REFRIGERATOR / FREEZER

User Manual

IMPORTANT NOTE:

Thank you for selecting a TECO quality Refrigerator. Please

read this manual carefully before installing or operating your new

appliance. Make sure to save this manual for future reference.

The design and specifications are subject to change without prior

notice for product improvement.

Model:

TBF86WMTAG

TBF86SMTAG

TBF86BMTAG

TABLE OF CONTENTS

Parts and features...................................................................... 4

Important safety instructions...................................................

Installation instructions............................................................

Operating instructions..............................................................

Cleaning.....................................................................................

Defrosting..................................................................................

Power failure.............................................................................

Vacation.....................................................................................

Moving the refrigerator............................................................

Troubleshooting tips...............................................................

Reversing the door.................................................................

Replacement of interior light.................................................

Specifications.........................................................................

Repairs, service & warranty..................................................



Thank you for purchasing our product and thank you for placing your

confidence in us.



Read this manual carefully before use. Follow instructions and keep

the manual for future reference.



Follow the operating instructions and safety notices in this manual.



If any trouble arise, do not attempt to fix it yourself. Please contact

TECO service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST).



This refrigerator is designed and approved for use with flammable

R600a refrigerant.



The appliance is specifically constructed for domestic use only.

The appliance has not been designed or manufactured for

professional use. TECO declines all responsibility for damage

deriving from improper use of the appliance. The refrigerator

has undergone the necessary tests on the tightness of the

refrigeration circuit and complies with the safety regulations

for electrical appliances.



All images, illustrations and photos contained in this manual are for

illustration purposes only and may differ from your appliance.

R600a

WARNING

CAUTION















 

IMPORTANT SAFETY INSTRUCTIONS

R600a Isobutane Refrigerant

•This appliance contains a small quantity of

flammable, non-synthetic R600a refrigerant.

•The room for installing the appliance must be at

least 1m3 per 8g of refrigerant. The amount of

refrigerant in the appliance can be found on the

rating plate attached to the appliance.

Risk of ﬁre

•If the refrigerant circuit should become damaged.

Avoid open flames and sources of ignition.

Disconnect the appliance from the mains power.

Thoroughly ventilate the room in which the

appliance is situated for several minutes.

•The refrigerator is designed to operate on a single phase

power supply within a voltage range of 220~240V/50Hz.

•The refrigeration system contains refrigerant. Do not allow

any sharp objects to come in contact with the refrigerant

system to avoid damage the refrigerant circuit.

•This product is for indoor use only.

•Do not place electrical items or cooking equipment nearby.

Keep away from substances which could cause ignition

and good ventilation shall be always maintained.

•Do not place objects on top of the appliance which are

magnetic, heavy or filled with water.

•If the supply cord is damaged, it must be replaced by

authorised TECO service personal, service agent or similarly

qualified persons in order to avoid a hazard.

•Do not store flammable, explosive, volatile and highly

corrosive materials in the refrigerator. Containers with

flammable gases or liquids can leak at low temperature. There

is a risk of explosion or fire.

•Do not splash water on the appliance. It may cause malfunction

or electric shock.

•Always switch off and unplug appliance before cleaning.

WARNING

•Keep ventilation openings, in the appliance enclosure or in the

built-in structure, clear of obstruction.

•Do not use mechanical devices or other means to accelerate the

defrosting process, other than those recommended by the

manufacturer.

•Do not use electrical appliances inside the food storage

compartments of the appliance.

•For appliances which use flammable insulation blowing gases,

Please keep the products away from the fire or similar glowing

substance.

•This appliance is intended to be used in household and similar

applications such as:

- staff kitchen areas in shops, offices and other working environments;

- farm houses and by clients in hotels, motels and other residential type

environments;

- bed and breakfast type environments;

- catering and similar non-retail applications.

•This appliance is not intended for use by persons

(including children) with reduced physical, sensory or

mental capabilities, or lack of experience and

knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a

person responsible for their safety.

•Young children should be supervised to ensure that they do not

play with the appliance.

•Packing (e.g. wraps, polystyrene etc.) can be dangerous

for children. There is a risk of suffocation. Keep packaging

materials away from children.

•Contact your local authorities for correct method of disposal.

Dispose of all packaging in a responsible manner in accordance

with local regulations.

Dispose of old appliances in accordance with local

regulations. Remove the doors, cut off the main cable,

break or remove spring or bolt catches if fixed to prevent

children getting trapped or involve themselves in other

dangers.

