Tenveo VHD Series Manual de usuario
Version V5.2(English)
Add.: Rm 638-639, Block B, Tianhui
building, No 106, Yousong Rd, Lon-
ghua Dist, Shenzhen, China.
E-mail: [email protected]
Mobile: +86-18929337105
Add.: Rm 2302, Block A, Zhongdeng
Wenjing building, Fengcheng 9th Rd,
Weiyang Dist, Xi'an, China.
Tel: +86-29-81318040
ShenZhen Tenveo Video Technology Co,.ltd
Headquarter Xi'an Branch
www.hktenveo.com
(ShenZhen)
HD Conference Camera
User Manual
Performance Characteristics
Quick Start
Remote control button description
Common operation instructions
Camera Menu Set
Trouble shooting
Tech parameters
Product Description
Foreword
Notice
Supplied Accessories
Camera papameters
Interface definition
Interface diagram
Installation instructions
Contents
Remote control instructions
Common Operation Instructions
Menu Description
Control Interface
Remote control match
Trouble shooting
Maintenance Services
Maintenance Services
1
1
1
2
2
3
3
4
5-6
7-8
9-15
16
16
17
17
Warranty card
Warranty card 18-19
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
------------------------------------
1
Attention
Thanks for choosing our VHD series conference cameras.
Please read this manual carefully before using the product.
1. Foreword
·To avoid damage from stress, violent vibration, soaking during tra-
nsportation, storage and installation.
·Take care of each components of camera during installation, and
install camera at where is affordable enough, to avoid drop or scra-
tches of camera case.
·Handle the camera parts gently, do not squeeze the camera units
hard. Please do not touch the camera lens by hand directly to avo-
id the lens scratched and image quality affected.
·Do not apply excessive voltage. (Use only the specified voltage)
Otherwise, you may get an electric shock or a fire may occur.
·Do not aim the camera at the sun or the other high luminous obje-
cts, otherwise it may cause image blurring or lens flare, even cause
permanent damage to the camera.
·Do not clean camera with active chemical or corrosive detergents,
and remove dust or dirt on the surface of the lens with a blower (C-
ommercially available)
·Do not disassemble any camera components, in case of abnormal
operation; contact your authorized dealer or the store where you p-
urchased the product.
(1) HD conference camera (2) DC12V-2A power supply
(3) Ceiling mount (4) Mounting screws
(5) Manual (6) Remote control
(7) Serial port control cable (8) USB cable
2. Notice
3. Supplied Accessories
Performance Characteristics
1. Camera technical parameters
2. Camera Parameters
Electric Communication
Operation Surroundings
Physics Installation Method
Input Voltage
Power
Decoder
Horizontal Rotation
Vertical Rotation
Baud
Protocol
Address Set
Operating
Environment
Operating Temp
Rotation Speed
Preset Point
Net-Weight
Image Sensor 1/3”Exmor CMOS 1/3”HD CMOS
2.38Mega pixel
1080P(1920*1080) 720P(1280*720)
3G-SDI,HDMI
1080P/720P
NTSC/PAL
IR remote control supports 9 presets PELCO,Protocol supports 256 presets
-170°~170° -30°~90°
100°/s 80°/s
VISCA,PELCO-D,PELCO-P(RS-232, RS485)
Product：260*175*180mm packaging：296*225*218mm
black
F=5.0-50.0mm
51.3°~4.64° 55.5°~3.0° 69.5°~2.7°
F=4.7-94.0mm F=4.7-140.0mm
3.28Mega pixel
1/3”CMOS
Effective Pixel
Lens
HD Format
Focal Length
HD Interface
FOV
Resolution
Signal System
Control parameters
Translation/
Pitching Angle
Translation/
Pitching Speed
Preset
Control Protocol
Common Parameters
Size
Color
Model VHD10N VHD30NVHD20N
10x Optical Zoom 30x Optical Zoom20x Optical Zoom
Spec
DC12V
12W
internal
±170°
120°
2400/4800/9600bps
VISCA/PELCOD/P
0~255
0°~+50°
0~95%
non-condensing
Support desktop,wall mount,ceiling mount
and tripod installation
100°/s
9 remote controls
Pelco Protocol
256
1.46kg
2
Quick Start
2.Interface diagram
1.3G-SDI 2.HDMI 3.Sys Select
4.RS232 5.IR Receiver 6.RS-485
7.DC12V
3
1. Interface definition
DC 12V Output AC 220V Input
① ② ③④⑤ ⑥ ⑦
HDMI3G-SDI
HDMI3G-SDI
HD-SDI
DVI interface
3.Installation instructions
(1)Surface Installation
Put the camera on the desk flat, and make sure the camera in
level. If want to put the camera on oblique surface, please m-
ake sure the angle of inclination less than 15 degree for ensu-
re camera pan and tilt working in normal operation.
