Toro 74560 Manual

FormNo.3416-990RevA

DH140LawnTractor

ModelNo.74560—SerialNo.310000001andUp

SetupInstructions

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescriptionQty.Use

Steeringwheel1

Rollpin1

1Spacer1

Installthesteeringwheel.

Seat1

Bolts2

Adjustingknob2

Flatwashers4

Springwashers2

Installtheseat.

Grasscollector1

Grasscollectorbottomanddumpframe

assembly1

Hingepin2

Pushnut2

Snapring2

Assemblethegrasscollector.

4Nopartsrequired–Checktheoillevel.

5Nopartsrequired–Activatethebattery.

6Nopartsrequired–Fillthefueltank.

7Nopartsrequired–Checkthetirepressure.

8Nopartsrequired–Lubricatethemachine.

MediaandAdditionalParts

DescriptionQty.Use

Operator'sManual1

EngineOperator'sManual1Readbeforeoperating.

Key2UseintheignitionandKeyChoice™switch.

CerticateofConformance1SaveforCEproofofcertication.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedintheCzechRepublic

AllRightsReserved*3416-990*A

InstallingtheSteering

Wheel

Partsneededforthisprocedure:

1Steeringwheel

1Rollpin

1Spacer

Procedure

1.Positionthefrontwheelsstraightahead.

2.Installtheplasticspaceroverthesteering-wheel

shaft(smallerdiameterrst).

3.Slidethesteeringwheelovertheshaft,aligning

theholesoneachsideofthesteeringwheel

withtheholesinthespacerandwiththeholes

intheshaft.

4.Drivetherollpinthroughtheholesinthe

steeringwheel,theplasticspacer,andtheshaft

withahammertosecurethesteeringwheel.

InstallingtheSeat

Partsneededforthisprocedure:

1Seat

2Bolts

2Adjustingknob

4Flatwashers

2Springwashers

Procedure

1.Removetheplasticcoverfromtheseatand

discardit.

2.Settheseatinplaceandsecureitwiththe2

bolts,springwashers,andatwashers(Figure

1).

g012505

Figure1

1.Safetyswitch3.Adjustingknobsand

washers

2.Boltsandwashers

3.Installthe2adjustingknobsandwashers

(Figure1).

4.Ensurethatthesafetyswitchisconnectedto

theseat(Figure1).

AssemblingtheGrass

Collector

Partsneededforthisprocedure:

1Grasscollector

1Grasscollectorbottomanddumpframeassembly

2Hingepin

2Pushnut

2Snapring

Procedure

1.Installapushnutontotheendofeachhingepin

andslideittowithinan1/8inch(3mm)fromthe

endofeachpin(Figure2).

g012491

Figure2

1.Lockingpin4.Pushnut

2.Holeinthedumpframe5.Snapring

3.Hingepin

2.Slidethecollectorintothedumpframesothat

theholesinthedumpframelineupwiththe

holesinthesidesofthecollector(Figure2).

3.Pushahingepinthroughtheholesoneachside

frominsidethecollector,andsecureeachonthe

outsideusingasnapringinstalledintothegrove

onthepin(Figure2).

4.Turnthelockingpindowntolockthedump

frameinplace(Figure2).RefertotheOperator's

Manualformoreinformation.

5.Liftthecollectorandslideitontothehooks

onthebackofthetractionunit.Refertothe

Operator'sManualformoreinformation.

CheckingtheOilLevel

NoPartsRequired

Procedure

Themachinecomesfromthefactorywithoilinthe

enginecrankcase;however,itmaybenecessaryto

addoil.RefertotheOperator’sManualforoiltype,

viscosity,andcrankcasecapacity.Addonlyenough

oiltoraisetheleveltotheFULLmarkonthedipstick.

ActivatingtheBattery

NoPartsRequired

Procedure

1.Removethebatteryfromthemachine;referto

theOperator’sManual.

2.Removethellercapsfromthetopofthebattery.

DANGER

Batteryelectrolytecontainssulfuric

acid,whichisfatalifconsumedandcan

severelyburnyou.

•Donotdrinkelectrolyte.

•Avoidcontactwithskin,eyes,or

clothing.

•Wearsafetyglassestoshieldyour

eyesandrubberglovestoprotect

yourhands.

•Fillthebatterywherecleanwateris

availableforushingtheskin.

•Followallinstructionsandcomply

withallsafetymessagesonthe

electrolytecontainer.

3.Slowlypourelectrolyteintoeachcelluntilthe

levelisuptothelowerpartofthetube.

4.Leavethellercapsoff,andconnecta3to4A

batterychargertothebatteryposts.

5.Chargethebatteryatarateof2Aorlessforat

least24hours(12volts).

Important:Useonlyabatterychargersetto

12voltstochargethebattery.

Important:Donotstarttheenginewith

abatterybooster(jumpstarter)pack.

Jump-startingtheenginewithabattery

boosterpackmaydamageelectronic

componentsofthemachine.

WARNING

Chargingthebatteryproducesgasses

thatcanexplode.

Neversmokenearthebattery,andkeep

sparksandamesawayfromthebattery.

6.Installthellercapsafterthebatteryisfully

charged.

7.Installthebatteryinthechassis;refertothe

Operator’sManual.

FillingtheFuelTank

NoPartsRequired

Procedure

Addfueltothefueltank;refertotheOperator’s

Manual.

CheckingtheTirePressure

NoPartsRequired

Procedure

Checkfrontandreartiresforproperination;referto

theOperator’sManualfortherecommendedination

pressure.

LubricatingtheMachine

NoPartsRequired

Procedure

Ensurethatallofthenecessarypointsonthemachine

arelubricated;refertotheOperator’sManual.

CheckingtheSafetySystem

NoPartsRequired

Procedure

RefertotheOperator’sManual.
