Fulfill IP Speaker Paging, Hand-Free Intercom

And BGM Functions

User ManualUser ManualUser ManualUser Manual

Revision History

v1.04

IP Speaker Module/ Box

Table of Contents

Foreword 0

Part I About This Manual 4

................................................................................................................................... 41 Safety Instructions & Declaration

................................................................................................................................... 52 Notice Sign

................................................................................................................................... 53 Copyright

Part II System Overview 5

................................................................................................................................... 61 Quick Start

Part III Hardware Installation 8

................................................................................................................................... 81 IPSM-2C20/IPSM-2C20M

.......................................................................................................................................................... 10Front Panel

.......................................................................................................................................................... 11Rear Panel

................................................................................................................................... 122 IPBX-2C20/IPBX-2C20M

.......................................................................................................................................................... 13Front Panel

.......................................................................................................................................................... 14Rear Panel

................................................................................................................................... 143 Bridge Amp Output

Part IV Configuration-Web Browser 15

................................................................................................................................... 151 Getting Started

................................................................................................................................... 162 IP & Network

.......................................................................................................................................................... 16IP Information

.......................................................................................................................................................... 16IP Address

.......................................................................................................................................................... 17Network Bandwidth And Bitrate

................................................................................................................................... 183 Login/Logout

................................................................................................................................... 194 Setup

.......................................................................................................................................................... 19Basic Setting

.......................................................................................................................................................... 23Device

.......................................................................................................................................................... 26Function Libraries

......................................................................................................................................................... 26Commend (String)

......................................................................................................................................................... 27DSPElement Adjust

......................................................................................................................................................... 29DSPElement Read

......................................................................................................................................................... 30Contact Out

......................................................................................................................................................... 32User Fault

......................................................................................................................................................... 33Rocord

......................................................................................................................................................... 33Multi Function

.......................................................................................................................................................... 34Audio Matrix

......................................................................................................................................................... 36How -to: Use RAC for music/source selection and level control

.......................................................................................................................................................... 38Media Setting

......................................................................................................................................................... 38Management

......................................................................................................................................................... 40Record

......................................................................................................................................................... 42Background Music

......................................................................................................................................................... 43Add Audio Files/Creat playlist for BGM

3Contents

.......................................................................................................................................................... 44I/O Control

......................................................................................................................................................... 45Call/Hang Up

......................................................................................................................................................... 46Message Call

......................................................................................................................................................... 46Message Play/Stop

......................................................................................................................................................... 47Contact Out

......................................................................................................................................................... 47Command(String)

......................................................................................................................................................... 47Multi Function

......................................................................................................................................................... 48Record

......................................................................................................................................................... 48User Fault

......................................................................................................................................................... 49DSPElement Adjust

......................................................................................................................................................... 49Music Play/Stop

.......................................................................................................................................................... 49Account Manager

.......................................................................................................................................................... 51Third Party

......................................................................................................................................................... 52Call/Hang Up

......................................................................................................................................................... 52DSPElement Adjust

......................................................................................................................................................... 53DSPElement Read

......................................................................................................................................................... 53Net StreamSelect

......................................................................................................................................................... 54Record

.......................................................................................................................................................... 55Scheduler

......................................................................................................................................................... 55Add/Edit/Delete

................................................................................................................................... 585 Update

.......................................................................................................................................................... 58Firmware

.......................................................................................................................................................... 58Configuration

.......................................................................................................................................................... 58Reboot

................................................................................................................................... 596 Status

.......................................................................................................................................................... 59TERRA System

.......................................................................................................................................................... 59Control Calibrate

.......................................................................................................................................................... 60Log File

................................................................................................................................... 617 DSP Function

.......................................................................................................................................................... 62Input

.......................................................................................................................................................... 63Hi/Lo Pass PEQ 8 Band

.......................................................................................................................................................... 64Major Audio Matrix

.......................................................................................................................................................... 64Ducker

.......................................................................................................................................................... 65Selector

.......................................................................................................................................................... 66Comp/Limiter

.......................................................................................................................................................... 67Output

................................................................................................................................... 688 About-Copy Right

Part V Techinical Data 68

................................................................................................................................... 681 IPSM-2C20/IPSM-2C20M

................................................................................................................................... 692 IPBX-2C20/IPBX-2C20M

................................................................................................................................... 703 YMC0101-005 MIC capsule

Index 0

1 About This Manual

This user manual will explicitly describe the hardware installation and the software configuration,

provides installers and users the necessary information to setup and configure the system.

Firmware version:

Model

Version

IPSM-2C20, IPBX-2C20

v0.0.0.1

1.1 Safety Instructions & Declaration

Do not expose the device to extreme temperatures, direct sunlight, humidity, or dust, which could

cause fire or electrical shock hazard.

