Thuraya XT-LITE Manual de usuario

XT-LITE satellite phone

USER GUIDE

THURAYA {()

ENGLISH

DELITSCH

ESPAfilOL

ITALIANO

PORTUGU

PYCCKlllLil

Certification/Compliance/Waminty

Limitation of Liability

Parts Description Overview of the Home Screen

13.

14.

3. 6. 15.

4. 7. 9.

10.

11. 12.

1. Satellite antenna

2. Receiver

Left soft key

Call key

5. Alphanumeric keypad

Navigationkeys

Selection key

Microphone

Right soft key

10.

End key

11.

USB/Datacablejack

12.

Chargerjack

13. Earphonejack

(Earphones are

available as an

optional accessory)

14. Battery release

15.

SIMcardholder

Satellite signal

Weak signal. Point

satellite.

Roaming

Active call

Mute

Ciphering (call

Receiving GPS-fix

Earphoneconnected

Status bar

Network information

Unread SMS

Voice mail

Voice mail + SMS

SMS inbox full

Silent

Schedule reminder

Alarm

Call divert

Available soft key

functions

Getting Started

Inserting the SIM card

Make sure to insert the SIM card in the

shown direction before inserting the

battery.

Inserting the battery

Insert the battery from the bottom end

first. Then push down the top end until

you hear it click in place.

Charging the battery

Open the cover at the bottom of the

phone and firmly connect the charger to

the charger jack.

Network connection

When the XT-LITE is powered on, the

phone will search for the network and

acquire location information. If the SAT

and location icons are lashing, the phone

is yet to receive the location information

and you will be able to make a call

or send a message once the lashing

stops. Upon successful registration to

the network, the phone will display the

country and the signal strength.

Calls

Making a call

To make a call, enter a phone number

using the keypad or choose a saved

contact and then press the Call key.

Receiving a call

To receive a call, press the Call key or

any key on the keypad.

During a call

During a call, you can mute the call or put

the call on hold from the Options menu.

Swapping calls

While receiving an incoming call during

an already active call, select Swap. This

will allow you to connect with up to 6

users.

Conference calls

1During an active call, go to Options >

New call. The first call is automatically

put on hold.

2Call the other user’s phone number.

3To add the first user into the

conference call, go to Options >

Multiparty.

You can include up to 6 users in the

conference call by repeating steps

1 to 3.

Note

During a conference call, you may

choose to speak with a user in private.

Select the user and go to Options >

Private, and then all other calls are put

on hold automatically.

Messaging Features

Sending messages

1Go to Menu > Messages > New

message.

2Enter the message.

3Add the phone numbers of the

recipient(s).

4Select Options > Send.

Tips

Press the key for symbol entry, the

# key for switching between number

and text, and Options > AutoText for

predictive text entry.

SMS to email

While writing a message, you can change

the sending format to email.

1Select Options > Sending options >

Format > SMS to email.

2Select Options > Send > enter an

email address > OK > enter an email

center number > Send.

Navigation

•

Find your current coordinates

•

Enter waypoints to navigate to a

specific position with the electronic

compass

•

Geo reporting can be used to send

your coordinates to pre-defined

numbers via SMS. Follow Option A to

send only the coordinates and Option

B to send coordinates plus a user-

defined message (see next page).

Features

Option A

To send only the GPS coordinates (without

user-defined message):

Go to Menu > Navigation > Geo

reporting.

1Enter recipient(s):

•

Enter up to four recipients, one for

each of the empty slots.

•

Select the slot, go to Options >

Add recipient, and choose to input

the number or select from contacts.

2Set the interval:

•

Select any of the four slots and go

to Options > Message intervals.

•

Choose frequency of outgoing

messages (every 3 minutes to

every 2 hours).

Option B

To send a user-defined message along

with the GPS coordinates:

Go to Menu > Navigation > Geo

reporting.

•

Follow steps 1 and 2 from above.

•

Turn on SOS message:

- Select any of the four slots and go

to Options > SOS message > On.

•

Set the SOS message:

- Select any of the four slots. and

go to Options > Setup SOS

message.

- Write the message and press the

Selection key to save.

How to activate and

deactivate Geo reporting:

•

To activate from the home screen,

long press the right soft key .

•

To deactivate while in use, short

press the right soft key .

Organizer

Use the Organizer of your XT-LITE for

a range of convenient features such as

setting alarms, scheduling appointments,

using the built-in calculator, stopwatch

and world time.

Call notification Software Upgrades

Your Thuraya XT-LITE allows you to

receive a notification of an incoming call

even if your satellite signal is too weak to

receive the call itself. This is particularly

useful when the Thuraya XT-LITE is in

your pocket with the antenna stowed, and

only has a weak signal.

1Fully extend the antenna of your

Thuraya XT-LITE.

2Ensure that you have direct line of

sight to the satellite.

3As soon as the signal strength

is strong enough, the warning

disappears from the display. You

can now accept the call as usual by

pressing the Call key.

A software upgrade is only required

if Thuraya releases a newer software

version. Before performing an upgrade

please check your current software

version under Security > S/W version to

see if an upgrade is required.

1Download and install the latest XT-

LITE upgrader file from www.thuraya.

com.

2Download the latest XT-LITE software

from www.thuraya.com.

3Power on your Thuraya XT-LITE with

a fully charged battery.

4Connect the PC and the Thuraya XT-

LITE using the USB cable.

5Double click the XT-LITE upgrader

icon on the desktop and the program

will guide you through the upgrade

process.

How to connect the data cable for a

software upgrade:

Open the cover at the bottom of the

phone and firmly connect the USB cable

to the UDC jack.

Afterwards attach the other side of the

data cable to your PC.
