Thank you for choosing TOP VME .
TGP58Series
Printer
Installation Guide
Contents
1. Introduction……………………………………………………………………………………………………… 1
1-1. Overview………………………………………………………………………………………………………… 1
1-2. Features ………………………………………………………………………………………………………… 1
2. Specification …………………………………………………………………………………………………… 2
2-1. General …………………………………………………………………………………………………… 2
2-2. Cutter …………………………………………………………………………………………………………… 2
2-3. Thermal Print head ……………………………………………………………………………………… 2
3. Dimension ……………………………………………………………………………………………………… 3
3-1. TGP58 Dimension ………………………………………………………………………………………… 3
3-2. TGP58-L Dimension……………………………………………………………………………………… 4
4. The hardware setup………………………………………………………………………………………… 5
4-1. Connection Setting ……………………………………………………………………………………… 5
4-2. LED and DIP Switch Setting ………………………………………………………………………… 6
4-3. Setting Step ………………………………………………………………………………………………… 7
5. Battery setup …………………………………………………………………………………………………… 8
6. Roll Installation Guide……………………………………………………………………………………… 8
7. RS232 Command Format ……………………………………………………………………………… 9
7-1. Reading the date and time…………………………………………………………………………… 9
7-2. Setting the date and time Command ………………………………………………………… 9
7-3. Upload trademark graphic formats …………………………………………………………… 9
7-4. Typeset print function ………………………………………………………………………………… 9
7-5. NO / NC choose…………………………………………………………………………………………… 11
7-6. Upload text …………………………………………………………………………………………………… 11
7-7. Clear diary …………………………………………………………………………………………………… 11
7-8. Cut the paper ……………………………………………………………………………………………… 11
7-9. Direct Print format graphics ………………………………………………………………………… 11
7-10. Print format text directly ……………………………………………………………………………12
7-11. Print Score Reports ………………………………………………………………………………………12
7-12. Print diary ……………………………………………………………………………………………………13
7-13. Back to the software version ………………………………………………………………………13
7-14. Read machine status……………………………………………………………………………………13
Contents
1
Printer
1
1. Introduction
1-1. Overview
TGP58 system with built-in clock, local time can be set before shipment, mark
the time on the printed document.
Provide users with one-day and summary reports, free to choose to delete,
the document has a typesetting function, users can easily download or
design document formats, trademarks, etc.The document format is stored
via TGP58 for future use.
1-2. Features
•Easy grasp data
•Recode data quickly and securely
•Query and print easily
TGP58 Series
2
2. Specification
2-1. General
Power Source 12V DC (10.8~13.2V DC)
Input/Output level HI : 12V LO : 0V DC
Roll Width 56 ± 0.5 mm
Installation Indoor
Power Consumption
TGP58
Standby：0.12A / 1.44W
Operation：2.1A / 25.2W
Maximum：2.5A / 30W
TGP58-L
Standby：0.23A / 2.76W
Operation： 2.22A / 26.64W
Maximum：2.61A / 31.32W
Weight Approx. 700g(without roll)
Temperature Range
Operation Temperature :
0° C~60° C
Storage Temperature :
-10° C~80° C
Humidity :
20%~70%RH(no condensation)
2-2. Cutter
Thickness Maximum0.12mm
Life Up to about 500,000 times
Time Fastest 1 time/ seconds
2-3. Thermal Print head
Life 30 km
Resolution 8 Ponints / mm
Speed 40 mm / sec
3
Printer
3
3. Dimension
3-1. TGP58 Dimension
Unit : mm [ inch ]
TGP58 Series
4
Unit : mm [ inch ]
3-2. TGP58-L Dimension
120.20
4.732
70.20 2.764
22.60 0.890 95.00 3.740
140.20
5.520
82.00 3.228
12.00 0.472
151.30
5.957
7.70
0.303
129.20
5.087
19.30 0.760
84.10 3.311
75.20 2.961
6.30
0.248
5
Printer
5
4. The hardware setup
4-1. Connection Setting
Please read the table below for information on connectors :
CN1 Serial Interface
PIN 1- GND PIN 5- RESET
PIN 2- X PIN 6- VCC (+5V DC)
PIN 3- PGD PIN 7- RX
PIN 4- PGC PIN 8- TX
PULSE MODE
PIN LINE COLOR FEATURES SIGNAL I/O
1 Red +12V DC
2 Black GND
3 Brown Coin PULSE I
4 Orange Note PULSE I
5 Yellow Payout PULSE I
6 Green NC
7 Blue Error Low active O
HOPPER MODE
PIN LINE COLOR FEATURES SIGNAL I/O
1 Red +12V DC
2 Black GND
3 Brown Coin PULSE I
4 Orange Note PULSE I
5 Yellow HOPPER SSR Low active I
6 Green HOPPER SW PULSE O
7 Blue Error Low active O
TGP58 Series
6
4-2. LED and DIP Switch Setting
A.Bezel LED：Normal - LED light，Error - LED is off
B. Status light：Normal : LED is green ; Error : LED is red .
LED
TGP58 TGP58-L
LED
