TA-7650 and TA-7750 Installation Manual

Last Revision: 9/30/11 11:23 AM

Table of Contents

Product Introduction ..................................................................3

Safety Precaution Information ....................................................4

Definitions ..................................................................................6

Electrical Requirements .............................................................7

Care and Maintenance ..............................................................7

Installation and Usage ...............................................................8

Packing List................................................................................ 8

Standard Installation Instructions............................................... 9

Configuring the Guest-Access Technique ................................. 9

Standard Auto-Sensing Feature ............................................... 10

Using MediaHub HD ................................................................ 10

Using Stereo Bluetooth…......................................................... 11

TV/STB Supported Installation –

For Implementing Auto-Switching Feature...............................13

Samsung North America .......................................................... 14

Panasonic North America......................................................... 16

Philips North America............................................................... 19

LG North America..................................................................... 21

Enseo Set Top Box................................................................... 23

LodgeNet PPV System ............................................................. 25

Troubleshooting MediaHub HD ...............................................26

How to Access the On-Screen Display .................................... 26

Troubleshooting Protocol Converter Dongle… ........................27

Technical Support

...................................................................... 28

Flush-Mount Cut Measurements

............................................... 29

Assemble Flush-Mount MediaHub HD with Power/Data .......30

Assemble Desktop Housing (DTH-HD01 or DTH-EXT) .........31

Add-On Accessories..........................................................33

iPodDocking Adapter IPODDONGLED60................................ 33

TA-7650 and TA-7750 Installation Manual

Last Revision: 9/30/11 11:23 AM

Product Introduction

Thank you for choosing the TeleAdapt MediaHub for your in-room entertainment or

conference room connectivity needs. MediaHub allows business and leisure

travellers to use the in-room TV display as their personal entertainment or projection

screen for enjoying their personal standard-and high-definition (HD) video games,

music playlists, movies, TV shows, photos, business presentations and more from

their portable electronic devices.

The MediaHub HD™ entertainment panel is unique as it features Stereo Bluetooth®

wireless technology. Hotel guests can pair their A2DP-enabled portable media

player with the MediaHub HD to stream personal music and audio choices through

the in-room TV and speakers, without having to physically connect the device with a

cable. MediaHub HD also features a single-HDMI back-end cable connection to the

TV for a more simple, faster installation process.

Please review this Installation Manual carefully, taking note of important safety,

installation and usage information.

This complete User and Installation Manual is available for download at

www.teleadapt.com.

TA-7650 and TA-7750 Installation Manual

Last Revision: 9/30/11 11:23 AM

Safety Precaution Information

When used in the directed manner, this unit has been designed and

manufactured to ensure your personal safety. However, improper use can result

in potential electrical shock or fire hazards. Please read all safety and operating

instructions carefully before installation and use. Be sure to keep these

instructions handy for future reference. Take special note of all warnings listed in

these instructions and on the unit.

The lightning flash with arrowhead symbol within an equilateral is intended to

alert the user to the presence of un-insulated dangerous voltage within the

product enclosure that may be of sufficient magnitude to constitute a risk of

electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user

to the presence of important operating and maintenance (servicing) instructions

in the literature accompanying the appliance.

Important Safety Instructions

1 |Read these instructions.

2 |Keep these instructions.

3 |Heed all warnings.

4 |Follow all instructions.

5 |Do not use this apparatus near water.

6 |Clean only with dry cloth.

7 |Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8 |Do not install near any heat sources such as radiators, heat registers,

stoves or other apparatus (including amplifiers) that produce heat.

9 |Do not defeat the safety purpose of the polarized or grounding-type plug. A

polarized plug has two blades with one wider than the other. A grounding

type plug has two blades and a third grounding prong. The wide blade or

the third prong are provided for your safety. If the provided plug does not fit

into your outlet, consult an electrician for replacement of the obsolete

outlet.

TA-7650 and TA-7750 Installation Manual

Last Revision: 9/30/11 11:23 AM

10 |Protect the power cord from being walked on or pinched particularly

at plugs, convenience receptacles and the point where they exit

from the apparatus.

11 |Only use attachments/accessories specified by the manufacturer.

12 |Use only with the cart, stand, tripod, bracket or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to avoid injury from tip-over.

13 |Unplug this apparatus during lightning storms or when unused for

long periods of time.

14 |Refer all servicing to qualified service personal. Servicing is required when

the apparatus has been damaged in any way, such as power-supply cord

or plug is damaged, liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, does not

operate normally, or has been dropped.

15 |The apparatus shall not be exposed to dripping or splashing and no objects

filled with liquids, such as vases, shall be placed on the apparatus.

16 |The mains plug used as disconnect device shall remain readily operable.

17 |To reduce the risk of fire or electric shock, do not expose this apparatus

to rain or moisture.

