TEXI Treccia & Treccia C Matic operation manual

Operaon manual

High speed interlock

sewing machine

Treccia

Treccia C Mac

TEXI Treccia & Treccia C Matic operation manual

CONTENTS

1. IMPORTANT SAFETY INSTRUCTIONS ………………………………………………………….…….……………………..

2. LUBRICATION ………………………………………………………………………………………………….……..……..…...

3. HOW TO CHANGE OIL .................................................................................................................................................

4. HOW TO CHANGE OIL FILTER ....................................................................................................................................

5. LUBRICATE AND COOLING OF NEEDLES AND THREADS …………………………………………….……....…...……

6. HOW TO REPLACE THE NEEDLES …………………………………………………………………………………..……….

7. THREADING …………………………………………………………………………………………………………….….……..

8. ADJUSTING THREAD TENSION …………………………………………………………………………………...…….………

9. ADJUSTING NEEDLE THREAD TAKE-UP ……………………………………………………………………...…….………

10. LOOPER THREAD TENSION…………………………………………………………….……….……....…………………….

11. ADJUSTING PRESSER FOOT ....................................................................................................................................

12. ADJUSTING STITCH LENGTH ...................................................................................................................................

13. ADJUSTING DIFFERENTIAL FEED RATIO ................................................................................................................

14. ADJSUTING THE PRESSURE OF PRESSER FOOT .................................................................................................

15. POSITION OF THE LOOPER THREAD TAKE-UP…………………………………………………………………………..

16. ADJUSTMENT OF THE LOOPER *.............................................................................................................................

17. HEIGHT OF THE NEEDLES…………………………………………………………………………………………………..

18. SPREADER……………………………………………………………………………………………………………………….

19. THREADING DIAGRAM………………………………………………………………………………………………………….

TEXI Treccia & Treccia C Matic operation manual

1. IMPORT SAFETY INSTRUCTIONS

1. Transportation

(1). The machine packed with machine cover.

(2). Put the machine into a carton.

(3). Use a cart or two men's hands to move it.

2. Storage

(1). Use duster-cover to cover the machine when it doesn’t work.

(2). Avoid to storage the machine in the temperature more than 45°C

3. Working

The machine doesn’t work over 40°C.

4. Warning

1) Pay attention to this warning advice as follow

a. Working area is dangerous.

b. Never touch the needle if the machine is still running.

c. Be Careful if you feed fabric.

d. Do not insert your finger between needle and roller for transportation on fabric.

2) Pay attention to the warning sticker

a. Movable parts must be enclosed was guard when you operate.

b. Put out the plug from socket when you adjust thread.

TEXI Treccia & Treccia C Matic operation manual

2. LUBRICATION

1. Please oil with TERESSTIC T32 oil or its equivalent.

2. The lubricating oil has been drained from the machine before delivery. Remove screw (A), and fill the oil until the oil level

reaches between lines H and L of oil level gauge (Fig. 3, 4).

3. Be sure to check every day and refill the oil, if oil level is lower than line L of oil level gauge. When you begin operating the

machine, please check whether all the lubricating system is at normal condition.

3. HOW TO CHANGE OIL

1. Loosen Screw (1), drain all the oil from the tank, then fasten the screw (Fig. 5).

2. For extending life of the machine, change oil after the initial 4-week operation. After that, change oil every four months.

4. HOW TO CHANGE OIL FILTER

This machine is equipped with an oil filter, and the filter must be cleaned every mouth, replace the filter if necessary (Fig. 6).

* Before starting a brand-new machine or a machine which has not been used for more than a couple of week oiling

the needle bar.

5. LUBRICATE AND COOLING OF NEEDLES AND THREADS

Fill reservoir (1) and(2) with silicone oil to prevent the thread from breaking (Fig. 7).

6. HOW TO REPLACE THE NEEDLES

1. See specifications of the needles.

2. Loosen Screw (1), then pull out the used needles.

Insert the new needles into the holder holes as far as they can go,

and let the long groove of the needle face you (Fig. 8).

3. Fasten Screw (1).

Needle system: UY 128 GAS

TEXI Treccia & Treccia C Matic operation manual

7. THREADING

Follow the procedures shown in (Fig. 9) for threading. Wrong threading may cause thread breaking, skipping stitch, puckering

or unexpected sewing.

8. ADJUSTING THREAD TENSION

The tension of the thread should be adjusted according to:

1. The material and the thickness of the fabric being sewed;

2. The thread;

3. The needle gauge.

If you turn thread tension knob clockwise, thread will be tighter (Fig. 10).

If you turn it counter-clockwise. It will tie looser.

