GemView 16 Tablet Display User Manual
Table of Contents
Compliant Information ............................................................................................................ 3
Important Safety Instructions................................................................................................. 4
Declaration of RoHS2 Compliance......................................................................................... 5
Copyright Information............................................................................................................. 6
Introduction.............................................................................................................................. 7
Packing List............................................................................................................................ 7
Product Overview................................................................................................................... 8
Front and Side View ..................................8
Rear View....................................................8
Interactive Electromagnetic Pen..............8
Installation................................................................................................................................ 8
Connect Tablet Display to PC................................................................................................ 8
Connect Pen to Tablet Display............................................................................................... 8
Install DisplayLink Driver........................................................................................................ 9
Configure Tablet Display for Installation................................................................................. 9
Install GemView Tablet Display Driver................................................................................. 10
Configure Tablet Display for Pen Input................................................................................. 11
Install Bundled Topaz Software............................................................................................ 13
Mounting Information............................................................................................................ 13
Troubleshooting .................................................................................................................... 14
Screen Problems.................................................................................................................. 14
Product Specification............................................................................................................ 15
Screen.................................................................................................................................. 15
Interactive Electromagnetic Pen........................................................................................... 16
Appendix................................................................................................................................ 17
Replace the Pen Tip............................................................................................................. 17
3 www.topazsystems.com Back to Top
GemView 16 Tablet Display User Manual
Compliant Information
This device complies with part 15 of FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy, and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
CE Conformity for European Countries:
The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive
2006/95/EC.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and Electronic
Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT
to dispose the equipment as unsorted municipal waste, but use the return and
collection systems according to local law.
If the batteries, accumulators and button cells included with this equipment, display
the chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal
content of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than
0.004% Lead.
4 www.topazsystems.com Back to Top
GemView 16 Tablet Display User Manual
Important Safety Instructions
1. DO NOT place objects on top of the device, as objects may scratch the screen.
2. DO NOT expose the device to dirty or dusty environments.
3. DO NOT place the device on an uneven or unstable surface.
4. DO NOT insert any foreign objects into the device.
5. DO NOT expose the device to strong magnetic or electrical field.
6. DO NOT expose the device to direct sunlight as it can damage the LCD Screen. Keep it
away from heat sources.
7. DO NOT use the device in the rain.
8. Please check with your Local Authority or retailer for proper disposal of electronic
products.
9. The device may produce some heat during normal operation or charging. To prevent
discomfort or injury from heat exposure, DO NOT leave the device on your lap.
10.POWER INPUT RATING: Refer to the rating label on the device. Only use accessories
specified by the manufacturer.
11. DO NOT use any sharp object to tap the screen.
12.Clean the touch screen with a soft cloth. If needed, dampen the cloth slightly before
cleaning. Never use abrasives or cleaning solutions.
13.Disconnect the device from an electrical outlet and power off before cleaning the device.
14.DO NOT disassemble the device. Only a certified service technician should perform
repair.
15.Users have to use the connection to USB interfaces with USB 2.0 version or higher.
5 www.topazsystems.com Back to Top
GemView 16 Tablet Display User Manual
Declaration of RoHS2 Compliance
This product has been designed and manufactured in compliance with Directive 2011/65/EU of
the European Parliament and the Council on restriction of the use of certain hazardous
substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply
with the maximum concentration values issued by the European Technical Adaptation
Committee (TAC) as shown below:
Substance
Proposed Maximum
Concentration
Actual
Concentration
Lead (Pb)
0.1%
< 0.1%
Mercury (Hg)
0.1%
< 0.1%
Cadmium (Cd)
0.01%
< 0.01%
Hexavalent Chromium (Cr6+)
0.1%
< 0.1%
Polybrominated biphenyls (PBB)
0.1%
< 0.1%
Polybrominated diphenyl ethers
(PBDE)
0.1%
< 0.1%
Certain components of products as stated above are exempted under the Annex III of the
RoHS2 Directives as noted below: Examples of exempted components are:
1. Mercury in cold cathode fluorescent lamps and external electrode fluorescent lamps
(CCFL and EEFL) for special purposes not exceeding (per lamp):
(1) Short length (≦500 mm): maximum 3.5 mg per lamp.
