TerraTec Aureon 5.1 USB MK II Manual de usuario

Quick reference (English)

Version: 25.10.04

CE Declaration

We:

TerraTec Electronic GmbH, Herrenpfad 38, D-41334 Nettetal, Germany

hereby declare that the product:

SoundSystem Aureon 5.1 USB MK II

to which this declaration refers are in compliance with the following standards or standardiz-

ing documents:

1. EN 55022 Class B

2. EN 50082-1

The following are the stipulated operating and environmental conditions for said compliance:

residential, business and commercial environments and small-company environments.

This declaration is based on:

Test report(s) of the EMC testing laboratory

The information in this document is subject to change without notice and shall not be deemed as a warranty by the

seller. No warranties, express or implied, are made with regard to the quality, suitability or accuracy of this docu-

ment. The manufacturer reserves the right to change the contents of this document and/or the associated products

at any time without the provision of prior notice to specific persons or organizations. The manufacturer shall not be

held liable for damages of any kind arising from the use, or the inability to use this product or its documentation,

even if the possibility of such damage is known. The information in this document is subject to copyright. All rights

are reserved. No part of this manual may be reproduced or transmitted in any form or for any purpose without the

express written permission of the copyright holders. Product and brand names contained in this document are used

for identification purposes only. All registered trademarks, product designations or brand names used in this

document are the registered property of their respective owners.

2 Aureon 5.1 USB MK II (English)

Contents

1. Introduction ...................................................................................................................... 4

1.1 Package Content ............................................................................................................ 4

1.2 Layout of the Aureon 5.1 USB MK II..................................................................................5

2. Installation ....................................................................................................................... 6

2.1 Connecting the Aureon 5.1 USB MK II to the computer.................................................... 6

2.2 Drivers? ......................................................................................................................... 6

3. Control Panel .................................................................................................................... 8

3.1 Play................................................................................................................................ 8

3.2 Record ........................................................................................................................... 8

3.3 Speakers ....................................................................................................................... 9

3.4 Misc............................................................................................................................... 9

4. Software ..........................................................................................................................10

Support ...............................................................................................................................10

Aureon 5.1 USB MK II (English) 3

1. Introduction

1.1 Package Content

Start by making sure that nothing is missing.

The scope of delivery includes at least the following:

1 USB sound card TerraTec SoundSystem Aureon 5.1 USB MK II·

· 1 USB cable

1 software CD

1 TerraTec registration card with the product serial number

1 customer service card

Please return the registration card to us at the earliest possible opportunity or register online

at http://www.terratec.com/register.htm. This is important for support and hot-

line services.

4 Aureon 5.1 USB MK II (English)

1.2 Layout of the Aureon 5.1 USB MK II

defgh

d– USB port

e– Analog stereo input (for 3.5 mm jack)

f– Analog stereo output "Center LFE" (for 3.5 mm jack)

g– Analog stereo output "Rear" (for 3.5 mm jack)

h– Analog stereo output "Front" (for 3.5 mm jack)

i– Analog headphone output (for 3.5 mm jack)

j– Analog microphone input (for 3.5 mm jack)

k– Digital S/PDIF input (with included Toslink adapter)

l– Digital S/PDIF output (with included Toslink adapter)

Aureon 5.1 USB MK II (English) 5

2. Installation

2.1 Connecting the Aureon 5.1 USB MK II to the computer

To connect the Aureon 5.1 USB MK II to your computer, you need a free USB Series A port:

It makes no difference whether the port is a USB 1.1 or USB 2.0 port; the unit functions equally

well when attached to either.

The Aureon 5.1 USB MK II is hot-pluggable, which means that you can connect or disconnect

the unit at any time while the computer is running.

2.2 Drivers?

When connected to your system for the first time, the Aureon 5.1 USB MK II installs a driver

that is integrated into Windows 2000 and Windows XP; this process is completely automatic.

Insert the Aureon 5.1 USB MK II software CD and install the Control Panel using the Autorun

feature. Double-click AUTORUN.EXE in the root folder of the Aureon 5.1 USB MK II CD and

select the "Control Panel" menu item.

6 Aureon 5.1 USB MK II (English)

Don't panic, everything's going to be fine:

this message is displayed for all hardware and software components that have not been

certified by Microsoft. It has no bearing whatsoever on the quality of the components, how-

ever. In some cases, 100% compliance with Microsoft's criteria may even result in a loss of

performance. In addition, a new certification is necessary every single driver update, so they

can't simply be made available on the Internet as soon as it's finished.

We therefore do not recommend canceling the installation at this point. We subject all of our

products to a rigorous test program, so all functions have been tested in all of the supported

operating systems. You can therefore continue the installation with absolute peace of mind.

Aureon 5.1 USB MK II (English) 7

3. Control Panel

3.1 Play

Use this to adjust the volume of the individual signal sources; a master fader controls the

volume from all sources.

You can also silence the master volume or individual sources by pressing the MUTE button

underneath the corresponding fader.

Adjust the position of the stereo image with the balance faders below the level faders.

3.2 Record

In the Record window you can set the signal source that you want to record and its volume.

S/PDIF is a digital signal that does not allow volume control.

The "AGC" button activates automatic gain control for microphone input. This function helps

you to avoid input interference and clipping, or to boost weak signals.

8 Aureon 5.1 USB MK II (English)

3.3 Speakers

Set the speaker configuration that you want use here.

You can activate every single speaker separately here to test them for correct wiring and

function. If you click on a speaker to activate it, you will hear static from that speaker.

Under each speaker is a label. The first digit (1-6) indicates the output jack of the Aureon 5.1

USB MK II to which that speaker should be connected. The other part of the display (+/- 20

dB) is a readout of the volume dials which are next to each speaker.

You can raise or lower the volume of each separate speaker by clicking the corresponding

volume dial and moving the mouse forwards or back. This allows you to match the surround

sound perfectly to your room and speaker system.

Clicking the "Reset Gain" button resets all values to 0dB.

3.4 Misc

Aureon 5.1 USB MK II (English) 9

10 Aureon 5.1 USB MK II (English)

Settings

You can save the settings made in the control panel as profiles and load the profiles.

Autostart

Automatically launches the Control Panel when the operating system is booted.

Colors

You can set the colors of the Control Panel to your taste here.

Language selection

The display language of the Control Panel can be changed with the drop-down menu.

About

This window shows the driver and control panel version installed on your computer.

4. Software

Bundle software

The bundled software supplied with the card can be easily started with the startup function.

Double-click AUTORUN.EXE in the root folder of the Aureon 5.1 USB MK II CD and select the

"Software" menu item.

Support

For more information on the TerraTec hotline, our BBS and Internet presence, please refer to

the included customer service card.
