Tecumseh OHV155-204509E Manual de usuario

OHV155-204509EPage 1 of 5

Engine Parts List #1

OHV155-204509EPage 2 of 5

Engine Parts List #1

Ref # Part Number Qty Description

136300A Cylinder (Incl. 2,11B,20,72B & 314)1

227652 Dowel Pin2

11A 36303 Breather Plate1

11 36302 Check Valve1

11B 650902 Screw, 10-32 x 7/16"1

15 36307 Governor Rod1

20 36301 Oil Seal1

30 36308 Crankshaft1

31 36324 Counterbalance Gear1

40 36312 Piston, Pin & Ring Set (Std.)1

40 36313 Piston, Pin & Ring Set (.010" OS)1

40 36314 Piston, Pin & Ring Set (.020" OS)1

41 36309 Piston & Pin Ass'y. (Std.) (Incl. 43)1

41 36310 Piston & Pin Ass'y. (.010" OS) (Incl. 43)1

41 36311 Piston & Pin Ass'y. (.020" OS) (Incl. 43)1

42 36315 Ring Set (Std.)1

42 36316 Ring Set (.010" OS)1

42 36317 Ring Set (.020" OS)1

43 35772 Piston Pin Retaining Ring2

45 36318A Connecting Rod Ass'y. (Incl. 46)1

45 36319 Connecting Rod Ass'y. (.010" US) (Inc l. 46)1

45 36320 Connecting Rod Ass'y. (.020" US) (Inc l. 46)1

46 650908 Connecting Rod Bolt2

48 36321 Valve Lifter2

50 36533A Camshaft (MCR)1

51 36323 Counterbalance Weight1

52B 36333 * "O" Ring1

52A 36331 Oil Pump Shaft1

52 37305 Oil Pump Ass'y.1

52D 650888 Screw, Torx T-30, 1/4-20 x 43/64"3

52C 36334 Oil Pump Cover (Incl. 52B)1

60A 650781 Screw, 5-16/18 x 11/16"1

60B 650867 Screw, 10-24 x 1/2"1

60 36361 Air Baffle1

65 30063 Screw, Torx T-30, 1/4-20 x 1/2"1

66 650737 Screw, 1/4-20 x 1/2"1

69 36565 * Mounting Flange Gasket1

70 37304 Mounting Flange (Incl.72,72B,75,80,38 1-387)1

72A 28483 Oil Drain Plug2

72B 28534 Oil Drain Plug2

75 36301 Oil Seal1

80 35712 Governor Shaft1

81 35479 Washer2

82 36327 Governor Gear Ass'y.1

83 35322 Governor Spool1

84 29193 Retaining Ring1

86 650970 Screw, 1/4-20 x 1-15/32"9

89 650592 Flywheel Key1

90 611243 Flywheel (W/Ring Gear)1

91 611241 Flywheel Fan1

91A 611242 Flywheel Retainer1

100 36344 Solid State Ignition (Incl. 101)1

101 610118 Spark Plug Cover1

102 651024 Solid State Mounting Stud2

103 651007 Screw, Torx T-15, 10-24 x 15/16"2

110 36645 Ground Wire1

OHV155-204509EPage 3 of 5

Engine Parts List #1

Ref # Part Number Qty Description

119 36337 * Cylinder Head Gasket1

120 36488 Cylinder Head1

125 35308 Exhaust Valve (Std.)1

125 35433 Exhaust Valve (1/32" OS)1

126 35309 Intake Valve (Std.)1

126 35432 Intake Valve (1/32" OS)1

127 650691 Washer6

128 650690 Belleville Washer6

130 650946 Screw, 5/16-18 x 2-45/64"6

135 34645 Spark Plug (RN4C)1

150 33507 Valve Spring2

151 33508 Valve Spring Keeper2

153 36339 Push Rod Guide1

154 650972 Rocker Arm Stud2

155 35950 Rocker Arm2

156 36341 Rocker Arm Bearing2

157 650973 Screw, 5/16-24 x 1/4"2

158 36340 Push Rod2

159 35952 * Rocker Arm Cover Gasket1

160 35953A Rocker Arm Housing1

161 30063 Screw, Torx T-30, 1/4-20 x 1/2"4

169 36304 * Breather Gasket1

172 36305 Valve Cover1

173 36306 Breather Tube1