(2) Medium length (＞500 mm and ≦1,500 mm): maximum 5 mg per lamp.
(3) Long length (＞1,500 mm): maximum 13 mg per lamp.
2. Lead in glass of cathode ray tubes.
3. Lead in glass of fluorescent tubes not exceeding 0.2% by weight.
4. Lead as an alloying element in aluminum containing up to 0.4% lead by weight.
5. Copper alloy containing up to 4% lead by weight.
6. Lead in high melting temperature type solders (i.e. lead-based alloys containing 85% by
weight or more lead).
7. Electrical and electronic components containing lead in a glass or ceramic other than
dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or ceramic
matrix compound.
6 www.topazsystems.com Back to Top
GemView 16 Tablet Display User Manual
Copyright Information
Disclaimer: Topaz Systems, Inc. shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential damages resulting from
furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, Topaz Systems, Inc. reserves the
right to change product specifications without notice. Information in this document may
change without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for
any purpose without prior written permission from Topaz Systems, Inc.
7 www.topazsystems.com Back to Top
GemView 16 Tablet Display User Manual
Introduction
Packing List
The following items are included with your GemView 16 Tablet Display:
•Tablet display
•Tablet display kickstand
•Power adapter
•USB 2.0 Y cable
•Electromagnetic pen
•Pen tether
•3 pen tips
•Pen tip replacement tool
•Installation instructions
8 www.topazsystems.com Back to Top
GemView 16 Tablet Display User Manual
Product Overview
Front and Side View
1. Display & electromagnetic pen touch area
2. Pen holder
3. Power button
4. Brightness adjustment button (increase)
5. Brightness adjustment button (decrease)
6. Ergonomic support (multi-angle kickstand)
Rear View
7. Pen slot
8. Tether hole
9. Lock hole (x2)
10.USB connector
11.Power connector
Note: Please don't open the enclosure; contact
service personnel for any problem.
Interactive Electromagnetic Pen
The interactive electromagnetic pen is made with electromagnetic resonance technology and
does not require batteries.
8 www.topazsystems.com Back to Top
GemView 16 Tablet Display User Manual
Installation
Connect Tablet Display to PC
To begin, follow the steps listed below to connect your GemView Tablet Display:
1. Connect the tablet display to the PC using the USB cable, as shown below.
2. Connect the tablet display to a power source using the power adapter, as shown below,
and push the power button to turn on the tablet display.
Note: Connect both USB connectors at one end of the cable to the PC, to ensure a stable
power supply. Due to the manner that Windows enumerates USB devices and the use of
internal USB hubs in some PCs, it may be necessary to change the ports into which the USB
connectors are inserted.
Connect Pen to Tablet Display
If your pen is not already connected to the tablet display, follow these instructions:
1. Loop one end of the pen tether through the eye at the end of the pen.
2. Loop the other end of the pen tether through the tether hole on either side of
the device.
9 www.topazsystems.com Back to Top
GemView 16 Tablet Display User Manual
Install DisplayLink Driver
Download and run the DisplayLink installer for use on Windows clients from the Topaz
website: www.topazsystems.com/software.html?tab=gemview-software-tab.
For silent installation, use the command -silent. For more information, view:
https://support.displaylink.com/knowledgebase/articles/544789-installation-switches-
for-installing-displaylink-s.
Configure Tablet Display for Installation
Use the Display program in the control panel to configure the tablet display for your installation
(see screenshot below). You may specify the following characteristics:
1. Resolution: Use the recommended resolution
2. Orientation: Landscape or portrait
3. Multiple displays: Extend these displays
4. Alignment: Make sure that the bottoms of the monitors are aligned as shown below,
and that the tablet display (Display 2) is on the side of the main display you want to use
when moving windows from the main display (Display 1).
After configuring the tablet display, you may test it as follows:
1. Click the identify button; the number 1 should appear on the main display and the
number 2 should appear on the tablet display.
2. Move your mouse from the main display to the tablet display; it should track properly.