Keep away water or other liquids from the device. Otherwise fire or electrical shock may result.

Connect the power cord only to an AC outlet of the type stated in this owner's manual or as marked

on the unit. Otherwise fire and electrical shock hazard results.

Avoid touching power plugs with wet hands. Doing so is a potential electrical shock hazard.

Take care for correct polarity when operating the device from a DC power source. Reversed polarity

may cause damage to the unit or the batteries.

Avoid placing heavy objects on power cords. A damaged power cord is a fire and electrical shock

hazard.

Do not cut, scratch, bend, twist, pull, or heat the power cord. A damaged power cord is a fire and

electrical shock hazard. Ask your TERRACOM dealer for replacement.

Turn off immediately the unit, remove the power cord from the AC outlet and consult your TERRACOM

dealer in any of the following circumstances:

oSmoke, odor, or noise getting out of the unit.

oForeign objects or liquids get inside the device.

oThe unit has been dropped or the shell is damaged.

oThe power cord is damaged.

oIf you continue using the device, fire and electrical shock may result.

Do not drop or insert metallic objects or flammable materials into the unit as this may result in fire and

electrical shock.

Do not remove the device's cover, as there are exposed parts inside carrying high voltages that may

cause an electrical shock. Contact your TERRACOM dealer if internal inspection, maintenance, or

repair is necessary.

Do not try to make any modifications to the device. This is a potential fire and electrical shock hazard.

Avoid the device's ventilation slots to be blocked. Blocking the ventilation slots is a potential fire

hazard.

To prevent the unit from falling down and causing personal injury and/or property damage, avoid

installing or mounting the unit in unstable locations.

Leave enough space above and below the unit to provide good ventilation of the device. If the airflow is

About This Manual 5

not adequate, the device will heat up inside and may cause a fire.

Operate the device in an environment with a free-air temperature of between -5ºC ~ 55ºC (23ºF ~

131ºF).

Turn off all audio equipment when making any connections to the device, and make sure to use

adequate cables.

Do not use benzene, thinner, or chemicals to clean the device. Use only a soft, dry cloth.

If the device is moved from a cold place (e.g., overnight in a car) to a warmer environment,

condensation may form inside the unit, which may affect performance. Allow the device to acclimatize

for about one hour before use.

1.2 Notice Sign

There are two types of signs can be used in this manual. The type is closely related to the effect that

may be caused if it is not observed.

Note: Containing additional information.

Caution: The equipment or the property can be damaged, or persons can be lightly injured if the

alert is not observed.

1.3 Copyright

means, electronic, mechanical, photocopying, or otherwise, without the prior written permission of the

publisher. The content and illustrations are subject to change without prior notice.

2 System Overview

IPSM-2C20/ IPBX-2C20 application in system

The TERRACOM IP speaker can be utilized within a variety of applications for real time

broadcasting, intercommunication, music playback etc. In addition, IPSM-2C20/ IPBX-2C20

supports user to control power switch of light, door, curtain and air condition.

System diagram

2.1 Quick Start

Power connection

The IP speaker can be powered by PoE+ switch via CAT5/6 cable, or/and the IP speaker can also

be powered by an external power supply adapter like PSU65-27 or PSU36-24.

Network connection

Use a straight CAT5/6 cable to link your PC network card to the IP speaker. Open your favorite web

System Overview 7

browser (we recommend Google Chrome or Mozilla Firefox). Each IP speaker is shipped from the

factory with a default IP address of 192.168.100.49, type the default IP address into the address bar.

You will be asked for a login (By default: admin). After login, you can start to program the settings of

IP speaker.

Assign IP address to IP speaker

Change the IP address of your device at "

Machine > Setting > IP". After the settings have

been saved, please plug out & plug in the

Ethernet cable of IP speaker to reboot the IP

setting.

You might need to change the IP settings of your PC network card to be in the same network mask

as the new IP address of your IP speaker. To avoid the conflict issues when connecting multiple IP

speakers with the same IP address, be sure to only connect one IP speaker at a time to the

Ethernet switch when assigning IP addresses.

SIP Setting

With SIP server

The audio streaming can be done using a SIP

Server. Go to "Machine > Setting > SIP" and

enter the settings of your SIP server.