WARNING

PARTS AND FEATURES

1. Freezer compartment

2. Interior light and temperature control knob

3. Removable glass shelf

4. Glass crisper cover

5. Vegetable crisper

6. Bottle storage

7. Can dispenser

INSTALLATION INSTRUCTIONS

1. Before using the refrigerator for the first time, remove all of the

packing materials, including the foam base and adhesive tape holding

accessories in place.

2. The refrigerator should be located on a firm, flat surface that is strong

enough to support the refrigerator when it is fully loaded.

3. Choose a location that is not exposed to direct sunlight, high

temperatures, heat sources such as a stove or radiator, or in a moist

area. Do not choose a location where the temperature will go below

12°C as this could cause the refrigerator to not function properly.

4. Leave a minimum of 50mm between each side of the appliance and

the wall. The top of the appliance should have a minimum of 300mm

clearance. This allows for proper air circulation. This appliance is

intended to be free-standing and should not be built-in or placed in a

recessed area.

5. The refrigerator legs must be adjusted during installation in order to

function properly. The leveling legs on the front corners can be

adjusted by turning clockwise to raise the appliance, and counter-

clockwise to lower it. Be sure to have the appliance slope slightly

backward to ensure that the door closes tightly.

OPERATING INSTRUCTIONS

1. Allow refrigerator to stand up right for 4 hours before using.

2. Plug into a grounded outlet.

3. Use the control dial to control the temperature of the

refrigerator manually. As shown in Figure, The numbers

shown on the dial does not represent the temperature,

instead the larger number is, cooler the interior

temperature. To stop the cooling, turn the dial to "0".

Do not switch off the power.

•Turn the knob to number "4" for normal use.

•Turn the knob to number "5-7", when cooler temperature needed.

•Turn the knob to number "1-3", when warmer temperature needed.

4. Food should be kept in a sealed container to prevent odors or

drying.

5. Hot food should be cooled down before placing into the appliance

to prevent an increase in interior temperature and power

consumption. Adding food in too soon will impact the performance.

6. Reducing the frequency of door opening can lower power

consumption.

CLEANING

Interior

Clean the interior of the appliance with a mixture of warm water and

baking soda, using about 1–2 tablespoons per liter of water. Use a

sponge or soft cloth and be sure to wring excess moisture out before

cleaning around the controls.

Rinse thoroughly with warm water and dry with a clean, soft cloth.

Exterior

The exterior surface can be cleaned using warm water and a mild

detergent.

Rinse thoroughly and dry with a clean, soft cloth.

Door Gasket

The door gasket must be kept clean to ensure a proper seal. Be sure

to clean the gasket frequently, using the method described above.

DEFROSTING

Frost build-up on the walls of the ice making section will increase

energy consumption and reduce the efficiency of the appliance.

Defrost the section whenever the frost reaches a thickness of 5mm.

1. Remove food from the refrigerator and ice making compartment.

The appliance should be maintained and cleaned

frequently. For your safety, unplug the appliance from

the mains power source before performing any

maintenance.

WARNING

2. If your model has a drip tray, be sure to place it under the ice making

compartment to collect water. It may be necessary to empty the drip

tray during the defrosting process.

3. Turn the unit off and unplug it from the outlet.

4. The defrosting process can take several hours. Open the door to

speed up the process.

5. When defrosting is completed, wipe the compartment with a soft cloth

to remove any remaining water.

6. Reset the refrigerator to the desired temperature.

7. Refer to Operating Instructions.

POWER FAILURE

When a power failure occurs, the refrigerator can normally store food

for several hours. Do not put additional food into the appliance during a

power failure, and do not operate door. Disconnect the plug from the

outlet, and reconnect when the power has been restored. Always

inspect for, and discard, any spoiled or thawed food in the

refrigerator before resuming use of the appliance.

VACATION

Before leaving on any vacation, remove food that could spoil while you

are gone. If you plan to be gone for an extended period of time, we

recommend that all of the food should be removed from the appliance

and it should be turned off and unplugged from the outlet. Clean the

interior according to the directions provided in the CLEANING section of

this manual, and leave the door open.

ATTENTION: Do not use sharp or pointed objects to

remove frost or ice from the surfaces of the ice

making compartment. This can cause damage to the

compartment walls and cooling coils, and will void the

warranty.

CAUTION

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

Electrolux

Electrolux ER 6821 D Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario
