Texas Instruments UCC25630-1EVM-291 Manual de usuario

Using the UCC25630-1EVM-291

User's Guide

Literature Number: SLUUBQ8B

August 2017–Revised January 2017

2SLUUBQ8B–August 2017–Revised January 2017

Submit Documentation Feedback

Table of Contents

Contents

1 Introduction......................................................................................................................... 5

2 Description.......................................................................................................................... 5

2.1 Typical Applications...................................................................................................... 5

2.2 Features................................................................................................................... 5

2.3 Using the EVM with UCC256302 ...................................................................................... 6

2.4 Using the EVM with UCC256303 ...................................................................................... 6

2.5 Using the EVM with UCC256304 ...................................................................................... 6

3 Performance Specifications................................................................................................... 7

4 UCC25630-1EVM-291 Schematic ............................................................................................ 8

5 Test Setup........................................................................................................................... 9

5.1 Test Equipment........................................................................................................... 9

5.2 Recommended Test Setup at No Load.............................................................................. 10

5.3 Recommended Test Setup With Load............................................................................... 11

6 List of Test Points .............................................................................................................. 11

7 List of Terminals ................................................................................................................ 12

8 Test Procedure................................................................................................................... 12

8.1 Equipment Shutdown .................................................................................................. 12

9 Performance Data and Typical Characteristic Curves ............................................................. 13

9.1 Efficiency................................................................................................................. 13

9.2 Load Regulation ........................................................................................................ 13

9.3 Output Turn On ......................................................................................................... 14

9.4 Load Transient ......................................................................................................... 15

9.5 Output Voltage Ripple.................................................................................................. 16

9.6 Burst Mode at Light Load.............................................................................................. 16

9.7 Voltage on Resonant Capacitor....................................................................................... 17

9.8 X-Cap Discharge........................................................................................................ 17

9.9 Bode Plot ................................................................................................................ 18

9.10 Switching Frequency vs. Load........................................................................................ 18

10 EVM Assembly Drawing and PCB Layout.............................................................................. 18

11 List of Materials ................................................................................................................. 21

Revision History.......................................................................................................................... 23

www.ti.com

SLUUBQ8B–August 2017–Revised January 2017

List of Figures

1 UCC25630-1EVM-291 Schematic......................................................................................... 8

2 UCC25630-1EVM-291 Recommended Test Setup for No Load..................................................... 10

3 UCC25630-1EVM-291 Recommended Test Setup With Load....................................................... 11

4 UCC25630-1EVM-291 Efficiency ........................................................................................ 13

5 UCC25630-1EVM-291 Load Regulation ................................................................................ 13

6 Output Turn On at 390 VDC with Full Load (10 A) .................................................................... 14

7 Output Turn On at 390 VDC with No Load ............................................................................. 14

8 No Load (0 A) to Full Load (10 A) Transient (Ch1 = Iout ; Ch3 = Vout)................................................ 15

9 Full Load (10 A) to No Load (0 A) Transient (Ch1 = Iout ; Ch3 = Vout)................................................ 15

10 Output Voltage Ripple at Vin = 390-V and 10-A Load ................................................................. 16

11 Burst Mode at Vin = 390-V and 100-mA Load (Ch3 = Vout ; Ch4 = LO).............................................. 16

12 Voltage on Resonant Capacitor (Vin = 390-V and 10-A Load, Ch1 = VRES ; Ch4 = LO)........................... 17

13 X-Cap Discharge ........................................................................................................... 17

14 Bode Plot at Vin = 390 V and 10 A Load ................................................................................ 18

15 Switching Frequency vs. Load (Vin = 390 V)............................................................................ 18

16 UCC25630-1EVM-291 Top Layer Assembly Drawing (Top View)................................................... 19

17 UCC25630-1EVM-291 Bottom Layer Assembly Drawing (Bottom View)........................................... 19

18 UCC25630-1EVM-291 Top Copper (Top View)........................................................................ 20

19 UCC25630-1EVM-291 Bottom Copper (Top View).................................................................... 20

List of Tables

1 UCC25630-1EVM-291 Specifications..................................................................................... 7

2 UCC25630-1EVM-291 Typical No Load and Standby Power ......................................................... 7

3 Test Points .................................................................................................................. 11

4 Terminals.................................................................................................................... 12

5 UCC25630-1EVM-291 List of Materials................................................................................. 21

WARNING

www.ti.com

4SLUUBQ8B–August 2017–Revised January 2017

Submit Documentation Feedback

List of Tables

General Texas Instruments High Voltage Evaluation (TI HV EVM) User Safety Guidelines

Always follow TI’s setup and application instructions, including use of all interface components within their

recommended electrical rated voltage and power limits. Always use electrical safety precautions to help

ensure your personal safety and those working around you. Contact TI's Product Information Center

http://support/ti./com for further information.