Without SIP server

If you don’t have a SIP server, please follow

the settings as below,

oFirewall Traversal Mode: TERRA Net

oSIP Port: 5060

oRTP Port: 6912

3 Hardware Installation

3.1 IPSM-2C20/IPSM-2C20M

Front panel

Rear panel

Modules of IPSM-2C20 are equipped with 1 channel in 2 channels in 20W with 8 ohm loudspeaker, and

PoE+ power (If PoE+ is not available, 24VDC power adapter will supply higher power). With Power over

Ethernet (PoE+), both audio control and power can be flowed over the standard female RJ45 Ethernet

Hardware Installation 9

connector, giving a cost effective way to used as the SIP endpoint of paging, intercom, mass notification

system and minimizing the number of cables. The IPSM-2C20 is designed to embed in TERRACOM's IP

speaker. To fulfill hands-free intercom and monitoring, the IPSM-2C20M is equipped with a built-in

microphone interface. The YMC0101-005 mic capsule could be connected to this microphone interface.

The IPSM have 3 control inputs for level control and source selection using the RAC 5/8 controller, 1

relay contact output can be programmed to control an external device via TerraManager. To configure,

control, monitor the IP speakers in real-time, this can be easily done through your favorite web browser

interface, making the management even the most complex environments simpler than ever. The

remarkable features include event management, volume control, paging, intercom, music streaming,

routing, logic control, 3rd party control, DSP control, monitoring, etc.

The 20W x 2CH amp output is applied for 8 ohm speaker. However, it can be bridged to 1 channel

40W for 4 ohm speaker by hand making.

See the following table listed the supported audio codec by IPSM-2C20

Function

Supported Audio Encoders/ Decoders

SIP

G.711 ulaw, G.711 alaw, G.722, G.726-32, G.727-32,

PCM16K, WAVE(decode only), MP3(decode only)

SHOUTcast/ Icecast

(decode only)

AAC, AAC+, MP3

Stream

G.711 ulaw, G.711 alaw, G.722, PCM16K, WAVE, MP3

Record

(encode only)

WAVE, MP3

Ordering information

Models

Model Description

IPSM-2C20

IP Speaker Module/2 ch/20W w/PoE+

IPSM-2C20M

IP Speaker Module/2 ch/20W w/mic in w/PoE+

IPSM-2C20P36

IP Speaker Module/2 ch/20W w/PSU36-24

IPSM-2C20P65

IP Speaker Module/2 ch/20W w/PSU65-27

IPSM-2C20MP36

IP Speaker Module/2 ch/20W w/mic in w/PSU36-24

IPSM-2C20MP65

IP Speaker Module/2 ch/20W w/mic-in w/PSU65-27

YMC0101-005

Mic Capsule w/40cm lead & connector

All IPSM-2C20 models are not shipped with the mic capsule, please order YMC0101-005 mic

capsule if necessary.

3.1.1 Front Panel

1. Ethernet POE+ port

Connect the IP speaker to Ethernet network via RJ45 plug, CAT5/6 cable, allowing the system to

be configured, controlled and monitored via web browser.

In addition, the IP speaker can use the power(20W) from PoE+ (PoE+ switch is required).

2. LED power light

Display the power of IPSM-2C20 is on or off.

3. Power Input

If the IP speaker require higher power or PoE+ power isn't available, external PSU power adapter

(24VDC/ 2A) can supply power.

External power adapter ordering information: "PSU65-27" supplies 65W and "PSU36-24"

supplies 36W for IP speaker.

4. Micro SD card interface:

Micro SD Card interface and internal 200MB storage of IPSM-2C20 are for music message/recording

storage.

The micro SD card must be formatted to FAT32 to read (max. 512GB)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Oradores de Terracom

Terracom

Terracom IPSM-1C40 Manual de usuario

Manuales populares de Oradores de otras marcas

argon audio

argon audio IE20 Manual de usuario

Denon

Denon SC-N7 Manual de usuario

Gemline

Gemline Ace 3952 Manual de usuario

Focal

Focal ON WALL 300 Manual de instrucciones

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manual de usuario

SoundLogic

SoundLogic BCCS-6/6395 Manual de usuario

Peavey

Peavey DTH 218 Manual de usuario

Avantree

Avantree Pluto Air Manual de usuario

Morel

Morel Integra Series INTEGRA OVATION 4 Manual de usuario

Oppo

Oppo SONICA Manual de usuario

Bose

Bose SoundLink Wireless Music System Manual de usuario

Rocksteady

Rocksteady Stadium Manual de usuario

Bowers & Wilkins

Bowers & Wilkins 4 Manual de usuario

Sonance

Sonance SONOS OUTDOOR Series Manual de usuario

Electro-Voice

Electro-Voice EVID FM4.2 Manual de usuario

Pioneer

Pioneer XW-HTD630 Manual de usuario

Onn

Onn BWA16AA002 Manual de usuario

HP GL313AA - USB Speakers PC Multimedia Manual de usuario
