Toro 70185 Manual

FormNo.3359-686RevA

G132andH132Rear-EngineRidingMower

ModelNo.70185

ModelNo.70186

SetupInstructions

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

ProcedureDescriptionQty.Use

Wheels2

Flatwashers,M16(3mmthick)2

Spacers,M16(1mmthick)4

1Cotterpins2

Installthefrontwheels.

Seat1

Screws,M8x18mm4

Flatwashers,M94

2Lockwashers4

Installtheseat.

3Socketpin1Attachthesteeringwheel.

Enginecover1

4Screws,M6x25mm2Installtheenginecover.

Frame1

Fabricbagwithclips1

Handle1

Locknuts,M82

Washers,M94

Assemblethegrasscollector.

Z-brackets2

Bolts,M6x35mm2

Spacers2

Washers2

Nuts,M62

Grasscollectorcover1

Pins2

Fullbaglever1

Installthegrasscollector.

Bolts,M6x20mm2

Flatwashers,M6.54

7Nuts,M62

Activatethebattery.

8Nopartsrequired–Checktheoillevel.

9Nopartsrequired–Fillthefueltank.

10Nopartsrequired–Checkthetirepressure.

11Nopartsrequired–Testthesafetysystem.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.Toro.com.OriginalInstructions(EN)

PrintedinItaly

AllRightsReserved

ProcedureDescriptionQty.Use

Operator’sManuals(Englishand

French)2

Engineoperator’smanual1

Keys2

Sparkplugwrench1

Oildraintube1

Recycler®cover1

Readthemanualbeforeoperatingor

servicingthemower.

InstallingtheFrontWheels

Partsneededforthisprocedure:

2Wheels

2Flatwashers,M16(3mmthick)

4Spacers,M16(1mmthick)

2Cotterpins

Procedure

1.Slideaatwasher(M16,3mmthick)ontoeach

spindle(Figure1).

Figure1

1.Spindle4.Spacers(M16,1mmthick)

2.Wheel5.Cotterpin

3.Flatwasher(M16,3mm

thick)

2.Mountthewheelsandsecureeachofthemwith2

spacers(M16,1mmthick)andacotterpin(Figure1).

3.Greasethewheels.

InstallingtheSeat

Partsneededforthisprocedure:

1Seat

4Screws,M8x18mm

4Flatwashers,M9

4Lockwashers

Procedure

Attachtheseattothesupportplatewith4atwashers

(M9),lockwashers,andscrews(M8x18mm)(Figure2).

Figure2

1.SeatSupportplate3.Lockwasher

2.Flatwasher(M9)4.Screw(M8x18mm)

Note:Beforetighteningthescrews,adjusttheseattoa

positionthatismostcomfortableforyou.

AttachingtheSteeringWheel

Partsneededforthisprocedure:

1Socketpin

Procedure

1.Rotatethesteeringwheelupwarduntilitisaligned

withthesteeringcolumn.

2.Securethesteeringwheelwiththesocketpin

(Figure3).

Figure3

1.Socketpin

InstallingtheEngineCover

Partsneededforthisprocedure:

1Enginecover

2Screws,M6x25mm

Procedure

1.Slidethetabsontheenginecoverintotheslotson

thebodyofthetractor(Figure4).

Figure4

1.Enginecover2.Screw

2.Securethecoverwith2screws(M6x25mm)

(Figure4).

AssemblingtheGrass

Collector

Partsneededforthisprocedure:

1Frame

1Fabricbagwithclips

1Handle

2Locknuts,M8

4Washers,M9

Procedure

1.Slidethebagontotheframeandsecureitwiththe

clips(Figure5).

Figure5

1.Bag2.Frame

2.Securethehandletothebagassemblywith4washers

(M9)and2locknuts(M8)(Figure6).

Figure6

1.Bagassembly3.Washer(M9)

2.Handle4.Locknut(M8)

InstallingtheGrassCollector

Partsneededforthisprocedure:

2Z-brackets

2Bolts,M6x35mm

2Spacers

2Washers

2Nuts,M6

1Grasscollectorcover

2Pins

1Fullbaglever

Procedure

1.Reachbeneaththerearofthetractorandholdthe

fullbagswitchandswitchplatewhileremovingthe2

screwsontherearpanel(Figure7).

Figure7

1.Rearpanel4.Fullbaglever

2.Switch5.Screw

3.Switchplate

2.Holdtheswitchplateagainsttheswitchandslide

thefullbagleverintotherectangularslotonthe

rearpanel.