TA-7650 and TA-7750 Installation Manual

Last Revision: 9/30/11 11:23 AM

Definitions

A2DP –Advanced Audio Distribution Profile, the

Bluetooth

® protocol that is built

into MediaHub HD for streaming high quality audio wirelessly between devices.

For example, music can be streamed from a mobile smartphone to an in-room

stereo/TV speaker using MediaHub HD as the receiver.

Auto-Sensing –the automatic detection of a device plugged into an audio/video

port of the MediaHub. For example, MediaHub will auto-sense a Composite AV

source when a device is connected to the 3RCA ports and begin playing the

Composite AV Out content. When a laptop is plugged into the PC socket,

MediaHub will detect a PC Video source and switch toplay the laptop video.

Auto-Switching –the automatic switching of the TV input away from

regular tuner mode (TV Mode) to the MediaHub’s portable device content

(MediaHub Mode).

Control Cable –MediaHub HD uses serial or game control protocol for

implementing the TV auto-switching feature. Most hospitality TVs support control

protocols through the following ports:

RS232 Serial Port (DB9)

Serial Control Jack (3.5mm)

Ex-Link Serial Control Jack (3.5mm)

RJP (RJ45 LG Remote Jack Pack)

GAME/DATA (RJ12 on TV or STB)

DIP Switches –MediaHub HD has eight (8) DIP Switches located on the rear

of the unit. (Figure 1) These switches must be configured accordingly to allow

appropriate communication between MediaHub and TV/STB. See Installation

& Usage section for DIP Switch setting required for standard installation, and the

TV/STB-Supported Installation section for setting required for specific TV/STB

auto-switching installation.

RS232 –MediaHub HD supports RS-232 serial control protocol for implementing

the TV auto-switching feature. Most hospitality TVs support RS232 protocol through

their RS232 Serial port (circular port with nine pins), or through their 3.5mm Serial

Control port.

Figure 1: DIP switches located on the

rear of the MediaHub HD

TA-7650 and TA-7750 Installation Manual

Last Revision: 9/30/11 11:23 AM

Electrical Requirements

A 120-volt, 60Hz, 15-Amp electrical supply is required for the TA-7650. A

standard duplex (2) 120-volt, 60Hz, 15-Amp electrical supply is required for

the TA-7650 plus TA-7500L.

Care and Maintenance

Though TeleAdapt MediaHubs are designed for durability, they still remain

complex electronic devices. As such, care needs to be taken with how they are

handled. The following are tips to care for your system:

If the MediaHub has visible smudges, fingerprints, or other foreign material,

you can clean it by using a soft clean cloth such as a lens or eyeglass

cleaning cloth.

Slightly dampen a corner of the cloth with water and wipe off the unit

housing to loosen any dirt or foreign material. Using a dry portion of the same

cloth, wipe the housing to dry.

Do not use harsh chemicals, cleaning solvents, or strong detergents to

clean the MediaHub.

Your TeleAdapt MediaHub should never be positioned or installed anywhere

where it could get hit, dropped, or banged around.

Do not drop, knock, or shake the device. Rough handling can harm

internal operations.

Your MediaHub should be dry. Liquids or moisture can cause damage to

internal electronic circuits. If your unit gets wet, immediately remove power

allowing the unit to dry before re-applying power.

Do not store the MediaHub in hot areas. High temperatures can shorten the

life of electronic components and warp or melt certain plastics.

Do not attempt to open the MediaHub gaining access to the internal

infrastructure. Please notify TeleAdapt service and support personnel

regarding return materials authorization policy.

TA-7650 and TA-7750 Installation Manual

Last Revision: 9/30/11 11:23 AM

Disposal

The crossed-out wheeled-bin symbol on your product, literature, or packaging

reminds you that in the European Union all electrical and electronic products must

be taken to separate collection at the end of their working life. Do not dispose of

these products as unsorted municipal waste.

Return the products to collection to prevent possible harm to the environment or

human health from uncontrolled waste disposal and to promote the sustainable

reuse of material resources.

Installation and Usage

Packing List(s)

“x” characters denote part numbers that correlate to the power supply variations and product

trim types

TA-7650x-xx-x03

AMediaHub HD Connectivity Panel

BPower Supply with Cable

CFlat-Head Mounting Screws x4

DCable Ties x4

CAB-76503D5 MediaHub HD Cable Kit (3m)

EHDMI Cable CAB-40683D5

FRS-232 Control Cable CAB-04583D5 (for serial control, see TV/STB-Supported

Installation Instructions)

GOptional DB9-3.5mm Adapter CAB-4067D16 (for serial control, see TV/STB-Supported

Installation Instructions)

TA-7500L-xx-x03 (PowerHub Extender) includes:

HTA-7500 PowerHub unit (Power/Data Panel)with connected Power Supply Cable

IExtender Trim with micro mounting screws

Cat5 Ethernet Cable (3m)

Additional Flat-Head Mounting Screws x4

TA-7650 and TA-7750 Installation Manual

Last Revision: 9/30/11 11:23 AM

DTH-xxx Desktop Mount Kit also includes:

ADesktop Housing

DTH-HD01 for MediaHub HD

DTH-EXT for MediaHub HD with PowerHub Extender

90º HDMI Replacement Cable CAB-40683D5A

Rear Door Screws

Rubber Tabs

See

Assembling Desktop Housing section

for assembly instructions.

