»ANWENDERHINWEISE FÜR FEUCHTEFÜHLER
At regular environmental condition, it is recommended to calibrate the sensor annually to check the compliance with the accuracy
required in the application.
The following conditions can damage the sensor element or lead in long therm
to loss of the specified
accuracy:
•Contamination (e.g. dust / fingerprints)
•Aggressive chemicals
•Ambient conditions (e.g. condensation on measuring element)
Do not touch the sensor
elements!
Re-calibration or exchange of the sensor element are not subject of the general warranty.
»TECHNICAL DATA
Measuring values Humidity, temperature, conductivity
Output switch contact NO contact, max. 250 V / 3,0 A (resistive, floating)
Power supply 15..24 V = (±10%) or 24 V ~ (±10%) SELV
Power consumption max. 2,3 W (24 V =) | max. 4,3 VA (24 V ~)
Output signal range temp
(Scaling analog output)
0..+50 °C (default setting), optionally configurable via Thermokon USEapp
Measuring range humidity 0..100% rH non-condensing
Accuracy temperature ±0,5 K (typ. at 21 °C, within default measuring range)
Accuracy humidity ±2% between 10..90% rH (typ. at 21 °C)
Display LED green – power supply OK; LED red – condensation
Enclosure enclosure USE-L, PC, pure white, cover PC, transparent, with removable cable entry
Protection IP65 according to EN 60529
Cable entry Flextherm M20 for wire Ø=4,5..9 mm incl. seal insert for double cable entry for wire max Ø=6 mm and M25, for
wire max. Ø=7 mm, seal insert
Connection electrical removable plug-in terminal, max. 2,5 mm², sensor wire white 2 m (default), for other lengths please request
Ambient condition 0..+50 °C, max. 85% rH short term condensation
Delivery content 1x syringe with terminal contact fluid, incl. mounting base enclosure USE-L pure white
Configuration Thermokon USEapp, LoRaWAN® Downlink, Jumper
Notes other cable lengths on request
LoRaWAN®
Radio technology LoRaWAN®
LoRaWAN version 1.0.2
Device class Class A
Frequency EU868 (863-870 MHz)
Max. transmission power +14 dBm (25 mW)
Receiver sensitivity -137 dBm
Antenna Internal send- / receiver antenna, external antenna available on request
LoRaWAN Features Over the Air Activation (OTAA), Adaptive Data Rate (ADR)
Data transmission
(configurable)
Configurable transmission interval, factory default value 5 min
»INFORMATION ABOUT LORAWAN SPECIFICATION
The Thermokon LoRaWAN specification can be downloaded from our website.
