Thales Cinterion DGL61-W Manual de usuario
Getting Started with DGL61-W
User Guide
Version: 01
DocId: DGL61-W_startup_guide_v01
GENERAL NOTE
THIS DOCUMENT CONTAINS INFORMATION ON THALES PRODUCTS. THALES RESERVES THE
RIGHT TO MAKE CHANGES TO THE PRODUCTS DESCRIBED HEREIN. THE SPECIFICATIONS IN
THIS DOCUMENT ARE SUBJECT TO CHANGE AT THE DISCRETION OF THALES. THE PRODUCT
AND THIS DOCUMENT ARE PROVIDED ON AN "AS IS" BASIS ONLY AND MAY CONTAIN DEFICIEN-
CIES OR INADEQUACIES. THALES DOES NOT ASSUME ANY LIABILITY FOR INFORMATION PRO-
VIDED IN THE DOCUMENT OR ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT
DESCRIBED HEREIN.
THALES GRANTS A NON-EXCLUSIVE RIGHT TO USE THE DOCUMENT. THE RECIPIENT SHALL
NOT COPY, MODIFY, DISCLOSE OR REPRODUCE THE DOCUMENT EXCEPT AS SPECIFICALLY
AUTHORIZED BY THALES.
Copyright © 2020, THALES DIS AIS Deutschland GmbH
Trademark Notice
Thales, the Thales logo, are trademarks and service marks of Thales and are registered in certain coun-
tries.
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
tDGL61-W_startup_guide_v01 2020-11-18
Public / Preliminary
Getting Started with DGL61-W
2
Page 2 of 17
User Guide: Getting Started with DGL61-W
Version: 01
Date: 2020-11-18
DocId: DGL61-W_startup_guide_v01
Status Public / Preliminary
Getting Started with DGL61-W
Contents
17
tDGL61-W_startup_guide_v01 2020-11-18
Public / Preliminary
Page 3 of 17
Contents
0 Document History ...................................................................................................... 4
1 Introduction ................................................................................................................. 5
1.1 Supported Products ........................................................................................... 5
1.2 Related Documents ........................................................................................... 5
2 Getting Started with DLGL61-W................................................................................. 6
2.1 Overview ............................................................................................................ 6
2.2 Installation on Windows 7 .................................................................................. 7
2.2.1 Technical Requirements ....................................................................... 7
2.2.2 Installation Procedure ........................................................................... 7
2.3 Installation on Windows 10 .............................................................................. 13
2.3.1 Technical Requirements ..................................................................... 13
2.3.2 Installation Procedure ......................................................................... 13
Getting Started with DGL61-W
1 Introduction
16
tDGL61-W_startup_guide_v01 2020-11-18
Public / Preliminary
Page 5 of 17
1 Introduction
The purpose of this document1is to guide you through the process of connecting the hardware,
installing the supplied drivers on a Microsoft®Windows 7 system, using Microsoft®Windows 10
and Linux and getting started with Device Gateway LTE DGL61-W.
1.1 Supported Products
This document applies to the following Thales product:
•Cinterion
®DGL61-W
1.2 Related Documents
[1] DGL61-W Hardware Interface Description
[2] PLS62-W AT Command Specification
1. The document is effective only if listed in the appropriate Release Notes as part of the technical docu-
mentation delivered with your Thales module.
Getting Started with DGL61-W
2 Getting Started with DLGL61-W
16
tDGL61-W_startup_guide_v01 2020-11-18
Public / Preliminary
Page 6 of 17
2 Getting Started with DLGL61-W
2.1 Overview
Before you plug in the DGL61-W to your computer system, please insert your SIM Card (mirco
format) into DGL61-W.
Connect DGL61-W with your computer system.
Depending on your operating system you have to do different steps:
• Windows 7:
For using DGL61-W with Windows 7 you have to install the drivers provided by Thales,
which can be downloaded from the product page of DGL61-W (https://www.thales-
group.com/en/markets/digital-identity-and-security/iot/iot-connectivity/products/iot-prod-
ucts/dgl61).
