The World Models Manufacturing Vendetta A345 Manual de usuario

A345PO32021803

Warning! This model is not a toy.

It is designed for maximum performance. Please seek advice if one is not familiar with this kind

of engine powered precision model. Operating this model without prior preparation may cause

injuries. Remember, safety is the most important thing. Always keep this instruction manual at

hand for quick reference.

*Specifications are subject to change without notice.*

INSTRUCTION MANUAL

Wing Span

Wing Area

Flying Weight

Fuselage Length

56.5 in / 1435 mm

558 sq in / 36 sq dm

7.3 Ib / 3350 g

51 in / 1290 mm

Specifications

FACTORY PRE-FABRICATED

ALMOST-READY-TO-FLY(ARF)SERIES

MADE IN CHINA

The World Models

Manufacturing Co., Ltd.

www.theworldmodels.com

(A345)

Requires: 5-channel radio w/ 3 standard servos and

2 mini servos,

2-stroke 0.46 engine, 4-stroke 0.81 engine

A345PO32021803

INDEX

BEFORE YOU BEGIN

PARTS LIST

ASSEMBLY

SAFETY PRECAUTIONS

P.1

P.2

P.3-P.11

P.12

Check all parts. If you find any defective or missing parts contact your local dealer. Please

DRY FIT and check for defects for all parts that will require CAor Epoxy for final assembly.

Any parts you find to be defective after the gluing process may be difficult to remove for

warranty replacement. The manufacturer will replace any defective parts, but will not extend

to the parts that are good before gluing to defective parts during assembly. Warranty will

not cover any parts modified by customer.

Symbols used throughout this instruction manual comprise of the following :-

Read through the manual before you begin, so you will have an overall idea of what to do.

P.1

Cut off shaded portion.

Ensure smooth non-binding

movement while assembling.

Apply instant glue

(C.A.glue, super glue.)

Assemble left and right

sides the same way.

Peel off shaded portion

covering film.

Pay close attention here!

Apply epoxy glue.

Must be purchased separately !

Drill holes with the specified

diameter (here: 3mm). Pierce the shaded portion

covering film.

3mm

Do not overlook this symbol !

Warning!

Apply thread locker

A345PO32021803

P.2

Parts List

COVERING:--

TOUGHLON STL 100 WHITE

TOUGHLON STL 311 FERRARI RED

TOUGHLON STL 201 BLACK

TOUGHLON STL 250 BLUE

TOUGHLON STL 320 ORANGE

8. ENGINE MOUNT PL5111050 -- 1 set

SOCKET HEAD SCREW M4x25mm -- 4 pcs

WASHER d4xD9mm -- 4 pcs

9. THROTTLE PUSHWIRE Ø1.2x620mm -- 1 pc.

PLASTIC TUBE d2xD3x460mm -- 1 pc.

SCREW PM3.5x30mm -- 4 pcs

WASHER d3.5xD8mm -- 8 pcs

M3.5 NUT -- 8 pcs

10. FUEL TANK 500cc -- 1 set

CABLE TIE 1.5x5x400mm -- 2 pcs

DOUBLE-SIDE TAPE 40x100mm -- 1 pc.

11. SILICON GROMMETS PL1265035 -- 4 pcs

SPINNER Ø82mm PL2111082 -- 1 set

SCREW PWA2.6x12mm -- 4 pcs

COWLING --1 pc.

TRANSPARENT 3D TEMPLATE -- 1 pc.

12. LINKAGE CONNECTOR Ø2.1mm w/ set screw -- 1 set

13. STRAPER PL4112102 -- 2 pcs

FUEL TUBE D6x5mm -- 2 pcs

PUSHROD CONNECTOR PL4410010 -- 1 set

PUSHROD Ø1.8x85mm (For Elevator) -- 1 pc.

SPONGE 60x70x105mm -- 2 pcs

BALSA 3x71x104mm (For Fuselage) -- 1 pc.