174 30063 Screw, Torx T-30, 1/4-20 x 1/2"4

265 36615 Cylinder Head Cover1

270A 35829A Exhaust Port Liner1

305 36349 Oil Fill Tube1

306 37401 * "O" Ring1

307 35499 "O" Ring1

309 650974 Screw, 1/4-20 x 57/64"1

310 36366 Dipstick1

314 651007 Screw, Torx T-15, 10-24 x 15/16"2

315 611181 Alternator Coil (3/5 Split)(Incl. 321 - 323)1

321 611161 Diode1

322 611142 Connector Body1

323 611118 Terminal1

325 36342 Wire Clip1

325B 37230 Wire Clip1

361 650969 Screw, 5/16-18 x 29/32"2

381 650767 Screw, 8-32 x 27/64"1

382 36328 Oil Strainer Screen1

385 570673 Ball1

386 36329 Pressure Relief Spring1

387 36330 Roll Pin1

394A 650982 Washer1

395 36795 Electric Starter Motor (12 Volt)1

400 36567 * Gasket Set (Incl. items marked PK i n notes) Incl. one

each of part #'s:35952, 36304, 36325, 36333, 36335, 36337,

36348, 36351, 36352, 36358, 36365, 36490, 36565

420 730225 SAE 30 4-Cycle Engine Oil (Quart)1

477 650971 Screw, Torx T-30, 5/16-18 x 7/8"2

478 36336 Oil Passage Cover (Incl. 479)1

479 36335 * Oil Filter Adapter Gasket1

OHV155-204509EPage 4 of 5

Engine Parts List #2

OHV155-204509EPage 5 of 5

Engine Parts List #2

Ref # Part Number Qty Description

14 28277 Washer2

16 36346A Governor Lever1

17 29916 Governor Lever Clamp1

18 651028 Screw, Torx T-15, 8-32 x 3/8"1

19 36414 Extension Spring1

28 30322 Lock Nut, 8-321

35 29826 Screw, 10-32 x 3/4"1

36 29918 Lock Washer1

37 29216 Lock Nut, 10-321

38 29642 Retaining Ring1

60C 650737 Screw, 1/4-20 x 1/2"1

60A 650781 Screw, 5-16/18 x 11/16"1

60B 650867 Screw, 10-24 x 1/2"1

92 650666 Lock Washer1

93 650594 Flywheel Nut1

110A 36917 Ground Wire (Solenoid)1

178 650928 Lock Nut, 1/4-202

182 650925A Carburetor Mounting Stud2

184 36352 * Carburetor To Intake Pipe Gasket1

185 36852 Intake Pipe1

186 36354 Governor Link1

200 36233 Control Bracket (Incl. 203,204,212A)1

203 36482 Compression Spring1

204 650777 Screw, 6-32 x 21/32"1

209 650902 Screw, 10-32 x 7/16"2

210 27793 Conduit Clip2

211 28942 Screw, 10-32 x 3/8"2

212A 36288 Bushing3

223 650975 Screw, Torx T-30, 5/16-18 x 1-9/32"2

224 36490 * Intake Pipe Gasket1

228 650977 Air Cleaner Stud2

234 650825 Nut & Lock Washer, 1/4-202

239 36358 * Air Cleaner Gasket1

240 36355 Air Cleaner Body (Incl. 228 & 239)1

245A 36357 Air Cleaner Filter1

245 36356 Air Cleaner Filter (Incl. 234)1

250 36359 Air Cleaner Cover1

251 650886 Wing Nut, 1/4-202

252 650976 Screw, 1/4-20 x 19/32"1

260 36347 Blower Housing1

262 650737 Screw, 1/4-20 x 1/2"3

263 36367 Trim Ring1

286 36343 Cup & Screen1

291 30705 Fuel Line1

292 26460 Fuel Line Clamp2

296 34279B Fuel Filter1

326 36210 Screen Plug1

347 650949 Screw, 10-32 x 9/16"3

348 36383 Choke Bracket1

370G 35274 Oil Instruction Decal1

380 640034A Carburetor (Incl. 184 & 212A)1

394A 650982 Washer1

406 611221 Fuel Shut-Off Solenoid1

406A 36918 Solenoid Spring1

485 36435A Oil Filter Adapter Kit (Optional)1
