Thank you for choosing a quality Thermaltake TR2 1000W

PC Power Supply. We trust that you will find it providing

you with many years of service.

You can always find a Thermaltake TR2 1000W PC Power

Supply that is suitable for all of your modern PC power

needs.

Please take the time in familiarize yourself with the power

supply, its connectors and the contents of this manual

before proceeding with the installation of the power unit.

You will need a Phillips crosshead screwdriver, perhaps

your PC case manual and most certainly your

motherboard manual.

1. Introduction

One AC Input power cord

4 mounting screws

User manual

1000W power

supply unit

2. Components Check

01 02

1000W

170 X 140 mm170 X 140 mm

W0176_TR2_1000W_ _A07102201

>> >>>> >>

TR2 1000W PSU TR2 1000W PSU

ATX12V 2.2 & EPS 12V 2.91 Version

Thermaltake TR2 Power SupplyThermaltake TR2 Power Supply

ATX12V 2.2 & EPS 12V 2.91 Version

3.1.1 Do not pull the AC power cord when the power supply is in

use or else damage to components will result.

3.1.2 Do not store the Power Supply in a high humidity and high

temperature environment.

3.1.3 When using power supply under testing

conditions where the power supply unit is not installed in a

PC with its components, please follow the steps below:

1)Please take a paper clip and untwist it.

2)Make sure the power supply unit is in the "OFF" position.

3)Locate the 20 or 24 pin motherboard connector from the

power supply unit.

4)Plug one side of the paper clip into the green wire hole.

5)Plug the other side of the paper clip into any of the black

wire holes.

6)Turn on the PSU to see if the power supply fans turn on.

3.1.4 High voltages exist in the power supply. Do not open the

power supply case unless you are an authorized service

technician or electrician.

3.1.5 All warrantees and guarantees shall be voided should there

be a failure to comply with any of the warnings and cautions

covered in this manual.

TR2 1000W

3 Installation

3.1 Warnings and Cautions

3.2.1 Disconnect the power cord from your old power supply.

3.2.2 Follow your computer case manual and disassemble the case.

3.2.3 Disconnect all the power connectors from the motherboard

and from the peripheral devices such as case fans, hard drives,

floppy drives. etc.

3.2.4 Remove the existing power supply from your computer case

and replace it with your new Thermaltake TR2 1000W PSU.

3.2.5 Connect the power connectors to the motherboard and

peripheral devices (refer to the rest of this manual to

match the various one-way key-locked connectors to the

motherboard and accessories).

3.2.6 Connect the 6pin or 8pin PCI-E connector to PCI Express

graphic card if you need.

Note: Please read the user manual supplied with your graphic card

for detail usage instructions.

3.2.7 Close the computer case.

3.2.8 Make sure your power supply switch is on "OFF" position,

and connect the supplied power cord to your Thermaltake

TR2 1000W PSU.

3.2 Installation Steps

03 04

170 X 140 mm170 X 140 mm

W0176_TR2_1000W_ _A07102201

>> >>>> >>

TR2 1000W PSU TR2 1000W PSU

ATX12V 2.2 & EPS 12V 2.91 Version

Thermaltake TR2 Power SupplyThermaltake TR2 Power Supply

ATX12V 2.2 & EPS 12V 2.91 Version

PCI-E Connector (6 pin)

Main Power Connector

Voltage

+3.3 V

COM

+5 V

COM

+5 V

COM

PWR_ON

+5 Vsb

+12 V

+3.3 V

Voltage

+3.3 V

-12 V

COM

PS_ON#

COM

N/C

+5 V

COM

Color

Orange

Black

Red

Black

Red

Black

Purple

Yellow

Orange

Color

Orange

Blue

Black

Green

Black

N/C

Red

Black

Color Signal Pin

Yellow

+12V

Yellow +12V 2

Yellow +12V 3

Black COM 4

Black COM 5

Black COM 6

Gray

4.1 Output Specification

4. Product Specification

05 06

PCI-E Connector (8 pin)

Color Signal Pin

Yellow

Black

Black COM

COM

Black

COM

Black

CPU Connector (4+4 pin)

Color Signal Pin

Black

Yellow

COM

Black COM

+12V

Yellow

+12V

170 X 140 mm170 X 140 mm

W0176_TR2_1000W_ _A07102201

>> >>>> >>

TR2 1000W PSU TR2 1000W PSU

ATX12V 2.2 & EPS 12V 2.91 Version

Thermaltake TR2 Power SupplyThermaltake TR2 Power Supply

ATX12V 2.2 & EPS 12V 2.91 Version

0807

Floppy Disk Connector (4pin)

Peripheral Connector (4 pin)

CPU Connector (4 pin)

Color Signal Pin

Black COM 1

Black COM 2

Yellow +12V 3

Yellow +12V 4

Color Signal Pin

Yellow +12V 1

Black COM 2

Red +5VDC 4

Black COM 3

Color Signal Pin

Yellow +12V 4

Black COM 2

Red +5VDC 1

Black COM 3

Yellow +12V 1

Black COM 2

Red +5VDC 3

Black COM 4

Orange

+3.3VDC

Color Signal Pin

Serial ATA Power Connector

8 pin PCI-Eto 6 pin PCI-E Converter

Enable 8pin PCI-E connectorconnect to the graphiccard

that only has 6pinPCI-E socket.

20+4pin Main Power

4+4pin CPU Power

4 pin CPU Power

Peripheral & Floppy

S-ATA

6 pin standard PCI-E

8 pin standard PCI-E

Connector +12V1 +12V2 +12V3 +12V4

W0176 - 1000W PSUW0176 - 1000W PSU

+12V Rail Distribution

170 X 140 mm170 X 140 mm

W0176_TR2_1000W_ _A07102201

>> >>>> >>

TR2 1000W PSU TR2 1000W PSU

ATX12V 2.2 & EPS 12V 2.91 Version

Thermaltake TR2 Power SupplyThermaltake TR2 Power Supply

ATX12V 2.2 & EPS 12V 2.91 Version

1009

Model

W0176

SPECIFICATION

Power

Dimension

Switches

PFC

Cooling System

Efficiency

INPUT

Input Voltage

Input Frequency Range

MTBF

Input Current

Hold-up Time

1000W

140mm(L)x150mm(W)x86mm(H)

ATX Logic on-off additional power rockerswitch

Active PFC (PF >0.9)

120mm ball-bearing Fan

3100 RPM 10%

Typical load of80% at 115V/ 230V input

Typical Load 20ms

115 VAC- 230 VAC

47 ~ 63 Hz

100,000 hrs minimum at25 C

14.5A - 7.5A

OUTPUT

Max/Min Regulation Ripple & Noise Output

+12V1

+12V3

+12V2

+5V

+3.3V

-12V

+5Vsb

Total Power 1000W

30A/0.8A +5,-5% 75mV 175W

975W

25W

75mV

140mV

200mV

75mV

+5,-5%

+10,-10%

+5,-5%

30A/0.5A

20A/0.5A

1.0A/0.0A

3.0A/0.1A

ENVIRONMENT

Operating Temp.

Storage Temp.

Operating Humidity

Storage Humidity

10 to 50

-20 to 80

5% to 95%, non-condensing

PROTECTION

DC rail Trigger Point/Range

Over Voltage Protection

Over Current Protection

Short Protection All output to GND

+3.3V trip point

+5.0V trip point

+12.0V trip point

+3.3V

+5.0V

+12V 30A Max.

48A Max.

60A Max.

13.5V~16.5V

3.76V~4.8V

5.6V~7.0V

Peak Power 1100W(3S)

+12V4 140mV

+5,-5%

20A/0.5A

Voltage

Items

4.2 TR2 1000W SpecificationPSU

24-pin

Main Connector

8-pin

+12V Power

Connector

4-pin

Peripheral Power

Connector

4-pin

Floppy Drive

Connector

6-pin

PCI Express

Connector

Total Output Connector

X1 X1 X1 X6 X1

5-pin

SATA Connector

Technology Features

X10

- Four +12V Rails

- EPS Structure

X2 X2 X2

- Hi-Tech Black housing

- Intelligent temperature control 120mm Fan

Ten S-ATA

Connectors

4-pin

+12V Power

Connector

8-pin

PCI Express

Connector

8-pinto 6-pin

PCI Express

Connector

AC INPUT

DC OUTPUT

Maximum Load

Minimum Load

Max Combined

Wattage

The continuous total outputpower is 1000W,peak 1100W(3 sec.)

Total combined+12V output load shallbe 75A.

