Topaz 16C/ 16CX

Rigging Instructions

Topaz16C Topaz16CX

TOPAZ 16C/ 16CX

RIGGING INSTRUCTIONS

INDEX

02. Introduction

02. Manufacturers Details

Rigging Instructions

03. BEAMS

03. TRAMPOLINE

04. LACING THE TRAMPOLINE

05. ATTACHING TRAMPOLINE

06. JIB BLOC S

06/ 07/ 08. MAST

08. TRAPEZE

08. DOWNHAUL/ IC ER SYSTEM

08/ 09/ 10/ 11. SPINNA ER

11/ 12. JIB

13. MAINSAIL

13. MAINSHEET

13. CAPSIZE LINE

INTRODUCTION

These RIGGING INSTRUCTIONS have been compiled

to help you to rig your TOPAZ 16C/ 16CX.

Please also ensure that you refer to your TOPAZ

OWNERS MANUAL. The OWNERS MANUAL has

been compiled to help you to operate your craft with

safety and enjoyment. It contains details of the craft, the

equipment supplied or fitted, it’s systems and information

on its operation and maintenance.

Please read it carefully and familiarise yourself with the

craft before using it.

If this is your first craft, or you are changing to a type

of craft you are not familiar with, for your own comfort

and safety, please ensure that you obtain handling and

operating experience before assuming command of the

craft. Your dealer or national sailing federation or yacht

club will be pleased to advise you of local sailing schools,

or competent instructors.

PLEASE EEP THE RIGGING INSTRUCTIONS and

THE OWNERS MANUAL IN A SECURE PLACE AND

HAND THEM OVER TO THE NEW OWNER WHEN YOU

SELL THE CRAFT.

MANUFACTURER DETAILS

For further information, spares and accessories,

please contact the manufacturer:

TOPPER INTERNATIONAL LTD,

ingsnorth Technology Park,

Wotton Road, Ashford, ent TN23 6LN

Telephone +44 (0) 1233 629186

Fax +44 (0) 1233 645897

email [email protected]

TOPAZ 16

RIGGING INSTRUCTIONS

TOPAZ 16

TOOLS REQUIRED

In order to rig the Topaz 16, it is advisable to have your

tool kit to hand You will need a flathead screwdriver, a

phillips screwdriver, a pair of plyers and a socket set.

TOPAZ16

TOPAZ 16

RIGGING INSTRUCTIONS

BEAMS

Lay the two hulls into the launching trolley cups bow first. This

will hold the hulls in the correct position to connect to the main

and rear beam.

8x lock nuts, washers and 8mm x 15mm s/s bolts are supplied.

You wll require assisstance to bolt the beams into the hulls. The

main beam has a ball deck step and is shaped to fit snugly into

the front socket of the hulls. The rear beam is smaller with a

traveller attached and a row of small plastic wheels along it’s

length. Again this is shaped to fit perfectly into the rear beam

sockets with the white plastic wheels facing aft.

Feed the bolts into

the holes in the hulls

going through the

washer and then

attach lock nut and

tighten.

Attach the main beam

first followed by the

rear beam.

TRAMPOLINE

A. Remove the beam end cap from the main beam.

B. Remove slugs from front beam.

C. Ensure that the 5mm glass tube is inserted into the sleeve

that runs along the front of the trampoline.

Insert 5mm glass tube and trampoline into the main beam.

Then slide across the length of the beam until the trampoline is

positioned centrally.

D. Re-insert slugs to the right and left of the trampoline

to hold it in position.

E. Re-affix beam end caps to secure trampoline in position.

LACING THE TRAMPOLINE

A. Insert 10mm glass rod into rear of trampoline.

B. Tie loop on end of trampoline lacing line using a bowline knot.

C. Then slide the loop on the lacing line over the end of the

10mm glass fibre rod. You can then begin to lace the trampoline

onto the rear beam.

D. Then (1) feed line under rear beam, (2) over the top of the 1st

nylon wheel, (3) on to next wheel, (4) over the top of 2nd wheel,

(5) Then forward under the beam, (6) and down through the eye

in the rear of the trampoline around the 10mm rod, (7) then back

under beam...

E. ... (8) over the top of the 2nd wheel and (9) on to 3rd wheel.

Then continue lacing process until you reach the final nylon

wheel on the end of the rear beam.

F. Once at the end of the beam. Go back to first loop and tight-

en the section between the first wheel and the second. Then

tighten the loop between the second and third and so on.

G. With the tail of the rope, feed under beam, (10) loop it over

the far end of the 10mm glass fibre rod and then (11) back

under the beam.

