1Introduction
1.1 Applications
The Prosaris OL1 is a portable directional ultrasonic leak
detector primarily used to detect, locate, and measure leaks
in compressed gas and vacuum systems.
The OL1 connects with any Android device and through an
app downloaded onto the Android device, captures a live-
view image of the scanned process or industrial system.
The OL1 attaches to the back of the Android device by
magnet and connects via cable.
The OL1 has a proprietary arrangement of sensor arrays which
detect ultrasonic noise and uses this data to provide visual
direction and location of the sound source directly onto the
visual display of the area under assessment.
When provided with input data, an estimation of both leak
volumetric flow and financial loss associated with the wasted
energy related to the leak can be calculated.
The OL1 is provided with a sealed rechargeable battery which
powers the device (power is not drawn from the Android
until the OL1 is below minimum levels). An external battery
charging cable is provided with the device.
All leak event record data are stored on the Android device
and Prosaris Leak Management application backend, which is
accessible to each user (subject to subscription tier).
The OL1’s main applications are:
• Compressed air leak detection, location and
quantification
• Compressed process (non-hazardous) gas leak detection,
location, and quantification
• Vacuum leak detection
The OL1 is not intended to be used for life safety
applications.
Industries served include:
