Terex Genie Superlift Advantage SL-5 Guía de inicio rápido

Parts Manual

Serial Number Range

Parts & Service Manual

Part No. 32283

Rev A6

August 2007

Serial Number Range

Superlift

Advantage

from serial number

9594-101 to 5501-15094

and from SLA02-15095

to SLA04-25258

Parts and Service Manual - First

Part No. 32283 Genie Superlift Advantage

July, 2007

Table of Contents

Introduction

Important Information...................................................................................................... ii

Section One Safety Rules

General Safety Rules .................................................................................................... iii

Section Two Specifications

Superlift 5 ................................................................................................................................. 2 - 1

Superlift 10 ................................................................................................................................. 2 - 1

Superlift 15 ................................................................................................................................. 2 - 1

Superlift 20 ................................................................................................................................. 2 - 1

Superlift 25 ................................................................................................................................. 2 - 1

Load Handling Attachments ................................................................................................................... 2 - 1

Bolt Torque Specification ....................................................................................................................... 2 - 3

Section Three Scheduled Maintenance Inspections

Introduction ............................................................................................................... 3 - 1

Table A ................................................................................................................................. 3 - 2

Table B ................................................................................................................................. 3 - 2

Table C ................................................................................................................................. 3 - 2

Maintenance Inspection Report ............................................................................................................. 3 - 3

Section Four Scheduled Maintenance Procedures

Introduction ............................................................................................................... 4 - 1

A-1 Inspect the Operator's Manual .................................................................................. 4 - 2

A-2 Inspect the Decals and Placards .............................................................................. 4 - 2

A-3 Inspect for Damage, Loose or Missing Parts ............................................................ 4 - 2

A-4 Check the Winch Operation ...................................................................................... 4 - 3

A-5 Inspect the Columns for Damage ............................................................................. 4 - 3

A-6 Inspect the Cable and Cable Pulleys ........................................................................ 4 - 3

A-7 Check the Mast for Proper Sequencing .................................................................... 4 - 4

A-8 Inspect the Casters and Wheels ............................................................................... 4 - 4

B-1 Inspect the Column Hold Down System ................................................................... 4 - 5

Parts and Service Manual - First Edition

Genie Superlift Advantage Part No. 32283

Section Four Scheduled Maintenance Procedures, cont.

B-2 Inspect All Welds ...................................................................................................... 4 - 5

B-3 Clean the Columns ................................................................................................... 4 - 5

B-4 Inspect and Lubricate the Winch............................................................................... 4 - 6

B-5 Inspect and Lubricate the Rotating Barrel Handler ................................................... 4 - 6

C-1 Lubricate the Casters and Wheels ............................................................................ 4 - 7

C-2 Inspect the Mast Assembly for Wear ........................................................................ 4 - 7

C-3 Replace the Winch Friction Disks ............................................................................. 4 - 8

C-4 Inspect the Safety Brake System.............................................................................. 4 - 8

C-5 Inspect the Painted Surfaces .................................................................................... 4 - 9

Section Five Troubleshooting Flow Charts

Introduction ............................................................................................................... 5 - 1

1 Mast Will Not Sequence Properly ............................................................................. 5 - 2

2 Carriage Will Not Raise, But Winch Will Operate ...................................................... 5 - 3

3 Winch Will Not Operate ............................................................................................ 5 - 4

Section Six Repair Procedures

Introduction ............................................................................................................... 6 - 1

Base Assembly

1-1 How To Remove the Base - Standard Base ............................................................. 6 - 2

1-2 How To Remove the Base - Straddle Base .............................................................. 6 - 3

Mast Assembly

2-1 How to Disassemble the Mast Assembly .................................................................. 6 - 4

2-2 How to Replace the Lifting Cable .............................................................................. 6 - 5

2-3 How to Replace a Lifting Pulley - Mast Installed ....................................................... 6 - 6

Winches

3-1 How To Disassemble the Winch - Single Speed ....................................................... 6 - 7

3-2 How To Disassemble the Winch - Two Speed .......................................................... 6 - 9

TABLE OF CONTENTS

Parts and Service Manual - First

Part No. 32283 Genie Superlift Advantage

August 2007

Section Seven Service Parts

How To Order Parts .................................................................................................. 7 - 1

Figure 7-A Decals and Paint (Rev A; August 2007) ................................................................... 7 - 2