H. (12) Round the last nylon wheel and (13) tie off between the

last wheel and the last but one.

NOTE; THE TRAMPOLINE LACING WILL NEED TO BE RE-

TIGHTENED FROM TIME TO TIME TO ENSURE THAT THE

TRAMPOLINE REMAINS TAUT.

ATTACH TRAMPOLINE TO FRONT BEAM

A. Tie the front end of trampoline onto slug on front beam.

B. Pull tight, so end pulley wheel is tight in the back end of

the trampoline.

C. Tie off to slug using a half hitch with a knot against it to

stop it slipping.

Repeat this on the opposite side.

ATTACH TRAMPOLINE TO REAR BEAM

A. (1) Attach trampoline tensioning lines to the deck eye on

rear beam.

B. (2) Feed forward & through pulley wheel at rear of trampoline.

C. (3) Back through deck eye. Tension as tight as possible.

Then repeat process, this time through the stainless steel ring

fixed to the back of the trampoline (4-5).

(6) Back through deck eye. Again, tension as tight as possible.

Tie off with a round turn and two half hitches.

Then repeat on opposite side. Ensure trampoline is as taut as

possible to ensure a firm platform.

TIGHTEN CENTRE OF TRAMPOLINE

A. Tighten centre of trampoline by (1) feeding rope through

deck eye left-to-right, then (2) up to and through right trampoline

eyelet, (3) through left eyelet and back down (4) through deck eye

(left to right).

B. (5-6) Then feed right hand tail up through right trampoline

eyelet and left hand tail up through left trampoline eyelet, tighten

and tie off with a reef knot.

C. Tidy tail ends by tucking back down through eyelets.

JIB BLOCKS

The jib block set includes (1) 2x rubber boots, (2) 2x jib blocks

and (3) a shackle.

A. To attach the two jib blocks to main beam, firstly, turn rubber

boot inside out. Then, Place over bottom of jib block.

B. Attach shackle to left eye (4) on the front beam.

C. Tighten shackle.

D. Fold rubber boot back over the eye.

E. Repeat, to attach second jib block to the right eye on the

front beam.

MAST

Lay mast section along centre of boat with the top of the mast

pointing towards the back of the boat.

A. Attach the rigging to the mast using the large bow shackle (1).

The rigging includes;

1x set of shrouds (coated in white plastic)

2x trapeze wires

1x forestay (metal ring and pulley).

B. Attach bow shackle including rigging to crane fitting (2)

located on the front of the mast section. It is important to tighten

this shackle.

Then you need to tidy the rigging lines in readiness for erecting

the mast.

1 + 2

MAST c ntinued

C. Attach the shroud wires (coated in white plastic) onto the

chain plates on either side of the boat (3) Use the third hole from

the bottom of the chain plates. (4) Then secure chain plates to

the hull as shown.

D. Lay trapeze wires to either side of the mast, so that they are

roughly in the correct position ready to be attached once the

mast is upright.

E. Next is the jib halyard, the jib halyard comes in two parts (5).

Ensure one section is fed through ring (6) and small pulley (7)

on forestay.

F. Then feed end of spinnaker halyard through the small pulley at

the top of the mast (8).

G. Take spinnaker halyard to foot of mast tying ends together to

create a loop.

H. Position mast so that the foot of the mast is on the ball joint

on the front beam and secure in place with pin.

E. Attach striker bar (9) (front cross bar) between the hulls at front

of boat.

EN URE THAT THE

TERN OF THE BOAT I

FACING INTO THE WIND.

ENSURE THAT THE

MAST IS CLEAR OF

ANY OVERHEAD

CABLES OR

OBSTRUCTIONS!

Re-tidy all of the rigging.

You are now ready to

raise the mast. This is a

two person job.

E. Person One (1) should

be positioned towards

the front of the boat

holding the trapeze wires.

Person Two (2) should

support the top of the

mast behind the boat

and then walk mast

forward until it is upright.

MAST c ntinued

F. Once mast is vertical, person 2 can remove the pin from the

ball joint allowing the mast to rotate freely.

G. Person 2 should then securely but loosely attach forestay to

striker bar shackle. You can then remove the mast lock pin.

H. Now tighten forestay and re-attach to striker bar shackle.

TRAPEZE

A. Attach shock cord and

rope with adjustement

stop to trapeze handle.

And feed through trapeze

wire eye (1). Then take

other end of cord. Feed

under line to other side of boat.

Up through trapeze wire

eyelet and handle as

before.

DOWNHAUL/

KICKER SYSTEM

You can now attach the

downhaul system to the

foot of the mast.

SPINNAKER KIT

A. Feed (2) spinnaker sock into (3) chute mouth groove.

Feed around ring. Note, this is a snug fit.

SPINNAKER KIT c ntinued

B. You are now ready to attach the spinnaker sock and pole to

the boat.

Ensure sock is fed over the striker bar.

Attach velcro straps around spinnaker pole.

C. Then attach back of spinnaker sock around either side of the

base of the mast.

(4) One line attaches to the mast foot. (5) The second line at-

taches through loop on front of trampoline (next to the capsize

line pocket).

D. Tie loop (6) in spinnaker pole bridle rope, (7) feed through eye

on front hull by main bridle. (8) Take rope back through loop and

then (9) tie off on eye. Repeat on other side and pull tight till there

is a slight bend in the spinnaker pole.

E. (1) Take line from the chute mouth and (2) tie off on to the eye

on the front of the hull.

SPINNAKER HALYARD

A. To secure one end of the spinnaker halyard, tie to bridle

for time being.

B. Take other end of spinnaker halyard down mast and through

pulley on back of spinnaker pole running from back of boat

forwards.

Remove the rope that is securing the double block to the

spinnaker pole (this is for shipping purposes only).

SPINNAKER HALYARD continued

C. (1) Feed spinnaker halyard forward and (2) through double

block and then (3) back to double cleat on front crossbeam aside

mast foot.

D. Attach ring on shockcord through back/ centre of trampoline

and tie off on eyelet on back of rear crossbeam/ centre.

E. Feed spinnaker halyard (4) back along trampoline, through

steel ring.

F. Then forward (5) to the guide pulley (6) on trampoline front

(by capsize line pocket).

G. (7) Then feed spinnaker halyard into back of spinnaker sock.

H. (8) Feed end of spinnaker halyard through the spinnaker chute

until the tail comes out the front of the chute. (Tip; it is easier to

do this by fishing the spinnaker halyard out of the chute with a

tiller arm or similar long object in order to feed it from the back of

the chute to the front).

SPINNAKER SAIL

A. To attach spinnaker, tie (T) tack line (attached to spinnaker

pole block) to ‘Tack’ of spinnaker sail with a bowline.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Bote de Topper

Topper

Topper TOPAZ XENON Guía de inicio rápido

Topper

Topper Topaz UNO PLUS Guía de inicio rápido

Topper

Topper TOPAZ XENON XK1 Manual de usuario

Topper

Topper TOPAZ TRES Manual de usuario

Topper

Topper Topaz UNO PLUS Manual de usuario

Topper

Topper TOPAZ TAZ RACE PLUS Manual de usuario

Topper

Topper topaz 14C Guía de inicio rápido

Topper

Topper Topper Manual de usuario

Topper

Topper TOPAZ OMEGA Guía de inicio rápido

Topper

Topper TOPAZ TRES Guía de inicio rápido

Topper

Topper TOPAZ ARGO Guía de inicio rápido

Topper

Topper TOPAZ VIBE Guía de inicio rápido

Manuales populares de Bote de otras marcas

Raymarine

Raymarine ST70 Instrument Manual de usuario

Pro-Line Boats

Pro-Line Boats Pro Line 19 Sport Manual de usuario

Jeanneau

Jeanneau CAP CAMARAT 8.5 CC Manual de usuario

Tiara Yachts

Tiara Yachts C49 2024 Manual de usuario

Monterey Boats

Monterey Boats Sport Yacht 330 Manual de usuario

J 105 Manual de usuario

PURSUIT

PURSUIT OS 335 Manual de usuario

Boston Whaler

Boston Whaler CONQUEST 345 Manual de usuario

Jeanneau

Jeanneau SUN ODYSSEY 41 DS Manual de usuario

Meridian

Meridian 490 Pilothouse Manual de usuario

Advanced Elements

Advanced Elements AdvancedFrame Expedition AE1009 Manual de usuario

Robo Marine Indonesia

Robo Marine Indonesia GEOMAR Manual de usuario

Swallow Boats

Swallow Boats BayRaider Manual de usuario

Intex

Intex Excursion 5 Set Manual de usuario

X SHORE

X SHORE EELEX 8000 Manual de usuario

ISLAND PACKET

ISLAND PACKET 370 Manual de usuario

Sea Ray

Sea Ray 175 Sport Manual de usuario

Regal

Regal 2300 Manual de usuario