110V-240V 13-6.5A 50-60Hz

175W

975W 25W

+3.3V +5V +12V1 +12V2 +12V3 +12V4 -12V +5VSB

30A 30A 20A 20A 20A 20A 1A 3A

0.8A 0.5A 0.5A 0.5A 0.5A 0.5A 0.0A 0.1A

Performance

170 X 140 mm170 X 140 mm

W0176_TR2_1000W_ _A07102201

>> >>>> >>

TR2 1000W PSU TR2 1000W PSU

ATX12V 2.2 & EPS 12V 2.91 Version

Thermaltake TR2 Power SupplyThermaltake TR2 Power Supply

ATX12V 2.2 & EPS 12V 2.91 Version

4.4 Protection:

If the power supply protection that latch off all main outputs. ( when

OCP,OVP or short protection is working).Reset by cycling remote

on/off control orAC power.

4.4.1 Over CurrentProtection

4.4.2 Over Voltage Protection

+3.3V output

+5.0V output

+12.0V output

4.4.3 Short Protection

All output to GND.

3.76V ~ 4.8V

5.6V ~ 7.0V

13.5V ~ 16.5V

4.5 Environment:

4.5.1 Operating Temp. +10 C to +50 C

4.5.2 Storage Temp. -20 C to +80 C

4.5.3 Operating Humidity 5% to 95%, non-condensing

4.5.4 Storage Humidity 5% to 95%, non-condensing

4.6 EMI & Safety

+3.3V

+5.0V

+12V

Trigger Point

60A Max.

48A Max.

30A Max.

Output Voltage

4.6.1 EMI Regulatory

- FCC Part15 Subpart J,class 'B'

- CISPR 22 Class 'B'

4.6.2 Safety

- NEMKO EN60950

- VDE EN60950

- CSA C22.2NO.60950

- IEC 60950

- UL 60950

- CE

4.3.1 Inrush Current:

Maximum inrush currentfrom power-on (with power on at any

point on theAC sine) and including, but not limited to,three

line cycles, shallbe limited to a level below the surge ratingof

the input linecord, AC switch if present, bridge rectifier,fuse,

and EMI filtercomponents. Repetitive ON/OFF cycling of the

AC inputvoltage should not damage the power supply or

Cause the inputfuse to blow.

4.3.2 Power Efficiency:

4.3.3 Note:

The combined power of +5V and +3.3V is 175W max.

Add 0.1uF and 10uF capacitors across output terminal during

ripple & noise test.

4.3.4 Hold-Up Time:

20mSec. minimum attypical load

4.3.5 Power GoodDelay:

100-500 msec.

4.3.6 Power FailDelay:

>1 msec.

4.3.7 Rise Time:

20ms max atfull load.

4.3.8 MTBF at25 C(demonstrated)

100KHrs minimum

4.3 Other Specification

Loading Full load Typical load Light load

115V Required Minimum Efficiency 76% 80% 80%

230V Required Minimum Efficiency 80% 80% 80%

170 X 140 mm170 X 140 mm

W0176_TR2_1000W_ _A07102201

>> >>>> >>

TR2 1000W PSU TR2 1000W PSU

ATX12V 2.2 & EPS 12V 2.91 Version

Thermaltake TR2 Power SupplyThermaltake TR2 Power Supply

ATX12V 2.2 & EPS 12V 2.91 Version

Should you have any questions regarding the

aforementioned steps, please contact Thermaltake

directly. Failure to follow the proper procedures may

cause severe bodily harm or PC component damage.

For Support or General Inquiries, please contact us at:

Thermaltake Technology USA

Toll Free: (800)988-1088

Email: [email protected]

Thermaltake Europe B.V.

Tel:+31-10-409-0150

Email: @thermaltake.com.tw

Thermaltake Beijing Co.Ltd.

Tel:+86-10-82883159/3189 ext.16

Email: [email protected]

Thermaltake Australia and New Zealand Pty Ltd

Tel:+613-9763-1622

Email: [email protected]

Thermaltake Japan Inc.

Email: [email protected]

tt.europe

Condition 1: No DC output. The fan or fans are motionless

Check:

1-1 Is the AC inlet plug firmly plugged intothe PSU inlet

socket?

1-2 Is the wall socket, extension power cord, power strip

or surgeprotector in use, fully functional and wall power

switch turned 'ON'?

1-3 Is the Main Board socket (24pin) plug fully and firmly

inserted?

Condition 2: The fan or fans began rotating and then stopped.

The system hangs without proceeding any further.

