Tempest Oasis Manual de usuario

Oasis User Manual 1

User Manual

Oasis

Revision 1.0

August, 2022




Oasis User Manual 2

Table of Contents
Table of Contents 2
Approvals –Europe 6
Approvals –China 7
Introduction 8
IMPORTANT: Safety Advisories 8
Installation 9
Dimensions 9
Access Clearance 9
Snow Clearance 10
Enclosure Mounting Hardware Options 10
Mounting Bolts 10
Mounting Options –Unistrut Kit 11
Mounting Options –Stacking Kit 11
Mounting Options –Swivel Stacking Kit 12
Cyclovator Tilt Kit 13
Cyclovator –Unistrut Mounting Rails 13
Fixing the Cyclovator in Place 14
Mounting the Enclosure 15
Setting the Show Position Stop 16
Oasis Angle Mount Kit 17
Angle Mount Kit Installation 17
Wiring the Enclosure 19
Power Wiring 19
SAFETY NOTICE 19
Electrical Standards 19
Wiring Access 20
One or Two Power Circuits? 21
Single Feed Power Termination 22
Split Feed Power Termination 22
North America 208V, Japan 200V Single Feed 23
North America 208V, Japan 200V Split Feed 23
International, 230V Single Feed 24
International, 230V Split Feed 24
Oasis Enclosure Condensate Drain 25
Find Enclosure Low Point 25
Install Condensate Drain 25




Oasis User Manual 3

Installing the Oasis Outdoor Unit 26
Single and Multizone ODU Installation 26
Line Set Lengths 26
ODU Location 27
Special Considerations for Extreme weather 27
Note: Drain Connections 27
Mounting the ODU 28
Wiring the ODU 29
ODU Power Requirement: 29
ODU Wiring Connections 29
Refrigerant Piping Connections 31
Oasis Standard Line Sets 31
Note on Pipe Length 31
Which Line Set Rating? 31
Prepare Refrigerant Pipes 32
Torque Requirements 34
Connecting Line Set to the Oasis Enclosure 34
Connecting Line Set to the ODU 35
Air Evacuation 36
Preparation and Precautions 36
Adding Refrigerant 37
Electrical and Gas Leak Checks 38
Electrical Safety Checks 38
Gas Leak Checks 38
Test Run 39
Before Test Run 39
Test Run Instructions 39
Cooling System Error Codes 40
Oasis Cooler Settings 41
Set Temperature Scale 41
Set Cool Mode 41
Power Cycling 41
Set Temperature 42
Projector on, Projector Standby 42
Remote Monitoring 43
DEC4 Ethernet Adapters –51.D4.15, 51.D4.23 44
51.D4.15 Default Configuration 44
51.D4.15 Additional Support 44




Oasis User Manual 4

RS485 (DMX/RDM) Cable Terminations 45
Line Termination Switch Settings 46
System Manager Installation 47
Enclosure Management 49
Enclosure Monitoring 49
DMX Control 51
Firmware Uploads 51
Remote Configuration 51
Tempest Equipment Management Protocol 52
Digital Enclosure Control 53
Schematic 53
DEC4 Main Functions 54
Firmware Revision 54
Factory Settings –Data Modes 54
Hardware Indicators & Fuses 55
Operating Modes 56
RDM Only Monitor (Factory Default) 56
RDM+DMX Control 56
RDM+DMX Service 56
DEC4 Control Parameters 57
Control Interface 58
User Interface LCD Display 59
Control Interface Operation 59
Control Menu 60
Set DMX Options 60
Set Temp Units 61
Set Temp Ranges 61
Set Max Humidity 61
Set Lamp Options 61
Set Fan Function 62
Status Display 63
DEC4 Firmware Updates 64
Direct Firmware Update (System Control Board only) 64
Indirect Firmware Updates 68
Requirements 68
Installation Procedure 68
Mounting the Projector 72
Projector Mounting –Landscape 72


Oasis User Manual 5

Projector Mounting - Portrait 73
Portrait L-Bracket Mounts 73
Important: Check Lamp-on Current 76
Connect Projector and Aux Equipment 76
Projector Connector Types 77
Warranty 78
Appendix –TEMP Protocol 79
Physical Layer 79
Developer’s Guide 79

Oasis User Manual 6

Approvals –Europe

CERTIFICATE AND DECLARATION OF CONFORMITY

FOR CE MARKING

Tempest Lighting, Inc.

