The Flying Culinary Circus PERFORMANCE 4.1 Guía

INSTRUCTION MANUAL & MAINTENANCE

Sare  u  cookin!

OUTDOORUSEONLY

READTHEOPERATINGINSTRUCTIONS

BEFOREUSINGTHEAPPLIANCE.

FCC-G-18220-41 / GD4842

Contents

Warnings...........................................................................................................3

Technical data Performance 4.1...........................................................4

Gas category..................................................................................................4

Exploded drawing .....................................................................................5

Parts list ............................................................................................................6

Assembly instructions ...............................................................................7

Gas leak test ................................................................................................14

Regulator and hose ...................................................................................15

Last Check ...................................................................................................16

Lighting instructions................................................................................. 17

Warnings ......................................................................................................18

Maintenance .............................................................................................19

Grease ﬁre..................................................................................................20

Singapore Chili Crab..............................................................................21

Troubleshooting..........................................................................................23

Consumer Contact.................................................................................24

WARNINGS

• FAILURE TO FOLLOW THE INSTRUCTIONS PROVIDED CAN

IMPLY A RISK OF SERIOUS INJURY TO PERSONNEL AND FIXED

INSTALLATIONS.

• THE BBQ IS INTENDED FOR OUTDOOR USE ONLY IN WELL-

VENTILATED AREAS. NEVER BBQ IN ENCLOSED SPACES OR

UNDER A ROOF, DUE TO THE DANGER OF THE LACK OF

OXYGEN.

• ACCESSIBLE PARTS OF THE BBQ BECOME VERY HOT DURING

USE. KEEP CHILDREN AND OTHERS WHO NEED SUPERVISION AT

A SAFE DISTANCE.

• NEVER MOVE THE BBQ WHILE IN USE OR CONNECTED TO THE

GAS BOTTLE.

• SHUT OFF THE GAS ON THE REGULATOR AFTER USE AND

DISCONNECT FROM THE GAS BOTTLE.

• MODIFICATION OF THE BBQ CAN CAUSE DANGER AND WILL

INVALIDATE THE WARRANTY.

• DO NOT PLACE THE BBQ COVER OR OTHER FLAMMABLE

MATERIAL IN THE COMPARTMENT UNDER THE BBQ WHEN IT IS

IN USE OR HOT.

• CLEAN THE BBQ REGULARLY AND THOROUGHLY.

Read carefully

GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4842S-AA

FOR OUTDOOR

USE ONLY

Do not attempt to assemble and use this grill unless you read this entire manual thoroughly.

Keep it in a handy place as it has answers for questions that may occur in your future use.

NOTE: THIS APPLIANCE IS NOT INTENDED TO INSTALL IN OR ON RECREATIONAL

VEHICLES OR BOATS.

Reminder : As the products have been renewing,if you ﬁnd the real products are different from the manual's, pls.in kind prevail.

2531-17

DESTINATIONOF

COUNTRIESTOUSE VALVESIZE GASTYPE GASCATEGORY

LU, NL, DK, FI, SE, CY,

CZ, EE, LT, LV, MT, SK ,

SI, BG, IS, NO, TR, HR,

RO, IT, HU

Dia 0.91 mm (main burner)

0.86 mm (hot plate burner)

G (butane), G(propane) and

their mixtures I3B/P(30)

I3B/P(30): G30(Butane), G31(propane)

and mixtures of these.

H: 120 cm

W: 146 cm

Technical information

Total Heat input: 17.2 kW (main burner 14 kW + side burner 3.2 kW.

Gas consumption: 1252 gram/hour (main burner: 1019 g/h + side burner: 233 g/h)

Gasbottle (not included): Use standard bottle approved for use in the Nordic Region.

Even though butane and propane gas can be used, we recommend propane for use in the

Nordic Region. Approved hoses and regulators are available om most outlets selling gas

equipment.

NB! Gas hoses used for this product must not exceed 120 cm in length.

• ONLY THE GAS TYPE AND GAS CATEGORY LISTED IN THE RATING LABLE

COUILD BE USED ON YOUR APPLIANCE.

This product is produced according

to EUROPEAN

GASAPPLIANCE

STANDARDEN-2012 and

EN -1997 and is CE certiﬁed.

THE APPLIANCE IS SET TO OPERATE

Explosion view:

— 2 —

GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4842S-AA

Exploded drawing

CODE hard ware QTY

AM x 60 SCREW 8

BM LOCKNUT 1

CGASKETS 1

DM x 12 SCREW 24

EM x 8 SCREW 12

CODE DESCRIPTION QTY

1WARMINGRACK 1

2COOKINGGRILL 1 1

3COOKINGGRILL 2 1

4FMETAMER 4

5BODYASSEMBLY 1

6RIGHTSIDETABLE 1

7DECORSHEETRIGHTSIDETABLE 1

8GREASECUP 1

9OILTRAY, SUPPORTRIGHTSIDE 1

10 RIGHTBACKFOOT 1

11 RIGHTFRONTFOOT 1

12 BOTTOMPANEL 1

13 LOCKABLECASTER 2

14 WHEELAXLE 1

15 WHEEL 2

16 FRONTPANEL 1

17 LEFTFRONTFOOT 1

18 OILTRAY, SUPPORTLEFTSIDE 1

19 LEFTBACKFOOT 1

20 OILTRAY 1

21 DECORSHEETLEFTSIDETABLE 1

22 SIDEBURNERASSEMBLY 1

23 KNOB 1

24 SIDEBURNER 1

25 POTSUPPORT 1

26 COOKINGGRILL 3 1

27 MATCHSTICKHOLDERASSEMBLY 1

28 KNOBBEZEL 1

WARNING! EXERCISECAUTIONWHENUSINGELECTRICTOOLS

 THEIRSTRENGTHCANDAMAGETHESCREWS.

Please follow these instructions step by step. A screwdriver is necessary

when assembling the BBQ. The BBQ should be assembled by two persons.

Parts List

— 4 —

GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4842S-AA

Assemble the legs and bottom panel

Assemble the wheels and castors

Assembly

— 5 —

GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4842S-AA

Install the front panel

Install the drip tray brackets

Assembly

— 6 —

GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4842S-AA

Install the ﬁrebox

Install the tooling hook panels to the

side burner table and side table

Assembly

— 7 —

GAS GRILL ASSEMBLY, USE AND CARE MANUAL GD4842S-AA

Install the right side table assy

Install the side burner assy

Assembly