Save all warnings and instructions for future reference.

Failure to follow warnings and instructions may result in personal injury, property damage, or

death due to electrical shock and burn hazards.

The term TI HV EVM refers to an electronic device typically provided as an open framed, unenclosed

printed circuit board assembly. It is intended strictly for use in development laboratory environments,

solely for qualified professional users having training, expertise and knowledge of electrical safety

risks in development and application of high voltage electrical circuits. Any other use and/or

application are strictly prohibited by Texas Instruments. If you are not suitable qualified, you should

immediately stop from further use of the HV EVM.

1. Work Area Safety

1. Keep work area clean and orderly.

2. Qualified observer(s) must be present anytime circuits are energized.

3. Effective barriers and signage must be present in the area where the TI HV EVM and its interface

electronics are energized, indicating operation of accessible high voltages may be present, for the

purpose of protecting inadvertent access.

4. All interface circuits, power supplies, evaluation modules, instruments, meters, scopes and other

related apparatus used in a development environment exceeding 50Vrms/75VDC must be

electrically located within a protected Emergency Power Off EPO protected power strip.

5. Use stable and nonconductive work surface.

6. Use adequately insulated clamps and wires to attach measurement probes and instruments. No

freehand testing whenever possible.

2. Electrical Safety

As a precautionary measure, it is always a good engineering practice to assume that the entire EVM

may have fully accessible and active high voltages.

1. De-energize the TI HV EVM and all its inputs, outputs and electrical loads before performing any

electrical or other diagnostic measurements. Revalidate that TI HV EVM power has been safely

de-energized.

2. With the EVM confirmed de-energized, proceed with required electrical circuit configurations,

wiring, measurement equipment connection, and other application needs, while still assuming the

EVM circuit and measuring instruments are electrically live.

3. After EVM readiness is complete, energize the EVM as intended.

WARNING: WHILE THE EVM IS ENERGIZED, NEVER TOUCH THE EVM OR ITS ELECTRICAL

CIRCUITS AS THEY COULD BE AT HIGH VOLTAGES CAPABLE OF CAUSING ELECTRICAL

SHOCK HAZARD.

3. Personal Safety

1. Wear personal protective equipment (for example, latex gloves or safety glasses with side shields)

or protect EVM in an adequate lucent plastic box with interlocks to protect from accidental touch.

Limitation for safe use:

EVMs are not to be used as all or part of a production unit.

SLUUBQ8B–August 2017–Revised January 2017

Using the UCC25630-1EVM-291

User's Guide

SLUUBQ8B–August 2017–Revised January 2017

Using the UCC25630-1EVM-291

1 Introduction

This EVM, UCC25630-1EVM-291, is used to help evaluate the UCC256301 LLC control device in digital

TV SMPS, AC-DC power adapter, LED lighting, etc. applications and then to aid their design. The EVM is

a standalone LLC resonant half-bridge DC-DC power converter. The EVM, UCC25630-1EVM-291, can be

used as it is delivered without additional work to evaluate an LLC resonant half-bridge DC-DC converter.

This user’s guide provides basic evaluation instruction from a viewpoint of system operation in standalone

LLC resonant half-bridge DC-DC power converter.

2 Description

UCC25630-1EVM-291 is an EVM for an LLC resonant half-bridge DC-DC power converter with LLC

controller UCC256301. UCC25630-1EVM-291 accepts DC line input from 340 VDC to 410 VDC, AC input

voltage from 85 VAC to 264 VAC, and a nominal output of 12 VDC with a full-load output power of 120 W,

or a full output current of 10 A.

NOTE: This EVM does not have an input fuse, and relies on an input current limit from its input

voltage source.

2.1 Typical Applications

• Digital TV SMPS

• AC-DC Power Adapters

• Enterprise Server Applications

• LED Lighting Applications

2.2 Features

• Hybrid Hysteretic Controlled LLC Resonant Half-Bridge DC-DC Power Conversion

• DC Line Input from 340 VDC to 410 VDC

• AC Input Voltage from 85 VDC to 264 VAC

• Regulated 12-VDC Output, from No-Load to Full-Load

• Full-Load Power of 120 W, or Full-Load Current of 10 A

• High Efficiency

• Optimized Low Power Features Enable Extremely Low Standby Power

• Advanced Burst Mode with Adaptive Threshold

• Improved Capacitive Region Avoidance Scheme

• Adaptive Dead-Time

• X-Capacitor Discharge

• Over Temperature, Output Over Voltage, and Three Level Over Current Protections