Standard Installation Instructions (for Manual Switch)

1 |While unplugged, ensure MediaHub rear DIP Switches are set to the following

positions

(Pg 6)

: UP - DOWN - UP - UP -- DOWN - DOWN - DOWN - DOWN

2 |Remove the back door of MediaHub HD.

3 |

Connect the HDMI and power supply to rear of the MediaHub HD.

4 |

Connect the HDMI cable to the TV’s HDMI port.

5 |Plug the MediaHub

HD power supply into a wall power socket.

6 | To fully install the MediaHub HD with PowerHub Extender, connect the Cat5

Ethernet cable to the rear of the PowerHub portion and plug other end into an

existing wall Ethernet jack. Plug the PowerHub power supply into a wall power

socket.

Configuring the Guest-Access Technique

Similar to installing a DVD player or other third-party component into a hospitality

in-room entertainment system, allowing guests to access the MediaHub HD plug

ports can be done through one of three common guest-access techniques.

Option 1:

“Channel map” the TV’s HDMI AUX port used to connect MediaHub HD

(e.g., HDMI1) to a number in the VOD/PPV/FTG channel roster. Using the

guest remote control, guests simply change the channel to the number

assigned to MediaHub HD.

Option 2:

Program the guest remote control to make the in-room TV’s HDMI AUX

available to the guest via the INPUT button. Using the guest remote

control, guests simply press the INPUT button to play content from the

MediaHub HD.

Figure 1: Desktop Mount Kit

HDMI

TV HDMI IN

TA-7650 and TA-7750 Installation Manual

Last Revision: 9/30/11 11:23 AM

Option 3:

Program the PPV/VOD GUI to offer the in-room TV’s HDMI AUX through

an on-screen prompt. Using the guest remote control, guests simply

follow the on-screen prompts to play content from the MediaHub HD.

Standard Auto-Sensing Feature

MediaHub HD has been engineered with a built-in auto-sensing audio/video

function. Multiple devices may be connected to the MediaHub HD at once. The

connectivity panel will recognize and automatically play content from the most

recently populated AV socket. To switch back to a previously used audio/video

port, press the LED/button above the desired AV socket.

Using MediaHub HD

When in use, MediaHub HD’s LED/buttons located above the sockets will light up notifying

you of which port is in use.

To change devices, plug in a new device using a new socket. TV will automatically play

content from the most recently populated socket. When connecting multiple devices, guests

may toggle between devices by pressing the LED/buttons located above the sockets.

Composite Audio/Video (3RCA):

Using a composite cable, provides audio and video

playback through the in-room TV. Compatible with any electric device that can use a

composite connection including iDevices, MP3 player, DVD player, game console, or

digital cameras.

BS-Video: Using an S-Video cable, provides video-only playback through the in-room TV.

Some Super Video-enabled video cameras, laptops, digital cameras and laptops. May

also couple the 2RCA stereo ports (red and white) of the Composite AV to provide paired

audio playback through the in-room TV speakers.

Otros manuales para TA-7650 MediaHUB HD

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Reproductor multimedia de TeleAdapt

TeleAdapt

TeleAdapt RoomCast TA2400 Manual de usuario

Manuales populares de Reproductor multimedia de otras marcas

Visual Land

Visual Land Impulse Manual de usuario

limHD

limHD 200i Manual de usuario

Transcend

Transcend DMP10 Manual de usuario

Philips

Philips GoGear Muse SA2MUS08 Manual de usuario

Fantec

Fantec MM-HDRL Manual de usuario

Dune HD

Dune HD Duo 4K Manual de usuario

IAdea

IAdea HMP-505S Manual de usuario

Camos

Camos MMS-1000 Manual de usuario

Energy

Energy 75 Series Manual de usuario

Z3 Technology

Z3 Technology DME-03 Manual de usuario

Sony

Sony SVR-2000 Guía del usuario

Meicheng

Meicheng HD-1080K12 Manual de usuario

DENAFRIPS

DENAFRIPS ARCE Manual de usuario

Topaz

Topaz CMS Media Player Instrucciones de uso

InFocus

InFocus LightCast Manual de usuario

IconBiT

IconBiT XDS1003D Manual de usuario

Quanmax

Quanmax QDSP-2090 Series Manual de usuario

Samsung

Samsung MP-80S Manual de usuario
