Textron JACOBSEN RC466 Guía de configuración

WARNING: If incorrectly used this machine can cause severe injury. Those who use

and maintain this machine should be trained in its proper use, warned of its dangers

and should read the entire manual before attempting to set up, operate, adjust or

service the machine.

OWNER/OPERATOR’S MANUAL

& ILLUSTRATED PARTS LIST

09-408 REV B

MODEL:

73-71010 ROUGH CUT MOWER RC466

CALIFORNIA

Proposition 65 Warning

Diesel engine exhaust and some of

its constituents are known to the State

of California to cause cancer, birth

defects and other reproductive harm.

Californie Proposition 65

Avertissement

Les échappements des moteurs diesel

et certains de leurs composés sont

reconnus par l’Etat de Californie pour

être cancérigènes, provoquer des

défauts congénitaux et d’autres dangers

en matière de reproduction.

ADVERTENCIA

AVERTISSEMENT

WARNING

The engine exhaust from this product

contains chemicals known to the State

of California to cause cancer, birth

defects or other reproductive harm.

California Advertencia

de la Proposicion 65

El estado de California hace saber que

los gases de escape de los motores

diesel y algunos de sus componentes

producen cáncer, defectos de

nacimiento y otros daños en el

proceso de reproducción humana.

L’

mission du moteur de ce mat

riel

contient des produits chimiques que

l’Etat de Californie consid

tre

canc

rig

nes, provoquer des d

fauts

cong

nitaux et d’autres dangers en

mati

re de reproduction.

El estado de California hace saber

que los gases de escape de este

producto contienen productos

quÍmicos que producen cáncer,

defectos de nacimiento y otros daños

en el proceso de reproducción

humana.

ROUGH

CUT

MOWER

IMPORTANTMESSAGE

Thank you for purchasing this Jacobsen product. You have purchased a world class product, one of the best

designed and built anywhere.

This product comes with an Owner/Operator's Manual. The useful life and good service you receive from this

product depends to a large extent on how well you read and understand this manual. Treat this product properly

and adjust it as instructed, and it will give you many years of reliable service.

See a Jacobsen dealer for any service or parts needed. Jacobsen service ensures that you continue to receive

the best results possible from Jacobsen products. You can trust Jacobsen replacement parts because they are

manufactured with the same high precision and quality as the original parts.

Jacobsen designs and builds its equipment to serve many years in a safe and productive manner. For longest

life, use this product only as directed in the manual, keep it in good repair and follow safety warnings and

instructions. You'll always be glad you did.

Jacobsen, a Textron Company

One Bob Cat Lane

Johnson Creek, WI 53038-0469

8-2004

TABLE OF CONTENTS FIGURES PAGE

DESCRIPTION / SPECIFICATIONS .............................................................................................................. 2

SAFETY ...................................................................................................................................................... 3-6

DECALS......................................................................................................................................................... 7

INSTALLATION .......................................................................................................................................... 8, 9

OPERATION ................................................................................................................................................ 10

SERVICE ................................................................................................................................................ 11-13

MAIN FRAME..................................................... FIGURE 1 ................................................................. 14, 15

PTO & DRIVE SHAFTS ..................................... FIGURE 2 ................................................................. 16, 17

SPINDLE ASSY & DRIVE BELTS ...................... FIGURE 3 ................................................................. 18, 19

DECK ASSY & SHIELDS ................................... FIGURE 4 ................................................................. 20, 21

DECALS............................................................. FIGURE 5 ................................................................. 22, 23

ROUGH

CUT

MOWER

DESCRIPTION / SPECIFICATIONS

SPECIFICATIONS

Overall Width .........................................................................70"

Caster Wheels .......................................................................13 X 5.00 - 6 foam filled (flat proof)

Mower Drive...........................................................................PTO Belt

Spindles .................................................................................Four cast iron housings, ball bearings

Cutting Width .........................................................................66", offset 16" to right

Cutting Height ........................................................................3-1/2" to 5-1/2"

Blades ....................................................................................Replaceable swinging blades on disc rotors

Discharge...............................................................................Rear

Weight....................................................................................550 lbs.