To start the connection to the Internet via DGL61-W, you have to send two commands to
the DGL61-W via the assigned COM Interface:
1.) setting the PIN for SIM Card (AT+CPIN="<your PIN>") and
2.) starting the connection (AT^SWWAN=1,1,1).
These commands can be easily put together in one batch-file, because these commands
have to be sent every time after DGL61-W powered up.
For details see Section 2.2.
• Window 10:
Windows 10 will recognize DGL61-W automatically and installs all required drivers. Win-
dows will then guide you to the Cellular page inside the Control Panel to enter the PIN for
your SIM. Windows 10 controls the connection to the Internet depending on your configu-
ration.
For details see Section 2.3.
•Linux:
For using DGL61-W with Linux see Thales IoT Developer Community "How to Guide:
ELS61/PLS62 and Linux Startup", which is valid for DGL61-W too at
https://developer.gemalto.com/tutorial/how-guide-els61pls62-and-linux-startup
For using DGL61-W with Linux (Ubuntu 18.04) and MBIM see Thales IoT Developer Com-
munity "Make the ELS81-E/US MBIM Function Works with Ubuntu Linux 18.04", which is
valid for DGL61-W too at
https://developer.gemalto.com/tutorial/make-els81-eus-mbim-function-works-ubuntu-linux-
1804
Getting Started with DGL61-W
2.2 Installation on Windows 7
16
tDGL61-W_startup_guide_v01 2020-11-18
Public / Preliminary
Page 7 of 17
2.2 Installation on Windows 7
2.2.1 Technical Requirements
• DGL61-W
• corresponding driver package (USB)
(download from DGL61-W product page https://www.thalesgroup.com/en/markets/digital-
identity-and-security/iot/iot-connectivity/products/iot-products/dgl61
• Computer running Windows 7, USB 2.0 Interface
• Local administrator privileges on the particular Windows computer to install and uninstall
the drivers
• (U)SIM from a UMTS/LTE/NR network provider
2.2.2 Installation Procedure
1. Insert micro SIM with the
circuit side facing upwards
into DGL61-W by gently
pushing it into the SIM
card holder until it snaps
hold.
Figure 1: Insert SIM
2. Connect DGL61-W with the PC/Notebook
Getting Started with DGL61-W
2.2 Installation on Windows 7
16
tDGL61-W_startup_guide_v01 2020-11-18
Public / Preliminary
Page 8 of 17
3. Windows 7 is starting to
search for driver.
Figure 2: Windows is searching for Drivers
4. Stop search for drivers
from Windows Update by
clicking on "Skip obtaining
driver software from Win-
dows Update" (see Figure
2) and then click on "Yes"
(see Figure 3)
Figure 3: Aborting Driver Installation
5. Open "Device Manager"
from "Control Panel"
Figure 4: Device Manager before installing the drivers
6. For each "PLSx" in section "other Devices" select "Update Driver Software ..." do the steps
7 to 11
Getting Started with DGL61-W
2.2 Installation on Windows 7
16
tDGL61-W_startup_guide_v01 2020-11-18
Public / Preliminary
Page 9 of 17
7. Select "Browse my com-
puter for driver software"
Figure 5: Select installation method
8. Enter path to unzipped
driver package (1), set
check mark at "Include
subfolders" (2) and click
on "Next" (3)
Figure 6: Enter path to unzipped driver package
1
2
3
Getting Started with DGL61-W
2.2 Installation on Windows 7
16
tDGL61-W_startup_guide_v01 2020-11-18
Public / Preliminary
Page 10 of 17
9. Set check mark at "Always
trust software from
"Gemalto M2M GmbH" (1)
and click on "Install (2)
Figure 7: Trust and Install
10. "Click on "Close"
Figure 8: Installed successfully
12