Figure 7-B Number 1 Mast Attached Parts (Rev A; August 2007) .............................................. 7 - 6

Figure 7-C Standard Base Components (Rev A; August 2007) .................................................. 7 - 8

Figure 7-D Straddle Base Components (Rev A; August 2007) ................................................. 7 - 12

Figure 7-E Mast Components - View 1 (Rev C; October 2006) ................................................ 7 - 14

Figure 7-F Mast Components - View 2 (Rev B; August 2007) .................................................. 7 - 16

Figure 7-G Mast Components - Pulleys and Cable (Rev C; August 2007)................................ 7 - 18

Figure 7-H Load Handling Attachments - Forks ........................................................................ 7 - 22

Figure 7-I Load Handling Attachments - Boom, Pipe Cradle and Load Platform ..................... 7 - 24

Figure 7-J Load Handling Attachments - Vertical Barrel Stacker ............................................. 7 - 26

Figure 7-K Load Handling Attachments - Rotating Barrel Handler ............................................ 7 - 28

Figure 7-L Single Speed Winch (Rev B; July 2007) ................................................................. 7 - 32

Figure 7-M Two Speed Winch (Rev B; July 2007) .................................................................... 7 - 34

vii

TABLE OF CONTENTS

Parts and Service Manual - First Edition

Genie Superlift Advantage Part No. 32283

This page intentionally left blank.

Part No.32283 Genie Superlift Advantage 2 - 1

Section 2 - Specifications

Part and Service Manual - First Edition

Model SL-5 SL-10 SL-15 SL-20 SL-25

Height-Stowed 781/2in 781/2in 781/2in 781/2in 781/2in

199 cm 199 cm 199 cm 199 cm 199 cm

Width 311/2in 311/2in 311/2in 311/2in 311/2in

Standard Base 80 cm 80 cm 80 cm 80 cm 80 cm

Width - stabilizers lowered 785/8in 785/8in 785/8in 785/8in 785/8in

Standard Base 185 cm 185 cm 185 cm 185 cm 185 cm

Width-Min 311/2in 311/2in 311/2in NA NA

Straddle Base 80 cm 80 cm 80 cm

Width-Max 58 in 58 in 58 in NA NA

Straddle Base 147 cm 147 cm 147 cm

Length-Stowed 29 in 29 in 29 in 29 in 31 in

74 cm 74 cm 74 cm 74 cm 79 cm

Length - Operating 571/2in 571/2in 721/2in 801/2in 801/2in

146 cm 146 cm 184 cm 204 cm 204 cm

Ground 2 in 2 in 2 in 2 in 2 in

Clearance 50.8 mm 50.8 mm 50.8 mm 50.8 mm 50.8 mm

Load Capacity 1000 lbs 1000 lbs 800 lbs 800 lbs 650 lbs

at 18" load center 454 kg 454 kg 363 kg 363 kg 295 kg

Net Weight - Standard Base 215 lbs 260 lbs 317 lbs 405 lbs 450 lbs

(no load handling attachment) 97.5 kg 117.9 kg 143.8 kg 183.7 kg 204.1 kg

Net Weight - Straddle Base 258 lbs 303 lbs 360 lbs NA NA

(no load handling attachment) 117.0 kg 137.4 kg 163.3 kg

Load Handling Attachments Length Width Depth Net Weight

Standard Forks 271/2in 231/2in 21/2 in 38 lbs

70 cm 60 cm 6.5 cm 17.2 kg

Adjustable Forks 271/2in 111/2 in to 30 in 21/2 in 52.5 lbs

70 cm 29 cm to 76 cm 6.5 cm 23.8 kg

Flat Forks 32 in 16 in to 31 in 11/2in 73 lbs

81 cm 41 cm to 79 cm 4 cm 33.1 kg

Boom 18 in to 42 in 11/2in 61/2in 34.5 lbs

46 cm to 107 cm 4 cm 16 cm 15.6 kg

Vertical Barrel Stacker 21 in 29 in NA 50.5 lbs

53 cm 74 cm 22.9 kg

Rotating Barrel Handler 29 in 31 in NA 85 lbs

74 cm 79 cm 38.6 kg

Pipe Cradle 271/2in 24 1/2in 6 in 10 lbs

70 cm 63 cm 11.5 cm 4.5 kg

Load Platform 271/2in 231/2in 21/2in 26.5 lbs

70 cm 60 cm 6.5 cm 12.0 kg

Specifications

2 - 2 Genie Superlift Advantage Part No.32283

Section 2 - Specifications Part and Service Manual - First Edition

SPECIFICATIONS

Dimensions - Operating SL-5 SL-10 SL-15 SL-20 SL-25

Standard Forks forks down 4 ft 101/2in 9 ft 9 in 14 ft 71/2in 19 ft 6 in 24 ft 4 in