SCREW PWA2.6x8mm -- 1 pc.

14. SCREW HM4x60mm -- 2 pcs

SCREW HM4x35mm -- 2 pcs

WASHER d4xD15mm -- 4 pcs

15. SCREW PM3x13mm -- 1 pc.

WASHER d3xD7mm -- 1 pc.

BELLY PAN -- 1 pc.

16. DECALS: A341 DEC -- 1 set

1. MAIN WING -- 1 pair

2. PUSHROD Ø1.8x85mm w/ Threads (For Aileron) -- 2 pcs

TRI-HORN PL4111221 -- 2 sets

SCREW PB2x16mm -- 4 pcs

SCREW PB2x12mm -- 2 pcs

SCREW PWA2.3x8mm -- 8 pcs

CLEVIS PL4112103 -- 2 pcs

FUEL TUBE D6x5mm -- 4 pcs

STRAPER PL4112102 -- 2 pcs

PLYWOOD 2x68x73mm (Aileron Servo Cover) -- 1 pair

BALSA 8x16x16mm (For Aileron Servo Stand) -- 4 pcs

MAIN LANDING GEAR COVERS -- 1 pair

RETRACTABLE LANDING GEAR COVERS -- 1 set

WING TUBE Ø16x456mm -- 1 pc.

180mm Y-CORD KW0021800 -- 1 pc.

3. VERTICAL FIN & RUDDER -- 1 set

FUSELAGE -- 1 pc.

NYLON SCREW M4x12mm -- 3 pcs

4. STABILIZER & ELEVATOR -- 1 set

STABILIZER TUBE Ø5x134.5mm -- 1 pc.

STABILIZER TUBE Ø6x234mm -- 1 pc.

5. PUSHROD Ø1.8x340mm w/ Threads (For Elevator) -- 2 pcs

SCREW PB2x16mm -- 4 pcs

SCREW PB2x14mm -- 2 pcs

CLEVIS PL4112103 -- 2 pcs

TRI-HORN PL4111221 -- 2 sets

FUEL TUBE D6x5mm -- 2 pcs

SCREW PWA3x12mm -- 2 pcs

6. PUSHROD Ø1.8x480mm w/ Threads (For Rudder) -- 1 pc.

CLEVIS PL4112103 -- 1 pc.

SCREW PB2x12mm -- 3 pcs

TRI-HORN PL4111301 -- 1 set

FUEL TUBE D6x5mm -- 1 pc.

7. TAIL LANDING GEAR -- 1 set

TAIL WHEEL Ø25mm -- 1 pc.

COLLAR Ø2.1mm w/ Set Screw -- 1 set

SCREW PA3x14mm -- 2 pcs

SCREW PM2x10mm -- 1 pc.

ALUMINIUM PLATE 0.3mm -- 1 pc.

M2 NUT -- 1 pc.

A345PO32021803

P.3

Main Wing

Aileron Pushrod & Retractable Landing Gear

PB2x16mm Screw

Ø1mm pilot holes for World Models horn are pre-drilled.

Please look for pin-hole marks at under side of control surfaces.

Straper Fuel Tube

D6x5mm

PB2x16mm

PB2x12mm

Clevis

Tri-horn

M3x14mm

Pushrod

Ø1.8x85mm

Fuel Tube

D6x5mm

PB2x12mm Screw

PWA2.3x8mm Screw

PWA2.3x8mm

1.5mm

Servo wire

Wing Tube

Ø16x456mm

Apply instant type CA glue to both sides of each hinge.

4.8V - 6.0V operation

only, higher voltage

will burn out the

retract motor.

Electric retract wire

PWA2.3x8mm

Bottom View

Balsa

8x16x16mm

Make a slot into the hatch for

the servo horn to come out.

1mm

A345PO32021803

P.4

Nylon Screw M4x12mm

Vertical Fin & Rudder

C C'

C=C'

Apply instant type CA glue to

both sides of each hinge.