11845 Wicks Street, Sun Valley, CA 91352, USA

t: +1 818 787 8984 f: +1 818 252 7101 e: info@tempest.biz

www.tempest.biz

Tempest Lighting, Inc. declares that their

Oasis Projector Enclosure Series 59.xxx.x.x

complies with the Essential Requirements of the following EU Directives:

Low Voltage Directive 2014/35/EU Test Report 60065-6500-01-14

Electromagnetic Compatibility Directive 2014/30/EU Test Report 61000-6500-03-14

and further conforms with the following EU Harmonized Standards:

EN 60065 : 2014/AC:2016 Test Report 60065-6500-01-16

EN 60529:1991/AC:2016-12 Test Report 60529-6500-02-16

EN 61000-6-3:2007+A1:2011 Test Report 61000-6500-03-14

EN61000-6-1:2007 Test Report 61000-6500-03-14

EN55015:2019/A11:2020 Test Report 61000-6500-03-14

Dated: 21st July 2022

Position of signatory: President

Name of Signatory: Tim Burnham

Signed below:

on behalf of Tempest Lighting, Inc.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Oasis User Manual 7

Approvals –China

Oasis User Manual 8

Introduction

Thank you for purchasing a Tempest enclosure! We have worked hard to provide you with the very

best product available for its purpose, and we shall continue to do everything possible to ensure

that it works well for you for many years to come.

Please read this manual before starting work!

In the event of difficulty, please contact your Tempest reseller or Tempest direct:

[email protected]

+1 818 787 8984

We will do everything we can to help you get the very best results from your Tempest enclosure.

IMPORTANT: Safety Advisories

•All installation and rigging work done must where applicable be designed and built in

accordance with norms and standards of the local authority having jurisdiction of the

installation site. It is the responsibility of the installer to obtain such approvals as may be

required to achieve full compliance.

•All electrical work must be carried out by a suitably licensed electrical contractor in full

compliance with local electrical standards.

•Lifting: some enclosures and the equipment inside them may be heavy. Use properly

rated lifting equipment where appropriate and never attempt to carry out work with

fewer than the number of workers needed to lift safely.

•It is the responsibility of the installer to ensure that all local building, safety and electrical

codes are strictly adhered to in the installation of this enclosure. Tempest Lighting, Inc.,

its employees and agents are in no way responsible for damage arising from failure to

follow either the instructions in this manual or building, safety and electrical codes

prevailing at the installation location.

•Do not attempt to install or operate the enclosure before fully reading and understanding

this manual

•Never allow anyone who has not read this manual to open the enclosure or perform

maintenance on the projector within.

•Never leave the enclosure unattended when open.

•Always make sure all bolts and latches are tight and safety locks are in place after

performing any form of maintenance on the unit.

•Do not open any electrical boxes until power has been shut off to all supply lines to the

enclosure (including the one powering the projector).

•Do not open the enclosure in wet weather.

Oasis User Manual 9

Installation

Dimensions

Please refer to Oasis 2D and 3D CAD files at

www.tempest.biz

Access Clearance

Observe these minimum access clearances shown around

your enclosure.

Enclosures may be placed side-by-side, with the projector

access opposite, but we recommend allowing clearance

for service access on both sides wherever possible.

60cm [24in] for installation

and service access to wiring,

controller, line set connections

Enclosure width

Note:

Door swing for Portrait

enclosures may exceed enclosure

width. Check Oasis submittal

drawings at www.tempest.biz.

5cm [2in]

Oasis User Manual 10

Snow Clearance

In areas where snow is likely, make sure the base of the

enclosure and cooler ODU are at least 24” [60cm] above

highest potential snow drift level.

Enclosure Mounting Hardware

Options

Mounting Bolts

•Each Enclosure must be mounted with at least FOUR

points (six points if hanging)

•All mountings must be made using the M12

threaded holes on the top or bottom of the

enclosure.

•Be sure to use the sealing washers supplied for any

top fixings.

•Use an 8mm hex key to secure the M12 socket cap

screws provided.

•Tempest recommends the use of stainless steel

mounting hardware.

•Make sure the inlet filter has at least 75mm/3in

clearance below.

IMPORTANT SAFETY NOTICE

Installer must ensure that all mounting points are secure

and conform to local safety regulations. Tempest Lighting

Inc. accepts no responsibility for damage or injury arising

from inappropriate or unsafe installation.

8mm

Mounted from Above:

M12-1.75 bolts

Use 8mm hex key

Sealing washers

Mounted from Below:

M12-1.75 bolts

Use 8mm hex key

60cm [24in]

For rigging point dimensions, see Oasis CAD drawings at www.tempest.biz.