DESCRIPTION

The RC466 Rough Cut Mower will cut through tall, dense growth and 1" woody stems. Free-swinging

blades on discs all but eliminate shock load to the four spindles. Chains at the front opening allow

unrestricted access for tall growth. Counter rotating disc blades move material freely to the rear discharge.

Mounted on the front lift, this mower cuts the growth before it is pressed down by the tractor, and offers

excellent visibility to your work.

ROUGH

CUT

MOWER

SAFETY

NOTICE !!!

Unauthorized modifications may present extreme

safety hazards to operators and bystanders and

could also result in product damage.

Jacobsen, a Textron Company strongly warns

against, rejects and disclaims any modifications,

add-on accessories or product alterations that are

not designed, developed, tested and approved by

Jacobsen Engineering Department. Any Jacobsen

product that is altered, modified or changed in any

manner not specifically authorized after original

manufacture–includingtheadditionof“after-market”

accessories or component parts not specifically

approved by Jacobsen–will result in the Jacobsen

Warranty being voided.

Anyandallliabilityforpersonalinjuryand/orproperty

damagecausedbyanyunauthorizedmodifications,

add-on accessories or products not approved by

Jacobsen will be considered the responsibility of

the individual(s) or company designing and/or

making such changes. Jacobsen will vigorously

pursuefull indemnificationandcosts fromany party

responsibleforsuchunauthorizedpost-manufacture

modifications and/or accessories should personal

injury and/or property damage result.

This symbol means:

ATTENTION!

BECOME ALERT!

Your safety and the safety of others is involved.

Signal word definitions:

The signal words below are used to identify levels

of hazard seriousness. These words appear in this

manual and on the safety labels attached to

Jacobsenmachines.Foryoursafetyand the safety

ofothers,readandfollowtheinformationgivenwith

thesesignalwordsand/orthesymbolshownabove.

DANGER indicates an imminently hazardous

situationwhich, ifnot avoided,WILL result indeath

or serious injury.

WARNING indicates a potentially hazardous

situation which, if not avoided, COULD result in

death or serious injury.

CAUTION indicates a potentially hazardous

situation which, if not avoided, MAY result in minor

or moderate injury. It may also be used to alert

against unsafe practices or property damage.

CAUTION used without the safety alert symbol

indicates a potentially hazardous situation which, if

not avoided, MAY result in property damage

MODEL NUMBER: This number appears on

sales literature, technical manuals and price

lists.

SERIAL NUMBER: This number appears only

on your mower. It contains the model number

followed consecutively by the serial number.

Use this number when ordering parts or seeking

warranty information.

ROUGH

CUT

MOWER

SAFETY

GENERALSAFETY

• Read and understand the owner’s manual,

before attempting to operate this machine.

• Operate all controls from the operator’s

seat, (if so equipped). NO RIDERS.

• Keep all shields in place and safety

switches adjusted properly.

• Do not leave equipment unattended. STOP

the engine and remove the key (if so

equipped).

• Do not allow minors or the inexperienced to

operate this machine.

• Never allow anyone to operate or service

this machine while under the influence of

alcohol or drugs.

• Keep people and pets a safe distance away

from machines using power driven

attachments. Injury could result from flying

debris.

• Wear all the necessary protective clothing

and personal safety devices to protect your

head, eyes, ears, hands, and feet.

• Operate the machine only in daylight or in

good artificial light.

ROUGH

CUT

MOWER

SAFETY

SAFE OPERATION PRACTICES FOR

MOWERS

This cutting machine is capable of amputating

hands and feet and throwing objects. Failure to

observe the following safety instructions could

result in serious injury or death.

I GENERAL OPERATION

1. Read, understand, and follow all instructions in

the manual and on the machine before starting.

2. Only allow responsible adults, who are familiar

with the instructions, to operate the machine.

3. Clear the area of objects such as rocks, toys ,

wire, etc., which could be picked up and thrown

by the blade.

4. Be sure the area is clear of other people before

mowing. Stop the machine if anyone enters the

area.

5. Never carry passengers.

6. Do not mow in reverse unless absolutely

necessary. Always look down and behind

before and while backing.

7. Slow down before turning.

8. Never leave a running machine unattended.

Always turn off blades, set parking brake, stop

engine, and remove keys before dismounting.

9. Turn off blades when not mowing.

10. Stop engine before unclogging or cleaning

under deck.

11. Mow only in good light, keeping away from

holes and hidden hazards.

12. Do not operate the machine while under the

influence of alcohol or drugs.

13. Watch for traffic when operating near or

crossing roadways.

14. Use extra care when loading or unloading the

machine into a trailer or truck.

15. Always wear safety goggles or safety glasses

with side shields when operating mower.

II SLOPE OPERATION

Slopes are a major factor related to

loss-of-control and tip-over accidents, which can

result in severe injury or death. All slopes

require extra caution. If you feel uneasy on it, do

not mow it.

DO:

• Mow up and down slopes where possible.

• Remove obstacles such as rocks, tree limbs,

etc.

• Watch for holes, ruts, or bumps. Uneven terrain

could overturn the machine. Tall grass can hide

obstacles.

• Use slow speed (low range). Do not attempt to

shift while on the slope.

• Follow the manufacturers recommendations for

wheel weights or counterweights to improve

stability.

• Keep all movement on the slope slow and

gradual. Do not make sudden changes in

speed or direction.

• Avoid stopping or starting on a slope. If tires

lose traction, disengage the blades and proceed

slowly straight down the slope.

ROUGH

CUT

MOWER

SAFETY

DO NOT:

• Do not turn on slopes unless necessary, and

then, turn slowly and gradually downhill, if

possible.

• Do not mow drop-offs, ditches, or

embankments. The mower could suddenly turn

over if a wheel is over the edge of a cliff or

ditch, or if an edge caves in.

• Do not mow on wet grass. Reduced traction

could cause sliding.

• Do not try to stabilize the machine by putting

your foot on the ground.

III CHILDREN

Tragic accidents can occur if the operator is not

alert to the presence of children. Children are

often attracted to the machine and the mowing

activity. Never assume that children will remain

where you last saw them.

1. Keep children out of the mowing area and under

the watchful eye of another responsible adult.

2. Be alert and turn machine off if children enter

the area.

3. Before and when backing, look behind and

down for small children.

4. Never carry children as passengers, even with

the blades turned off. They may suddenly fall

off and be seriously injured or interfere with safe

machine operation.

5. Never allow children to operate the machine.

6. Use extra care when approaching blind corners,

shrubs, trees, or other objects that may obscure

vision.

IV SERVICE

1. Use extra care in handling gasoline and other

fuels. They are flammable and the vapors are

explosive.

a. Use only an approved container.

b. Never remove gas cap or add fuel with

engine running. Allow engine to cool before

refueling. Do not smoke.

c. Never refuel or drain the machine indoors.

d. Never store the machine or fuel container

inside where there is an open flame, such

as in a water heater.

2. Never run the machine in a closed area.

3. Keep nuts and bolts, especially blade

attachment bolts, tight and keep equipment in

good condition.

4. Never tamper with safety devices. Check their

proper operation regularly.

5. Keep machine free of grass, leaves, and other

debris build-up. Clean up oil or fuel spillage.

Allow machine to cool before storing.

6. Stop and inspect the equipment if you strike an

object. Repair, if necessary, before restarting.

7. Never make adjustments or repairs with the

engine running.

8. Frequently check components and replace with

manufacturer’s recommended parts, when

necessary.

9. Mower blades are sharp and can cut. Wrap the

blade(s) or wear gloves, and use extra caution

when servicing them.

ROUGH

CUT

MOWER

DECALS

Location: On mower drive line shield.