3.Hooktheswitchplateontotheleverandsecurethe

switchandswitchplatetotherearpanelwiththe

2screws(Figure7).

4.Attachthegrasscollectortotherearofthetractor

with2bolts(M6x16.2mm),Z-brackets,spacers,

washers,andnuts(M6)(Figure8).

Figure8

1.Bolt(M6x35mm)4.Grasscollector

2.Z-bracket5.Washer

3.Spacer6.Nut(M6)

5.Attachthegrasscollectorcovertothetractorwith2

pins(Figure9).

Figure9

1.Grasscollectorcover2.Pin

ActivatingtheBattery

Partsneededforthisprocedure:

2Bolts,M6x20mm

4Flatwashers,M6.5

2Nuts,M6

Procedure

Purchasebulkelectrolytewith1.260specicgravity

fromalocalbatterysupplyoutlet.

Batteryelectrolytecontainssulfuricacid,a

deadlypoisonthatcancausesevereburns.

•Donotdrinkelectrolyteandavoidcontact

withskin,eyesorclothing.Wearsafety

glassestoshieldyoureyesandrubbergloves

toprotectyourhands.

•Fillthebatterywherecleanwaterisalways

availableforushingtheskin.

•Followallinstructionsandcomplywithall

safetymessagesontheelectrolytecontainer.

1.Removethebatteryfromthetractorandplaceiton

alevelsurface;refertoRemovingtheBatteryinthe

Operator’sManual.

Important:Neverllthebatterywith

electrolytewhilethebatteryisinstalledinthe

tractor.Youcouldspillelectrolyteonotherparts

andcausecorrosion.

2.Cleanthetopofthebatterywithapapertowel.

3.Removetheventcapsfromthebattery(Figure10).

Figure10

1.Ventcaps3.Lowerline

2.Upperline

4.Slowlypourelectrolyteintoeachbatterycelluntil

theelectrolytelevelisuptotheupperlineonthe

batterycase(Figure10).

Important:Donotoverllthebatterybecause

electrolyte(sulfuricacid)canseverelycorrode

anddamagethechassis.

5.Wait5to10minutesafterllingthebatterycells,

thenaddelectrolyte,ifnecessary,untiltheelectrolyte

levelisuptotheupperline(Figure10)onthebattery

case.

6.Installthebatteryventcaps.

7.Chargethebatteryfor1hourat25to30ampsor

6hoursat4to6amps.Donotoverchargethe

battery.

Chargingthebatteryproducesgassesthatcan

explode.

Neversmokenearthebatteryandkeepsparks

andamesawayfrombattery.

8.Whenthebatteryisfullycharged,unplugthecharger

fromtheelectricaloutlet,thendisconnectthe

chargerleadsfromthebatteryposts(Figure11).

Figure11

1.Positivepost3.Chargerred(+)wire

2.Negativepost4.Chargerblack(–)wire

9.Installthebatteryinthetractorandconnectthe

batterycables;refertoInstallingtheBatteryinthe

Operator’sManual.

CheckingtheEngineOilLevel

NoPartsRequired

Procedure

Beforeyoustarttheengineandusethetractor,check

theoillevelintheenginecrankcase;refertoChecking

theOilLevelintheOperator’sManual.

FillingtheFuelTank

NoPartsRequired

Procedure

Addfueltothefueltank;refertoFillingtheFuelTank

intheOperator’sManual.

CheckingtheTirePressure

NoPartsRequired

Procedure

Checkthefrontandreartiresforproperination;refer

toCheckingtheTirePressureintheOperator’sManual.

TestingtheSafetySystem

NoPartsRequired

Procedure

Testthesafetyinterlocksystem;refertoTheSafety

InterlockSystemintheOperator’sManual.

ReadingtheManual

Partsneededforthisprocedure:

2Operator’sManuals(EnglishandFrench)

1Engineoperator’smanual

2Keys

1Sparkplugwrench

1Oildraintube

1Recycler®cover

Procedure

•ReadtheOperator’sManual.

•Readtheengineowner’smanual.

•Usetheignitionkeytostarttheengineandthe

KeyChoicekeytooperatethemowerinreverse

(refertotheOperator’sManual).

•Usethesparkplugwrenchtoservicethesparkplug

(refertotheOperator’sManual).

•Usetheoildraintubewhenyouchangetheengine

oil(refertotheOperator’sManual).

•UsetheRecyclercoverwhenrecyclingthegrass

clippings(refertotheOperator’sManual).
