Telex TK-80 Series Guía del usuario
2018|03
F.01U.321.735 Rev. 02
Kenwood Radio Series
TK-x80, -x90, -x150, and -x180
to IP-224 Remote Adapter Panel
Kenwood Radio Series
2F.01U.321.735 Rev. 02
PROPRIETARY NOTICE
The product information and design disclosed herein were
originated by and are the property of Bosch Security Systems, Inc.
Bosch reserves all patent, proprietary design, manufacturing,
reproduction, use and sales rights thereto, and to any article
disclosed therein, except to the extent rights are expressly granted
to others.
COPYRIGHT NOTICE
Copyright 2018 by Bosch Security Systems, Inc. All rights
reserved. Reproduction, in whole or in part, without prior written
permission from Bosch is prohibited.
*All other trademarks are property of their respective owners.
WARRANTY NOTICE (LIMITED)
FOR WARRANTY AND SERVICE INFORMATION, REFER TO
WWW.TELEX.COM/WARRANTY.
FACTORY SERVICE CENTER
Factory Service Center
Bosch Security Systems, Inc.
Radio Dispatch Products
8601 East Cornhusker Highway
Lincoln, Nebraska, 68507
CONTACT INFORMATION
Sales:
Phone ...........................................................(800) 752-7560
Fax ................................................................(402) 467-3279
Customer Service Repair:
Phone ............................................................(800) 553-5992
Technical Support:
Knowledge Database . http://knowledge.boschsecurity.com/
LiveChat ..................... www.telex.com/us/dispatch/support
Web ............................................................. www.telex.com
CLAIMS
No liability will be accepted for damages directly or indirectly
arising from the use of our materials or from any other causes. Our
liability shall be expressly limited to replacement or repair of
defective materials.
WARNING
This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be
required to take adequate measures.
Do not open the unit. No user serviceable parts are contained
within. Bosch cannot be responsible for damage. If the unit is
opened, the warranty can be voided.
OPENSSL PROJECT
This product includes software developed by the OpenSSL Project
for use in the OpenSSL Toolkit (http://www.openssl.org/). This
product includes cryptographic software written by Eric Young
3F.01U.321.735
Table of Contents
1.0 Introduction.................................................................................................. 5
2.0 Hardware Requirements ............................................................................. 5
3.0 Software Requirements ............................................................................... 5
4.0 Supported Features...................................................................................... 6
5.0 Cable Diagram.............................................................................................. 7
5.1 TK-x80 Model Cable Assembly ...............................................................................7
5.2 TK-x90 Model Cable Assembly ...............................................................................7
5.3 TK-x150/-x180 Model Cable Assembly...................................................................8
6.0 Radio Setup................................................................................................... 9
6.1 TK-x80 Series Radio Configuration........................................................................9
6.1.1 TK-x80 Series Radio Programming............................................................ 9
6.1.2 TK-x80 Series Radio Hardware Modifications ....................................... 10
6.2 TK-x90 Series Radio Configuration......................................................................10
6.2.1 TK-x90 Series Radio Programming.......................................................... 10
6.2.2 TK-x90 Series Radio Hardware Modifications ....................................... 11
6.3 TK-x150/-x180 Series Radio Configuration .........................................................12
6.3.1 TK-x150/-x180 Series Radio Programming ............................................. 12
7.0 IP-224 Setup................................................................................................ 14
7.1 Setting for Auto Configuration..............................................................................14
7.2 Multicast Configuration .........................................................................................15
7.3 Hardware Configuration........................................................................................16
7.4 Per Line Configuration ..........................................................................................17
7.4.1 Per Line Function Tone Configuration ................................................... 18
7.4.2 LAM/COR Configuration......................................................................... 19
7.4.3 Options Configuration ............................................................................... 20
7.5 Gain Configuration.................................................................................................21
4F.01U.321.735
F.01U.321.735 5
1.0 Introduction
This application note is intended to assist technical staff with the creation of an IP-224 interface to
the Kenwood TK-x80, TK-x90, TK-x150, and TK-x180 series radios.