9. ADJUSTING NEEDLE THREAD TAKE-UP

When the needle bar is in the highest position, the top edge

of the Needle Thread Take-up (A) should remain horizontal

(Tip of part (a) of Needle Thread Take-up should be 52mm

from the center of screw (B)).

To tighten needle thread, move Needle Thread Take-up (A)

in the direction of (Y), and to release, move it in direction of

(X).

To adjust the position of the Take-up, loosen the Screw (B)

first (Fig. 10).

When this adjustments is not sufficient check thread tension

by moving Thread Eyelet (D) after loosing screw (C), When

is moved in the (Y) direction, thread is tighten and in (X)

direction, thread is loosened. The upper end of Eylet is 8

mm above the center screw (C). (Fig. 11)

10. LOOPER THREAD TENSION

To increas running out of thread, loosen screws of Eyelet (F) and (G) and move Eyelets forward, to decrease move them

backward. (Fig. 12 A)

When usuing woolly thread , move Eyelet (F) and (G) all the way to the front and do not pass the thread through Supple-

mentary Tension Disc (Fig. 12 B)

TEXI Treccia & Treccia C Matic operation manual

11. ADJUSTING PRESSER FOOT

Loosen Screw (1) and adjust Presser Foot (2) left and right to a proper position to let the needle may get into the center of

Presser Foot ‘s eyelet. After adjusting, tighten screw (1). (Fig. 13)

12. ADJUSTING STITCH LENGTH

Stitch length can be adjusted variably in range from 1.2 mm - 4.0 mm, or 6 - 18 stitches per inch.

1. Keep pressing the push button (A) with your left hand, then turn the hand-wheel with your right hand until your left hand

finger feels the push button lock in (Fig. 14).

2. Keep turning hand-wheel for an inquired stitch length, whose scale indicated on the hand-wheel must be aligned with, then

stop pressing the button (Fig. 15).

3. Rotate the hand-wheel counter clock-wide to increase the stitch length, and clockwise to decrease.

4. After adjusting stitch length the differential ratio will usually be changed too. So adjustment of differential ratio is required.

13. ADJUSTING DIFFERENTIAL FEED RATIO

The differential Feed Ratio of this machine is adjustable from 1:0.5 to 1:1.3 (Fig. 16).

To adjust the ratio, loosen the nut (2), move the indicator (1) up or down.

* To stitch the cloth, move the indicator (1) upward;

* To gather the cloth, move the indicator (1) upward;

14. ADJUSTING THE PRESSURE OF PRESSER FOOT

Pressure of the Presser Foot should be as light as possible, so that cloth can be fed and sewed smoothly.

TEXI Treccia & Treccia C Matic operation manual

15. POSITION OF THE LOOPER THREAD TAKE-UP

Lower the needle from the highest position and adjust, so that the thread comes off from the highest point of the looper Thre-

ad Take-up (I) when left needle reaches to the middle part of the looper .

The adjustment is made by loosening screw (j) (Fig. 18 & 19)

16. ADJUSTMENT OF THE LOOPER *

Please refer to the below table and Fig. 20.

* Only for Treccia (flat bed)

17. HEIGHT OF THE NEEDLES

When the tip of lLooper comes to the center of the left needle, Looper must

pass 0,5~1,0 mm above the upper end of eye—that is—the height of needle is

set on the basis of Looper. Both—needles and looper should be properly fixed.

TEXI Treccia & Treccia C Matic operation manual

18. SPREADER

When Spreader (A) moves from right to the left , clearance should be about 0,5 ~0,8 mm between left needle and tip (a) of

thread hooking point. When it comes to the extreme left, the clearance between the center of the left needle and tip (a) of

thread hooking point should be 4,5 ~5,5 mm (Fig. 22).

Adjust the height of Spreader (A) above the stitch palte to 9 ~11 mm (Fig. 23).

To adjuct the Spreader loose screw (B) and ( C) (Fig. 24).

19. THREADING DIAGRAM

TEXI Treccia & Treccia C Matic operation manual

20. CONVERSION CHART

MODEL

NEEDLE

CLAMP

NEEDLE

PLATE

MAIN

FEED

DOG

KIFF

FEED

DOG

PRESSER

FOOT

SPREAD-

LOOPER

NEEDLE

TEXI TRECCIA

10011608

10010834

10011466

10011470

10014315

10011662

10012780

UY 128

GAS

OPTIONAL

GAUGE 6.4 10011266

10011332

10011328

10011327

10014105

TEXI TRECCIA

C MATIC

10011608

10012291

10012837

10012863

10014315

10011662

10012780

UY 128

GAS

OPTIONAL

GAUGE 6.4 10011266

10010362

10012877

10014447

10014105