• Test Points to Facilitate Device and Topology Evaluation

Description

www.ti.com

6SLUUBQ8B–August 2017–Revised January 2017

Submit Documentation Feedback

Using the UCC25630-1EVM-291

2.3 Using the EVM with UCC256302

To use this EVM with UCC256302:

• Replace U1 with UCC256302

• Remove D1, D2

• Connect TP10 to TP5

2.4 Using the EVM with UCC256303

UCC25630-1EVM-291 is designed for UCC256301. With a slightly modification, this EVM can be used for

UCC256303. To use this EVM with UCC256303:

• Replace U1 with UCC256303

• Remove R11, D4

• Connect pin1 (HV) of U1 to PGND

• Connect external bias (11.25V - 26V) to TP21

2.5 Using the EVM with UCC256304

To use this EVM with UCC256304:

• Replace U1 with UCC256304

• Change R4 to 44.2 kΩ

www.ti.com

Performance Specifications

SLUUBQ8B–August 2017–Revised January 2017

Using the UCC25630-1EVM-291

3 Performance Specifications

Table 1. UCC25630-1EVM-291 Specifications

PARAMETER TEST CONDITIONS MIN TYP MAX UNITS

INPUT CHARACTERISTICS

DC voltage range 340 390 410 VDC

AC voltage range 85 264 VAC

AC voltage frequency 47 63 Hz

Input DC UVLO On 320 VDC

Input DC UVLO Off 140 VDC

Input DC current Input = 340 VDC, full load = 10 A 0.383 A

Input DC current Input = 390 VDC, full load = 10 A 0.331 A

Input DC current Input = 410 VDC, full load = 10 A 0.315 A

OUTPUT CHARACTERISTICS

VOUT Output voltage No load to full load = 10 A 12 VDC

IOUT Output load current 340 to 410 VDC 10 A

Output voltage ripple 390 VDC and full load = 10 A 130 mVpp

SYSTEM CHARACTERISTICS

Switching frequency 53 160 kHz

Peak efficiency 390 VDC, load = 8 A 92.9%

Operating temperature Natural convection 25 ºC

Table 2. UCC25630-1EVM-291 Typical No Load and Standby Power

VIN = 390 V

INPUT POWER (mW) OUTPUT POWER (mW) POWER LOSS (mW)

39.7 0 39.7

163.7 103.0 60.6

295.0 201.2 93.8

421.7 299.0 122.7

548.0 401.6 146.4

674.0 498.6 175.4

GBU8J-BP

1uF

MURA160T3G

0.47µF

VCC

BLK 4

FB 5

ISNS

VCR

LL/SS

LO 10

GND 11

RVCC

HB 14

HO 15

HS 16

UCC25630-1DDB

470µF

C20

470µF

C21

470µF

C22

470µF

C23

TP4

TP1

TP3

TP5

TP2

TP10

TP7

TP12

TP11

TP23

HS2

HS1

PGND

SGND

PGND

EARTH

PGND

HS3

HS4

SGND

SPW20N60CFD

10pF

C29

DNP

0.047µF

C28

10.0k

R22

SGND

PGND

147k

R25

16.9k

R26

SGND

2 3

TLVH431AQPK

6.04k

R20

2.2

R16

2.2µF

C18

VO618A-3

42.2k

R17

10.0k

R18

PGND

3.9pF

C13

2.2µF

C12

4.7µF

C15

4.99M

140k

PGND

BLK

PGND

0.022µF

PGND

TP19

120µF

C16

0.15µF

C17

220pF

TP6

RV1

MOV-14D621K

12V Vout

340V - 410V DC Input

85V - 264V AC Input

TP8

TP9 22µF

C24

0.022µF

1.5 µF

402k

R15

732k

R14

357

R13

PGND PGND

1.65k

R10

1.65k

R24

TP17

TP18

10.0

5.11k

10.0M

R28

TP13

60V

6.04k

R23

NC 8

NC 11

150pF

C11

TP20

TP16

TP15

VO618A-3

PGND

2.00k

R19

SGND

External disable

22µF

C25

22µF

C26

22µF

C27

STPS41H100CTY

ES1JAF

47µF

10.0M

R27

10.0M

R12

10.0M

R29

TP22

1.65k

R11

3300pF

C30

DNP

1.00

R30

1N4148W-7-F

TP14

TP21

4.7µF

C14

R32

10pF

C19

DNP

10.0k

R21 D10

MMSZ5234B-7-F

0.015µF

C10

150pF

1.00

R31

2NC 5

NC 6

50µHL1

UCC25630-1EVM-291 Schematic

www.ti.com

8SLUUBQ8B–August 2017–Revised January 2017

Submit Documentation Feedback

Using the UCC25630-1EVM-291

4 UCC25630-1EVM-291 Schematic

Figure 1. UCC25630-1EVM-291 Schematic

www.ti.com

Test Setup

SLUUBQ8B–August 2017–Revised January 2017

Using the UCC25630-1EVM-291

5 Test Setup

5.1 Test Equipment

DC Voltage Source: capable of 340 VDC to 410 VDC, adjustable, with minimum power rating 200 W, or

current rating not less than 1 A, with current limit function. The DC voltage source to be used should meet

