Contents
TI6VG4 User’s Manual iii
Contents
Chapter 1 Introduction....................................................1
Chapter 2 Specifications..................................................3
Chapter 3 Hardware Description ...................................5
3.1 Processor ...................................................................................7
3.2 L2 Cache ...................................................................................7
3.3 Main Memory............................................................................7
3.4 BIOS..........................................................................................9
3.5 Onboard AGP Slot.....................................................................9
3.6 Hardware Monitoring................................................................9
3.7 Multi-I/O ...................................................................................9
3.8 Interrupt Request (IRQ) Lines.................................................10
3.9 Onboard PCI-IDE....................................................................10
3.10 DMA Channels......................................................................10
3.11 I/O Port Address Map............................................................11
3.12 Onboard Audio......................................................................11
3.13 AMR Slot ..............................................................................11
Chapter 4 Configuring the Motherboard ....................13
4.1 CPU Frequency Setting ...........................................................15
4.2 JP4, JP5: Force Clock Select...................................................15
4.3 JP6: Onboard Audio and AMR Slot Setting ...........................16
4.4 JP9: Clear CMOS Select .........................................................16
Chapter 5 Installation....................................................17
5.1 I/O Connectors ........................................................................19
5.2 J1: PS/2 Keyboard and PS/2 Mouse Connectors.....................19
5.3 J2: ATX Power Supply Connector..........................................20
5.4 J5: Floppy Drive Connector ....................................................20
5.5 IDE1, IDE2: EIDE Connectors...............................................21
5.6 J3, J6: Serial Ports...................................................................23
5.7 J4: Parallel Port Connector......................................................23
5.8 J10, J7, J8, J9: Game Port, Mic In/Line In/Line Out...............24
5.9 J12, J13, J14: CD In and Auxiliary In Connectors.................24
5.10 FAN1, FAN2, FAN3: Fan Power Connectors.......................24
5.11 J16: IrDA Connector .............................................................25
5.12 USB1, J18: USB Connectors.................................................25