(2) Tripod Mount Installation
(3) Ceiling Mount Installation
Twist the tripod’s screw on the camera tripod hole, then the
tripod could be installed on the bottom of camera. The tripod
screw must fit below.
>
_
15°
_
<
15°
Screw specification 1/4-20UNC
6mm
4
1.Fix the upper bracket to the ceiling
3 Close the upper and lower brackets
2.Fix the lower bracket to the ceiling
lower bracket
Ceiling
Upper bracket
Ceiling
4.Lock the upper and lower brackets
Screw hole
Screw holeScrew hole
Remote control button description
(1) Remote Control Launch Window
(2)【POWER】： Standby Button, pressing
it, camera goes into Standby Mode; pres-
sing again, camera goes Power ON.
(3)【Camera Pan/Tilt Reset 】： Camera -
Pan/Tilt reset Function same with⑧（ P/T-
RESET）
(4)【CAMERA SELECT】Choose the ca-
mera number that needed to control, to c-
orrespond the dial-up code on the back o-
f camera;
(5)【POSITION】： Preset position setup
keys, include【PRESET】and【RESET】.
Press PRESET+NUMNER: to setup preset;
Press RESET+NUMBER: to clear preset.
(6)【OSD】： Turn on/off the on-screen m-
ode or enter the movement menu;
(7)【PAN-TILT】Camera rotation control -
key:
Press this button and move by the arrow -
direction, press
Press【HOME】to back to the center of -
vertical and horizontal position.
(8)【P/T Reset 】： Camera Pan/Tilt reset ；
5
12
13
15
14
1 2 3
12 3
45 6
78 9
PRESET
0RESET
CAMERA SELECT
STD REV
POSITION
OSD B-LIGHT
HOME
PAN-TILT
MENU
PT/RESET
ZOOM
SLOW
+
-
ZOOM
FAST
+
-
FAR
NEAR
MANUAL
FOCUS
L/R
SET
AUTO
FOCUS
Remote control instructions
(9)ZOOM SLOW
【Zoom SLOW+】T：Zoom out at low speed
【ZOOM SLOW-】W：Zoom in at low speed
(10) Manual Focus Mode
【MANUAL FOCUS】： Start manual focus function
【FAR】： Manually far focus button, clearer for the distant -
objects, loose finger to stop.
【NEAR】： Manually near focus button, clearer for the nea-
rby objects, loose finger to stop.
(11)【L/R DIRECTION/SET】： Press this functi-
on key, then:
press 1（STD）camera rotating horizontally in regular ins-
talled direction
press 2（REV）camera rotating horizontally inreversed -
installed direction
(12)【AUTO FOCUS】： Auto Focusing Button
(13) Fast Zoom Key
【ZOOM FAST +】： Zoom out at fast speed
【ZOOM FAST -】： Zoom in at fast speed
(14)【MENU】Enter/Exit the menu
(15)【BACK LIGHT】Backlight compensation
★Attentions for Remote Control
1. If remote control doesn't work, please replace batteries.
2. If there is an object between remote control and speci -
alized remote control sensor, the camera will not work. -
Please make sure the remote control is aimed at the sen -
sor which in front of the camera when controlling it.
6
Common Operations Introductions
1. Camera Select
Refer to the dial-up at the back of camera and choose
camera address number that you want to control（1-3）。
2. Camera Direction Control
*Note: Press direction key to move the camera.Press the
direction key when you need to change the angle. If you
want to move the camera slowly, just click the direction
key; If you want to move the camera fast at a large scale,
just long-press the button.
3. Camera Focusing Mode Control
【AUTO】Switch the focus mode to AUTO
【MANUAL】Switch the focus mode to MANUAL
【FAR】Far focus manually
【NEAR】Near focus manually
Turning up
Turning down
Turning to left
Turning to right
7
1 2 3
CAMERA SELECT
HOME
FAR
NEAR
MANUAL
FOCUS AUTO
FOCUS
4. Camera Zoom Control
Press any one of the 4【ZOOM】
to make the zoom functioning.
5. Back Light
The subject will become dark when there is a
light source behind it, press【BACK LIGHT】
to use back light shooting function. To cancel,
press【BACK LIGHT】again.
6. Preset Setup,Call,Cancel
(1) Reserve Preset: Press【PRESET】
then press one of the number（1-9）to
reserve a preset that correspond to the
NUMBER.
*Note: you can setup 9 presets at most by the remote control.
(2) Call Preset: Press the NUMBER（1-9）directly to call the-
reserved preset.
*Note: It won’ t work if there’ s no preset reserved in the cor-
responded number.
(3) Remove Preset: Press【RESET】, then press one of the-
number（1-9）to remove a preset that correspond to the NU-
MBER.
8
12 3
45 6
78 9
PRESET 0RESET
STD REV
POSITION
B-LIGHT
ZOOM
SLOW
+
-
ZOOM
FAST
+
-
(1) Reserve Preset:
