Tissot E09 Manual de usuario

E09 - Chinese Big Date

User’s Manual

TISSOT

1853

www.tissot.ch 159_EN / 10.15

1/3

Displays and functions

➊

Hour hand

➋

Minute hand

➌

Digital display (with push-button)

➍

Push-button

Conditions for push-button use (4):

Single press

Multiple presses

2-second press

5-second press

10-second press

Display time in seconds

Time taken to exit the function

2”

10”

5”

1”

E09 - Chinese Big Date

www.tissot.ch

159_EN / 10.15

2/3

List of settings

Principle of setting mode

Acknowledgements

Thank you for choosing a watch from TISSOT®, a Swiss brand among

the most highly renowned in the world. Meticulously assembled using

high quality materials and components, it is protected against impacts,

temperature variations, water and dust.

This watch is equipped with a perpetual calendar. This means that the

month lengths and the leap years are calculated automatically.

To ensure that your watch operates with perfect precision for many years

to come, we advise you to pay careful attention to the advice given in

this manual.

Gregorian and Chinese calendars

This model displays the date according to both the Gregorian and Chinese calendars.

Consulting the date

Access setting mode

Hour setting (see p. 3)

Minute setting

Seconds setting*

Year setting**

Month setting**

Day of the week setting**

Synchronisation mode (see p. 3)

* When setting the seconds, the watch exits setting mode after

60 seconds. Within this interval, it is possible to press the push-button

to reset the “seconds count” back to zero.

** This information is used for managing the date in the perpetual calendar.

The calendar is set using the Gregorian calendar.

TISSOT

1853

5”

2”

10”

5”

Activate setting mode

Enter setting mode

See the list of settings

Activate editing

(the display will flash)

Set the value

Switch to the next setting after

three seconds then exit setting

mode

TISSOT

1853

TISSOT

1853

TISSOT

1853

TISSOT

1853

TISSOT

1853

TISSOT

1853

TISSOT

1853

5” 5”

5”

Chinese CalendarGregorian Calendar

E09 - Chinese Big Date

www.tissot.ch

159_EN / 10.15

3/3

Care and maintenance

We would advise you to clean your watch regularly (except for the leather

strap) using a soft cloth and lukewarm soapy water. After immersion in

salt water, rinse it in fresh water and leave it to dry completely.

Do not leave it anywhere where it might be subjected to major variations

in temperature or humidity, direct sunlight or strong magnetic fields.

We recommend you have your watch inspected every 3 to 4 years by a

TISSOT®approved service centre. To enjoy impeccable maintenance ser-

vice and ensure the guarantee remains valid, always consult a TISSOT®

approved service centre.

TISSOT®quartz watches have the incomparable precision of quartz.

Their power reserve is usually more than 2 years in continuous use

(depending on how often the watch functions are used).

Replacing the battery

When the battery reaches its End Of Life (EOL), the display blinks when

switched on, and is less bright.

Once the battery has been fully drained (EOE), the watch automatically

switches to energy saving mode.

Once the battery has been drained, it must be replaced without delay by

a TISSOT®approved service centre. Battery type: Lithium CR2032 button

cell.

Collection and treatment of end of life quartz watches*

This symbol indicates that this product should not be disposed with

household waste. It has to be returned to a local authorized col-

lection system. By following this procedure you will contribute to

the protection of the environment and human health. The recycling of the

materials will help to conserve natural resources.

* valid in the EU member states and in any countries with corresponding

legislation.

Apply the same principle to all settings.

Hour setting

Quick summer time / winter time switch

Synchronisation

Apply this procedure if the hands are not showing the same time as the

digital display, or they are not at 12:00 in setting mode.

TISSOT

1853

TISSOT

1853

5”

2”

TISSOT

1853

TISSOT

1853

5”

10”

5”

TISSOT

1853

TISSOT

1853

TISSOT

1853

TISSOT

1853

5”

10”

2”

TISSOT

1853

TISSOT

1853

TISSOT

1853

TISSOT

1853

10”

5”