1.5 m 3 m 4.5 m 6 m 7.4 m

forks up 6 ft 7 in 11 ft 51/2in 16 ft 4 in 21 ft 21/2in 26 ft 1/2in

2 m 3.5 m 5 m 6.5 m 7.9 m

Adjustable Forks forks down 4 ft 101/2in 9 ft 9 in 14 ft 71/2in 19 ft 6 in 24 ft 4 in

1.5 m 3 m 4.5 m 6 m 7.4 m

forks up 6 ft 7 in 11 ft 51/2in 16 ft 4 in 21 ft 21/2in 26 ft 1/2in

2 m 3.5 m 5 m 6.5 m 7.9 m

Flat Forks 4 ft 101/2in 9 ft 9 in 14 ft 71/2in NA NA

1.5 m 3 m 4.5 m

Boom 5 ft 101/2in 10 ft 9 in 15 ft 71/2in 20 ft 6 in 25 ft 4 in

1.8 m 3.3 m 4.8 m 6.3 m 7.7 m

Note: measured from ground to bottom of shackle

Vertical Barrel Stacker 30 gallon 4 ft 8 ft 10 in 13 ft 9 in NA NA

(24 Load Center) 1.2 m 2.7 m 4.2 m

55 gallon 3 ft 10 in 8 ft 8 in 13 ft 7 in

1.2 m 2.6 m 4.1 m

Note: measured from ground to bottom of barrel

Rotating Barrel Handler 55 gallon 3 ft 10 in 8 ft 8 in 13 ft 7 in NA NA

(24 inch Load Center) 1.2 m 2.6 m 4.1 m

Note: measured from ground to bottom of barrel

Load Platform forks down 4 ft 101/2in 9 ft 9 in 14 ft 71/2in 19 ft 6 in 24 ft 4 in

1.5 m 3 m 4.5 m 6 m 7.4 m

forks up 6 ft 7 in 11 ft 51/2in 16 ft 4 in 21 ft 21/2in 26 ft 1/2in

2 m 3.5 m 5 m 6.5 m 7.9 m

Note: can be used with standard forks and adjustable forks only

Pipe Cradle:handles round objects up to 30 in (76 cm) in diameter

Note: can be used with standard forks and adjustable forks only (see above for working heights)

Non-marking Fork Option

Note: can be used with standard forks and adjustable forks only (see above for working heights)

Fork Extension Option

Note: can be used with standard forks and adjustable forks only (see above for working heights)

Part No.32283 Genie Superlift Advantage 2 - 3

Section 2 - Specifications

Part and Service Manual - First Edition

Torque - Dry

inch-pounds

Torque - Dry

foot-pounds

Torque - Dry

Newton meters

Torque - Dry

inch-pounds

Torque - Dry

foot-pounds

Torque - Dry

Newton meters

120

110

120

150

170

260

300

430

470

640

700

102

122

149

163

204

231

353

407

583

637

868

949

144

168

110

120

150

170

220

240

380

420

600

660

900

1000

109

149

163

204

231

298

326

515

570

814

895

1221

1356

1/4

5/16

3/8

7/16

1/2

9/16

5/8

3/4

7/8

Torque specifications for lubricated bolts are 25% less than dry torque specifications for each bolt size.

These bolt torque specifications are for general use only. Specification may vary depending on application of bolt.

Size Threads SAE Grade 5 Bolts SAE Grade 8 Bolts

Bolt Torque Specifications

SPECIFICATIONS

2 - 4 Genie Superlift Advantage Part No.32283

Section 2 - Specifications Part and Service Manual - First Edition

This page intentionally left blank.

Part No.32283 Genie Superlift Advantage 3 - 1

Section 3 - Scheduled Maintenance InspectionsParts and Service Manual - First Edition

Dealer

service

suggested

New parts

required

Tools are

required

Scheduled Maintenance Inspections

Observe and Obey:

Maintenance inspections shall be completed by

a person trained and qualified on the

maintenance of this machine.