IEC60950 reinforced insulation requirement.

AC Voltage Source: capable of single-phase output AC voltage 85 VAC to 264 VAC, 47 Hz to 63 Hz,

adjustable with minimum power rating 100 W. The AC voltage source to be used should meet IEC60950

reinforced insulation requirement.

DC Digital Multimeter: One unit capable of 0-VDC to 450-VDC input range, four digit display preferred;

and one unit capable of 0-VDC to 20-VDC input range, four digit display preferred.

Output Load: DC load capable of receiving 0 VDC to 20 VDC, 0 A to 15 A, and 0 W to 200 W or greater,

with the capability to display things such as load current and load power.

Current Meter: DC, optional in case the load has no display, one unit, capable of 0 A to 15 A. If you want

to measure standby power, the current meter needs to have a time averaging function.

Oscilloscope: capable of 500-MHz full bandwidth, digital or analog, if digital, 5 Gs/s or better.

Fan: 200-LFM to 400-LFM forced air cooling is recommended, but not required.

Recommended Wire Gauge: capable of 15 A, or better than #14 AWG, with the total length of wire less

than 8 feet (4 feet input and 4 feet return).

Test Setup

www.ti.com

10 SLUUBQ8B–August 2017–Revised January 2017

Submit Documentation Feedback

Using the UCC25630-1EVM-291

5.2 Recommended Test Setup at No Load

Figure 2 shows the equipment setup for testing at no load. It is important to note that in this setup, current

drawn by the voltage meter does not flow through the current meter.

Also, do not connect oscilloscope probes or any other sensing devices to the unit while measuring no-load

power, as these can provide a path for common mode current to flow. This causes an error in the

measurements.

During the no-load test, the current meter should be set to long-averaging mode and a few minutes should

be allowed for the reading to be accurate. Additionally, an appropriate current scale factor should be used.

Figure 2. UCC25630-1EVM-291 Recommended Test Setup for No Load

Tabla de contenidos

Otros manuales de Placa madre de Texas Instruments

Texas Instruments

Texas Instruments DS16EV51-AEVKD Manual de usuario

Texas Instruments

Texas Instruments LOGIC PD ZOOM OMAP-L138 Manual de usuario

Texas Instruments

Texas Instruments TLV767EVM-014 Manual de usuario

Texas Instruments

Texas Instruments TSW1200EVM Manual de usuario

Texas Instruments

Texas Instruments AFE5832 Manual de usuario

Texas Instruments

Texas Instruments BQ2573 Series Manual de usuario

Texas Instruments

Texas Instruments TPA3156D2EVM Manual de usuario

Texas Instruments

Texas Instruments LP5012EVM Manual de usuario

Texas Instruments

Texas Instruments TUSB1044 Manual de usuario

Texas Instruments

Texas Instruments ADS4449 EVM Manual de usuario

Texas Instruments

Texas Instruments TPS51113 Manual de usuario

Texas Instruments

Texas Instruments TUSB3410UARTPDK Manual de usuario

Texas Instruments

Texas Instruments TPA0213 Manual de usuario

Texas Instruments

Texas Instruments AN-1993 LM3406HV Manual de usuario

Texas Instruments

Texas Instruments BQ25710EVM-017 Manual de usuario

Texas Instruments

Texas Instruments ADS62P EVM Series Manual de usuario

Texas Instruments

Texas Instruments TPS65986EVM Manual de usuario

Texas Instruments

Texas Instruments DAC7811EVM Manual de usuario

Texas Instruments

Texas Instruments bq27421 EVM Manual de usuario

Texas Instruments

Texas Instruments bq24165EVM-720 Manual de usuario

Texas Instruments

Texas Instruments TPS25921XEVM-637 Manual de usuario

Texas Instruments

Texas Instruments DRV8428E Manual de usuario

Texas Instruments

Texas Instruments ADS7861 EVM Manual de usuario

Texas Instruments

Texas Instruments CC1175EM Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