2.0 Hardware Requirements
•IP-224 Ethernet Adapter Panel (P/N F.01U.306.547)
•IP-224 to Kenwood TK-X150/X180, 5X10 and NXDN Radios Cable (P/N
F.01U.165.540)
•IP-224 to Kenwood TK-X90 Cable (P/N F.01U.165.541)
•Kenwood TK-x80, TK-x90, TK-x150, or TK-x180 series radios
3.0 Software Requirements
•C-Soft version 6.500 or later
•IP-224 version 2.300 or later
•Telex System Manager (TSM) 2.300 or later
•Windows 7 (32-bit or 64-bit)
•Windows 8.1
Kenwood Radio Series
6 F.01U.321.735
4.0 Supported Features
TK-x80, -x150, and -x180 Supported Features
Feature Analog Support Feature Analog Support
Channel/Talkgroup Yes Emergency Acknowledgement No
Zone Change No Encryption On/Off Yes
GPS Read No
Group Call Yes GPS Trigger On/Off No
Private Call Yes Monitor On/Off Yes
Radio Call Alert No
ANI Decode Yes Radio Check No
Emergency Decode Yes Radio Enable/Disable Yes
Status Message Decode Yes Radio Select Call Yes
Text Message Decode No Radio Remote Monitor No
Radio Send Text Message No
Query Encryption Yes Radio Status (Send Status
Message) Yes
Query Monitor Yes Radio Status Request Yes
Query Scan Yes Scan Add/Delete Yes
Query Talk Around Yes Scan On/Off Yes
Talk Around On/Off Yes
TK-x90 Supported Features
Feature Analog Support Feature Analog Support
Channel/Talkgroup Yes Emergency Acknowledgement No
Zone Change No Encryption On/Off Yes
GPS Read No
Group Call No GPS Trigger On/Off No
Private Call No Monitor On/Off Yes
Radio Call Alert No
ANI Decode No Radio Check No
Emergency Decode No Radio Enable/Disable No
Status Message Decode No Radio Select Call No
Text Message Decode No Radio Remote Monitor No
Radio Send Text Message No
Query Encryption No Radio Status (Send Status
Message) No
Query Monitor No Radio Status Request No
Query Scan No Scan Add/Delete Yes
Query Talk Around No Scan On/Off Yes
Talk Around On/Off Yes
Kenwood Radio Series
F.01U.321.735 7
5.0 Cable Diagram
5.1 TK-x80 Model Cable Assembly
IP-224 to TK-x80 audio and serial cable connections. This cable is manufactured from a
Kenwood KCT-19 accessory cable.
5.2 TK-x90 Model Cable Assembly
IP-224 to TK-x90 audio and serial cable connections.
Signal IP-224 DB-37 KCT-19 Accessory Connector
Ground 29 6
PTT Common 5 6
PTT 24 8
COR 15 11
RX+ 20 12
TX+ 1 5
TXD 17 14
RXD 36 15
Signal IP-224 DB-37 TK-x90 Radio DB-25
Ground 29 7
PTT Common 5 7
PTT 24 2 Aux Input (Programmable)
COR 15 20 AOI (Programmable)
RX+ 20 17
TX+ 1 13
TXD 17 10
RXD 36 9
Kenwood Radio Series
8 F.01U.321.735
5.3 TK-x150/-x180 Model Cable Assembly
IP-224 to TK-x150/-x180 audio and serial cable connections.
Signal IP-224 DB-37 TK-XXXX Radio DB-25a
a. There are differences between the TK-x150 and TK-x180 radio’s DB-25 connectors:
• If COR is used, then pin 20 (TK-x150 an output only) is programmed for that
function and the cable routes that signal to the IP-224.
• On the TK-x180 the same pin is a general purpose I/O and has an additional 470
Ohm series resistance added. Therefore, the IP-224 internal pull-up voltage must be
removed. The Auto Configuration feature will adjust hardware settings accordingly.
Ground 29 7
PTT Common 5 7
PTT 24 12 Aux Input 4 (Programmable)
COR 15 20 Aux Output 1 (Programmable)
RX+ 20 17
TX+ 1 6
TXD 17 2
RXD 36 3
Kenwood Radio Series
F.01U.321.735 9
6.0 Radio Setup
6.1 TK-x80 Series Radio Configuration
6.1.1 TK-x80 Series Radio Programming
To configure the radio, do the following:
1. From the Com 1(Internal Port) drop down menu, select Data.
2. Configure the Scan Information window to set up the scan functionality.
6.1.2 TK-x80 Series Radio Hardware Modifications
To modify the radio settings, do the following:
1. Move R94 to R24 position
NOTE: For more information, see the Kenwood TK-80 series manual, section 1.3.
Kenwood Radio Series
10 F.01U.321.735
6.2 TK-x90 Series Radio Configuration
6.2.1 TK-x90 Series Radio Programming
To configure the radio, do the following:
1. From the edit menu, select Function Port.
The Function Port window appears.
2. Verify the Input tab is open.
3. In the Radio 1 AI1 field, enter Ext PTT.
4. Click the Output tab.
5. In the Radio 1 AO1 field, enter COR.