Stabilizer Tube Ø5x134.5mm

Stabilizer Tube Ø6x234mm

Stabilizer & Elevator

Apply instant type CA glue to

both sides of each hinge.

Temporary install the main wing,

adjust leveling of the stabilizer

to make it as parallel to the main

wing as possible

(Stabilizer)

(Main Wing)

B B'

B=B'

M4x12mm Screw

A345PO32021803

PB2x16mm Screw

PB2x14mm Screw

PB2x12mm Screw

Elevator Pushrod

Rudder Pushrod

Tail Landing Gear

P.5

PB2x16mm

PB2x14mm

Clevis

Tri-horn

M3x14mm

Pushrod

Ø1.8x340mm

Fuel Tube

D6x5mm

PA3x14mm Screw

M2 Nut

PM2x10mm Aluminium Plate

M2 Nut

Ø1mm pilot holes for World Models horn are pre-drilled. Please look for pin-hole marks at

under side of control surfaces.

PB2x12mm

Fuel Tube

D6x5mm

Pushrod

Ø1.8x480mm

Clevis

Tri-horn

M3x22mm

Ø1mm pilot holes for World Models horn are pre-drilled. Please look for pin-hole marks at

side of control surfaces.

2.1mm Collar

PA3x14mm

3mm set screw

1.5mm

PM2x10mm Screw

2.1mm Collar

Bottom View

PWA3x12mm

1.5mm

PWA3x12mm Screw

A345PO32021803

P.6

Engine Mount

Engine Mount PL5111050

M4x25mm

d4xD9mm

M4x25mm Socket Head Screw

d4xD9mm Washer

Apply thread locker to screws

For short engines, add base brackets.

Blind nuts are off-centered

to keep the spinner at the

fuselage axis.

Engine

PM3.5x30mm Screw

d3.5xD8mm Washer

M3.5

Throttle Pushwire

Ø1.2x620mm

Plastic Tube

d2xD3x460mm

PM3.5x30mm

d3.5xD8 Washer

M3.5 Nut

Illustration is for inverted mounting.

You can mount the engine upright or

side ways simply by rotation the

engine mount. Thrust angles will not

be affected.

129mm

5.08 in.

For short engines.

A345PO32021803

Cowling

P.7

First insert the grommet to the

cowling then apply screw.

d1.5xD6.5mm

Grommet

Cowling

Fuselage

PWA2.6x12mm

PWA2.6x12mm Screw

d1.5xD6.5mm Silicon Grommets

Silicon Grommets

PWA2.6x12mm

Spinner

Fuel Tank

Front Cable Tie 1.5x5x400mm

Fuel Tank 500CC

Bottom View

A345PO32021803

Servos Setting

P.8

Fuel Tube

D6x5mm

Straper

Sponge

60x70x105mm Elevator Pushrod

Rudder Pushrod

Throttle Puswire

Rudder Servo

Elevator Servo

Reciever

Battery

Throttle Servo

Install and arrange the servo as shown in the diagram.

Elevator Servo

Pushrod Connector

J1(Pushrod Ø1.8x85mm)

Servo Set

Throttle Pushwire

3x3mm SetScrew

Washer

2mm

Washer

2mm

M2Nut

Throttle Servo

1.5mm

Please refer to the attached sheet for linkage connector installation.

3x3mm Set Screw

M2 Nut

Linkage Connector

2mm Washer

PWA2.6x8mm

Balsa 3x71x104mm

PWA2.6x8mm Screw

Bottom View

A345PO32021803

HM4x60mm Screw

d4xD15mm Washer

HM4x35mm Screw

Belly Pan

P.9

Main wing

HM4x60mm

PM3x13mm

HM4x35mm

d4xD15 Washer

d3xD7 Washer

Belly Pan

d4xD15 Washer

Completed

PM3x13mm Screw

d3xD7mm Washer

Bottom View