Location: On drive belt shield.

Location: On mower deck right rear.

Location: On mower deck top front center and

both sides.

Location: On mower deck top left and right

shields.

ROUGH

CUT

MOWER

INSTALLATION

ATTACHING MOWER TO TRACTOR:

- Operate latch control to open hitch latches.

- Drive tractor into position aligning the quick hitch.

- Be sure both latches engage fully and and are placed in the locked position.

-Stop engine! Do not attempt to install drive belt with engine running.

- Release idler assembly to facilitate easy installation of the drive belt.

- Put belt over drive pulleys and engage or adjust idler assembly.

(See Power Unit Operator’s Manual for PTO belt tension adjustments.)

- Move hitch stand to transport position. Set mower to desired cutting height.

- Start engine and engage PTO slowly to prevent shock load on mower components.

- Mow with front lift lever in “FLOAT” position only.

LEDOMTINUREWOP TLEBEVIRD

032/022 LESEID032 040A-18 140B-18

TONSITINUSIHT(014 )DEDNEMMOCER

034/024040A-18

524140B-18

525140B-18

DRIVE BELT CHART

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cortacésped de Textron

Textron

Textron JACOBSEN GP400 Guía

Textron

Textron JACOBSEN LF 3400 Guía

Textron

Textron JACOBSEN Eclipse 2 Manual de usuario

Textron

Textron RANSOMES FRONT-LINE 933 Especificaciones

Textron

Textron BUNTON BZT 2000 Series Manual de uso y cuidado

Textron

Textron Jacobsen Fairway 250 Guía

Textron

Textron Ransomes Jacobsen Super Certes 51 Guía

Textron

Textron Ransomes DM Hydraulic 5/7 Mk4 Guía

Textron

Textron Bunton EC Hydro Midsize 930024 Manual de usuario

Textron

Textron RANSOMES 933407 Guía

Textron

Textron Ransomes Mastiff 91 Series Guía

Textron

Textron JACOBSEN PGM Series Manual de usuario

Textron

Textron Jacobsen Fairway 305 Guía

Textron

Textron BOB-CAT 930022 Manual de usuario

Textron

Textron Jacobsen G-Plex III Guía

Textron

Textron JACOBSEN PGM Series Manual de usuario

Textron

Textron Ransomes Parkway 2250 Plus Guía

Textron

Textron Jacobsen Tri-King 67139 Manual de usuario

Textron

Textron RANSOMES JACOBSEN HR6010 Manual de usuario

Textron

Textron Cessna SL510-34-18 Manual de servicio

Textron

Textron Jacobsen 744908A Manual de usuario

Textron

Textron JACOBSEN JZT 1250 CUTTERDECKS Manual de usuario

Textron

Textron RANSOMES Highway 2130 Manual de usuario

Textron

Textron Jacobsen HR 9016 Turbo Manual de usuario

Manuales populares de Cortacésped de otras marcas

RHINO

RHINO 1958 Manual de usuario

Wolf Garten

Wolf Garten Compact plus 40 B Manual de usuario

Cub Cadet

Cub Cadet LTX 1045 Manual de usuario

Craftsman

Craftsman 917.378461 Manual de usuario

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manual de usuario

Challenge

Challenge CH18V2 Instrucciones de operación

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manual de usuario

DEWEZE

DEWEZE ATM-725 Manual de operación

Weed Eater

Weed Eater 180083 Manual de usuario

Husqvarna

Husqvarna Poulan Pro PP185A42 Manual de usuario

Better Outdoor Products

Better Outdoor Products Quick Series Manual de usuario

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manual de funcionamiento

MTD

MTD 795, 792, 791, 790 Manual de usuario

Toro

Toro Groundsmaster 3505-D Manual de usuario

Dennis

Dennis FT 610 Manual de usuario

AIRFORCE

AIRFORCE F-15 Gen 3 Manual de usuario

MTD

MTD 126-220-000 Manual de usuario

Toro

Toro 74806 Manual de usuario
