracket,L.H.
4.FastentheR.HandL.H.headlightassembliesto
theheadlightbrackets(Figure8)withthefasteners
suppliedwiththelights.Makesuretheturnsignallens
ontheheadlightispositionedtowardtheoutsideof
themachine.
5.Plugtheconnectorbodyfromtheenclosedheadlight
wireharnessintotheharnessconnectorofthesteering
towerwireharnessunderthesteeringcoveropening.
6.Routetheheadlightwireharnessunderneaththefront
edgeoftheoperator'splatform.
7.Inserteachharnessconnectorthroughtheendofthe
appropriateharnessbracket,outthehole(grommet)
andconnectittotheheadlight(Figure8).
8.Securetheheadlightwiringharnesstotheheadlight
bracketsandoperator'splatformwiththeharnessclips
andcableties.
9.Installthesteeringtowercover.
ForGroundsmaster4010and4110,
Models30602,3060330606and30607
1.Fastentheheadlightbracketstotheexistingbrackets
onthefrontofthecabwithscrews(1/2x1inch)and
locknuts(1/2inch).Positionthebracketsasshown
inFigure9.
Figure9
1.Wireharness4.Headlightassembly,L.H.
2.Headlightassembly,R.H.5.Screw,1/2x1inch
3.Headlightbracket(2)6.Locknut,1/2inch
2.FastentheR.H.andL.H.headlightassembliesto
theheadlightbrackets(Figure9)withthefasteners
suppliedwiththelights.Makesuretheturnsignallens
ontheheadlightispositionedtowardtheoutsideof
themachine.
3.Plugtheconnectorbodiesfromtheenclosedheadlight
wireharnessintotheharnessconnectorsofthesteering
towerwireharness.
4.Routetheheadlightwireharnessunderneaththefront
edgeoftheoperator'splatformandconnectittothe
headlights(Figure9).
6
