INSTRUCTIONS FOR BUILT-IN
Cut out the work surface according to the sizes shown in the following drawing.
• Note: Before carving, check that the dimensions indicated correspond to the
dimensions of the product.
• Be sure the thickness of the work surface is at least 1.18inch. Choose a heat-resistant
work surface material.
• The safety distance between the sides of the cooktop and the inner surfaces of the
worktop must be at least 0.12inch.
• For the purposes of installation and use, at least 0.2inch space must be kept around
the cut-out.
VENTILATION AND SAFETY DISTANCES
Make absolutely sure that the following conditions are met for adequate ventilation of the
cooktop and that the supply and exhaust air is not blocked:
• Note: The safety distance between the cooktop and the cabinet or the cooker hood should
be at least 29.93inch
• If the cooktop is installed above an oven, the oven must have its own fan.
• The safety distance between the bottom of cooktop and the oven must be at least 1.97inch
• The installation must comply with all distance regulations and other regulations.
INSTALLING THE COOKTOP
The cooktop must connect to a separate, grounded wire, single phase, AC Only
electrical supply with their own circuit breaker. These appliances must be installed
in accordance with National Electrical Codes, as well as all state, municipal and local
codes. This appliance must be supplied with the proper voltage and frequency and
amperage, which is protected by a properly sized circuit breaker or time delay fuse.
The cable from appliance is equipped with 3-wires:
If 3-Wire Cable from Home Power Supply
IMPORTANT: Use the 3-wire cable from Home Power Supply where local codes
permit a 3-wire connection.
If 4-Wire Cable from Home Power Supply
IMPORTANT: Use the 4-wire cable from Home Power Supply where local codes do
not allow grounding through neutral.
4-Wire Cable from Home Power Supply
