Telex RadioCom IC-100 Manual de usuario

RadioComTM

General Description

The IC-100 allows the assignment of any two of six

input lines to any one of twelve two channel outputs.

In addition, the six input lines are available as a loop

through output. All input are protected against

transients and power crosses.

IC-100 Product Features

•Input and output connections are compatible with

BTR-1 Wireless Intercom.

•Non-shorting rotary switches allow reconfiguration

without channel cross-connection.

•An active power monitor indicates the presence of

power on all input lines with minimal loading.

•D sub to XLR breakout on rear panel.

Inputs

There are two ways to connect input lines to the

IC-100:

1. Feed the lines into the 15 pin D sub connector on

the rear panel marked I/C IN. The pin assignments

are shown in Table 1.

2. Connect a patch cable between I/C IN and

EXTERNAL LINES OUTPUT on the rear panel

and feed the lines into the six XLR connectors

marked EXTERNAL LINES INPUT.

Table 1 - Inputs

IC-100

CAT. NO. 301971000

INTERCOM SOURCE ASSIGN PANEL PN 804203

INSTRUCTION SHEET

XLR Equivalent D Conn Pin Number

LINE 1 PIN 2 1

LINE 1 PIN 3 9

LINE 2 PIN 2 2

LINE 2 PIN 3 10

LINE 3 PIN 2 3

LINE 3 PIN 3 11

LINE 4 PIN 2 4

LINE 4 PIN 3 12

LINE 5 PIN 2 5

LINE 5 PIN 3 13

LINE 6 PIN 2 6

LINE 6 PIN 3 14

GND 7

GND 8

GND 15

Telex Communications, Inc.

Specifications

Bridging Impedance...................44k Each Channel

Supply Current........................20ma Each Channel

Peak Pulse Capability..................................1500W

Fuse Rating....................................1.5A Fast Blow

Overvoltage Protection < 1.5A Indefinite Duration

Size (Approximate).................H: 7.00" (177.8mm)

W: 19.00" (482.6mm)

D: 5.00" (127mm)

Weight (Approximate)..................10 lbs. (4.54 kg)

Patents........................................................Pending

Assigned Outputs

Assigned outputs are available in two places.

1. The twelve six pin XLR connectors on the front

panel.

2. The two 25 pin D sub connectors on the rear panel.

The pin assignments are shown in Table 2.

Table 2 - Assigned Outputs

Loop Through Outputs

Loopthroughconnectionsmaybemadeinoneofthree

ways.

1. Connect to the three pin XLR connectors on the

frontpanel.Eachlinehastwoconnectorsavailable.

2. Connect to the 15 pin D sub connector on the rear

panel marked I/C OUT. The pin assignments are

the same as for the I/C IN connector.

3. Connect a patch cable between I/C OUT and

POWER SUPPLY OUTPUT and connect to the six

three pin XLR connectors marked POWER

SUPPLY INPUTS.

Front View - IC-100

Rear View - IC-100

Assigned

Output XLR Equivalent D Conn Pin Number

1 or 7

CHANNEL 1 PIN 2

CHANNEL 1 PIN 3

CHANNEL 2 PIN 2

CHANNEL 2 PIN 3

2 or 8

CHANNEL 1 PIN 2

CHANNEL 1 PIN 3

CHANNEL 2 PIN 2

CHANNEL 2 PIN 3

3 or 9

CHANNEL 1 PIN 2

CHANNEL 1 PIN 3

CHANNEL 2 PIN 2

CHANNEL 2 PIN 3

4 or 10

CHANNEL 1 PIN 2

CHANNEL 1 PIN 3

CHANNEL 2 PIN 2

CHANNEL 2 PIN 3

5 or 11

CHANNEL 1 PIN 2

CHANNEL 1 PIN 3

CHANNEL 2 PIN 2

CHANNEL 2 PIN 3

6 or 12

CHANNEL 1 PIN 2

CHANNEL 1 PIN 3

CHANNEL 2 PIN 2

CHANNEL 2 PIN 3

Telex Communications, Inc.

8601 East Cornhusker Highway, Lincoln, NE 68507

CH 1 1

CH 2

CH 1 1

CH 2

CH 1 1

CH 2

CH 1 1

CH 2

CH 1 1

CH 2

CH 1 1

CH 2

CH 1 1

CH 2

CH 1 1

CH 2

CH 1 1

CH 2

CH 1 1

CH 2

CH 1 1

CH 2

CH 1 1

CH 2

LINE 1 LINE 2 LINE 3 LINE 4 LINE 5 LINE 6

Telexâ

RadioCom

IC-100

RadioCom

IC-100

P/N: 879944

SN: XXXX

Telex Communication, Inc.

8601East Cornhusker Highway, Lincoln, NE 68507

Madein U.S.A. 804070

LINE 1

P2 P3

LINE 2

P2 P3

LINE 3

P2 P3

LINE 4

P2 P3

LINE 5

P2 P3

LINE 6

P2 P3

EXTERNAL LINES

OUTPUT

I/C IN

POWER SUPPLY

OUTPUT

I/C OUT

7 THRU 12

1 THRU 6

ASSIGNED

OUTPUTS

POWER SUPPLY INPUTS

EXTERNAL LINES INPUTS

LINE 1 LINE 2 LINE 3 LINE 4 LINE 5 LINE 6 LINE 1 LINE 2 LINE 3 LINE 4 LINE 5 LINE 6

FOR CONTINUED EQUIPMENT PROTECTION REPLACE

ONLY WITH 1.5A 250V FAST ACTING FUSES