Scheduled maintenance inspections shall be

completed daily, quarterly and annually as

specified on the maintenance inspection report.

Failure to properly complete each

inspection when required may

result in death, serious injury or

substantial machine damage.

Immediately tag and remove from service a

damaged or malfunctioning machine.

Repair any machine damage or malfunction

before operating machine.

Keep records on all inspections for three years.

Machines that have been out of service for a

period longer than 3 months must complete the

quarterly inspection.

About This Section

Schedule

There are three types of maintenance inspections

that must be performed according to a schedule—

daily, quarterly and annually. To account for

repeated procedures, the Maintenance Tables and

the Maintenance Inspection Report have been

divided into three subsections—A, B, C. Use the

following chart to determine which group(s) of

procedures are required to perform a scheduled

inspection.

Inspection Table or Checklist

Daily A

Quarterly (every 150 hours or three months) A + B

Annual A + B + C

Maintenance Tables

The maintenance tables contained in this section

provide summary information on the specific

physical requirements for each inspection.

Complete step-by-step instructions for each

scheduled maintenance procedure are provided in

section 4,

Scheduled Maintenance Procedures

Maintenance Inspection Report

The maintenance inspection report contains

checklists for each type of scheduled inspection.

Make copies of the Maintenance Inspection Report

to use for each inspection. Keep records on all

inspections for three years.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de elevación de Terex

Terex

Terex SX180H-745 Manual de usuario

Terex

Terex Genie GS-1530 Manual de usuario

Terex

Terex Genie Z-45/25 DC Manual de instalación y funcionamiento

Terex

Terex Genie GTH-4014 AU Manual de usuario

Terex

Terex GS90D-4695 Manual de instalación y funcionamiento

Terex

Terex Genie GRC-12 Manual de usuario

Terex

Terex SX135XCH-101 Manual de instalación y funcionamiento

Terex

Terex Genie GS -1530/32 Manual de usuario

Terex

Terex TA50RT Manual de usuario

Terex

Terex Z-30/20N Manual de usuario

Terex

Terex C5000 Series Manual de usuario

Terex

Terex Genie GTH1215M-101 Manual de instalación y funcionamiento

Terex

Terex Genie S-60 FE Manual de instalación y funcionamiento

Terex

Terex GTH08E-11500 Manual de instalación y funcionamiento

Terex

Terex Genie Z-60 DC Manual de usuario

Terex

Terex Genie GTH4016 SR Manual de usuario

Terex

Terex Genie GR-12 Manual de usuario

Terex

Terex Robot 5000 Manual de servicio

Terex

Terex Genie SX-135 XC Manual de usuario

Terex

Terex HP-32 Manual de usuario

Terex

Terex Genie GR Series Manual de usuario

Terex

Terex Genie GS-1432m Manual de usuario

Terex

Terex SX18014-101 Manual de usuario

Terex

Terex Genie Lift Guard S-60 Manual de usuario

Manuales populares de Sistema de elevación de otras marcas

morse

morse 82H-124 Manual de usuario

Braun

Braun NL955 Series Manual de usuario

haacon

haacon 1889.10 Manual de usuario

Protekt

Protekt AT 252 Manual de usuario

R. Beck Maschinenbau

R. Beck Maschinenbau HS 600 Manual de usuario

Nova Technology International, LLC

Nova Technology International, LLC NAS Series Manual de usuario

Genie

Genie Z-60/34 Manual de usuario

Screen Technics

Screen Technics INTERFIT Vertical Up Lift Manual de usuario

Mortuary Lift

Mortuary Lift ULTIMATE 1000 Manual de usuario

Custom Equipment

Custom Equipment Hy-Brid 3 Series Manual de programación

Custom Equipment

Custom Equipment Hy-Brid Lifts 2 Series Manual de programación

Hy-Brid Lifts

Hy-Brid Lifts HB-P3.6 Manual de programación

BERG

BERG BeNomic EasyLeaf Manual de usuario

Powermate

Powermate LiftGate LG-3 Manual de usuario

Snorkel

Snorkel TM12 Series Manual de usuario

Terberg

Terberg OMNIDEKA Manual de usuario

Harmar Mobility

Harmar Mobility AL625 Instrucciones de funcionamiento

Rotary

Rotary SPO16 Manual de usuario