Check:

2-1 Are the peripheral connectors firmly plugged into

accessory devices, such as the main hard drive,CD ROM

, etc?

2-2 If a plug has been inadvertently connected in an off-set or

reversed position,unplug the AC power source, reconnect

the offendingconnectors and then wait for 30 seconds

before replugin the AC power source and try again.

Note:

If the power supply is still unable topower up after following

the above instruction, please send the unit back to your dealer

or retailer for after sales service.

5. Trouble Shooting

1413

170 X 140 mm170 X 140 mm

W0176_TR2_1000W_ _A07102201

>> >>>> >>

TR2 1000W PSU TR2 1000W PSU

ATX12V 2.2 & EPS 12V 2.91 Version

Thermaltake TR2 Power SupplyThermaltake TR2 Power Supply

ATX12V 2.2 & EPS 12V 2.91 Version

PSU Adaptor Cable

(A)4pin-8pin (B)20pin-24pin

Specification

6.Cable Retail Package(Optional)

58g

Plastic

Black

pin -24 pin

198mm

Adaptor Cable

PlasticMaterial

( A )Model

16g

Weight

Red

Cable

sleeving

color

Adaptor CableModel

4pin -8 pin

Connector

type

193mm

Dimension

(mm)

( B )

Voltage 12V 3.3V,5V,

+12v,-12V

P/N:A2169

170 X 140 mm170 X 140 mm

W0176_TR2_1000W_ _A07102201

Otros manuales para TR2

Tabla de contenidos

Otros manuales de Fuente de alimentación de Thermaltake

Thermaltake

Thermaltake W0151 Manual de usuario

Thermaltake

Thermaltake Litepower 400W Manual de usuario

Thermaltake

Thermaltake TR2 RX 700w Manual de usuario

Thermaltake

Thermaltake Toughpower 800W Manual de usuario

Thermaltake

Thermaltake Toughpower Grand Manual de usuario

Thermaltake

Thermaltake W0104 Toughpower 650 AP Manual del propietario

Thermaltake

Thermaltake W0106RU Manual de usuario

Thermaltake

Thermaltake EPS 12V 2.91 Manual de usuario

Thermaltake

Thermaltake W0163 Toughpower QFan 650 A Manual de usuario

Thermaltake

Thermaltake TR2 Manual de usuario

Thermaltake

Thermaltake W0131RU Manual de usuario

Thermaltake

Thermaltake W0117 Manual de usuario

Thermaltake

Thermaltake Toughpower XT TPX-575M Manual de usuario

Thermaltake

Thermaltake W0157 Manual de usuario

Thermaltake

Thermaltake TR2-430W Manual de usuario

Thermaltake

Thermaltake Toughpower XT Series Manual de usuario

Thermaltake

Thermaltake Toughpower 1500W Manual de usuario

Thermaltake

Thermaltake TR2 500W Manual de usuario

Thermaltake

Thermaltake W0103 Toughpower 600 AP Manual del propietario

Thermaltake

Thermaltake ATX 12V 2.2 Manual de usuario

Thermaltake

Thermaltake TWV 500W Manual de usuario

Thermaltake

Thermaltake LITEPOWER PRO 550W Manual de usuario

Thermaltake

Thermaltake TR2-550W Manual de usuario

Thermaltake

Thermaltake ATX 12V 2.2 Manual de usuario

Manuales populares de Fuente de alimentación de otras marcas

Monacor

Monacor PS-12CCD Manual de usuario

VOLTIMA

VOLTIMA MagicBox 15 Manual de usuario

Agilent Technologies

Agilent Technologies 6032A Manual de usuario

Miller

Miller Auto Deltaweld 452 Manual de usuario

BCP

BCP PUOUBK Hoja de instrucciones

HC 2210 Manual de usuario

Puls

Puls CT5.241 Manual de usuario

OCZ

OCZ ZX1250W Manual de usuario

iseg

iseg ECH 238 Manual de usuario

Power

Power XXL A Series Manual de usuario

Agilent Technologies

Agilent Technologies 6631B Manual de usuario

Renogy

Renogy PHOENIX 300 Manual de usuario

HP 6200B Manual de servicio

Epson

Epson Stylus Scan 2500 Manual de funcionamiento

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manual de usuario

Puls

Puls MiniLine ML50.100 Manual de usuario

Puls

Puls AS-Interface SLA4.100 Manual de usuario

Kenwood

Kenwood PS-60 Manual de usuario
