Tecnoalarm TP8-96 Manual de usuario

USER MANUUSER MANU

USER MANUALAL

ALAL

Release: 1.0

Update March2011

Language: English

FWversion 0.7.05-->

TP8-96 VITP8-96 VI

TP8-96 VIDEODEO

DEODEO

DEO

EN60950-1

EN50130-4

EN50081-1

8 TO 96 ZONES EXPANDIBLE

CONTROL PANEL WITH

INTEGRATED ETHERNET

1-2 User manual Ver.1.0 - 03/11 TP8-96 VIDEO

The product features can be subject to change without notice. Unauthorized reproduction or distribution of this manual,

or any portion of it, on any device and in any form, is prohibited. The contents of this manual may be subject to change

without notice

1-3

Ver.1.0 - 03/11 User manualTP8-96 VIDEO

CONFORMITY

Hereby, Tecnoalarm srl declares that the present equipment is in compliance with the essential requirements and other

relevant provisions of the R&TTE 1999/05/EC directive.

The declaration of conformity is available on the website: www.tecnoalarm.com.

1-4 User manual Ver.1.0 - 03/11 TP8-96 VIDEO

1-5

Ver.1.0 - 03/11 User manualTP8-96 VIDEO

Index

1 - General features

TP8-96VIDEOsystem...............................................................................................................Page 7

Master code................................................................................................................................Page 7

Standardusercode.................................................................................................................... Page 8

Controlbytelephone...................................................................................................................Page 8

Functioning...................................................................................................................................Page 8

2 - Console LCD300/S

SignalingoftheconsoleLCD300/S..........................................................................................Page 9

Arming-Singleandmultiplearming.........................................................................................Page 11

Arming-Directarming............................................................................................................... Page 11

Disarming-Singleandmuultipledisarming............................................................................ Page 12

Disarming- Directdisarming................................................................................................... Page 12

Arming-Exclusionofopenzones.............................................................................................Page 13

Hold-upalarmrelease................................................................................................................ Page 13

Panicalarmrelease....................................................................................................................Page 14

3 - Key point PROX K6N

Signalingof thePROXK6N......................................................................................................Page 15

Arming.........................................................................................................................................Page 16

Arming-Exclusionofopenzones.............................................................................................Page 15

By-pass........................................................................................................................................ Page 15

Disarming....................................................................................................................................Page 16

Panicalarmrelease....................................................................................................................Page 16

4 - Programming of the console LCD300/S

Accesstoprogramming.............................................................................................................Page 19

Clockmenu..................................................................................................................................Page 20

Functionmenu............................................................................................................................. Page 20

Programmenu.............................................................................................................................Page 21

Timemenu-Timers....................................................................................................................Page 23

Timemenu-Accessperiods.....................................................................................................Page 25

Telephonemenu-GSM.............................................................................................................Page 28

Telephonemenu-Tecnocell......................................................................................................Page 29

Telephonemenu-Channels...................................................................................................... Page 33

Telephonemenu-Callback...................................................................................................... Page 34

Codemenu-Mastercode......................................................................................................... Page 35

Codemenu-Standardusercodes...........................................................................................Page 37

1-6 User manual Ver.1.0 - 03/11 TP8-96 VIDEO

Keysmenu................................................................................................................................... Page 39

Wirelesskeymenu..................................................................................................................... Page 41

Consolesmenu............................................................................................................................Page 43

Keypointmenu.............................................................................................................................Page 45

Exclusionmenu............................................................................................................................Page 46

Testmenu.....................................................................................................................................Page 47

Optionmenu................................................................................................................................ Page 49

5 - Controle by telephone

Remotecontrol............................................................................................................................Page50

Index

1-7

Ver.1.0 - 03/11 User manualTP8-96 VIDEO

General features

TP8-96 VIDEO SYSTEM

The security system TP8-96 VIDEO is a new generation equipment which is able to control up to 96 zones.

The control panel is programmed by the installer using a PC or the console LCD300/S.

The end user can make simple settings through the console.

Accesslevels

TheTP8-96 VIDEOsystempermitstwoaccesslevelsformanagement/programmingofitsfunctions.

Master level

Themasterlevelpermitsprogrammingof the user functionsaswellasarming/disarmingof the control panel and

activation/deactivationoftheremotecontrols.

To enter the master menu enter the master code (it is usually given by the installer to the owner of the system).

Thedefaultmastercodeis:12345

Standard user level

Thestandard userlevel permits only simple functions such as arming/disarming of the controlpanel. Typeone ofthe

usercodes to enterthe standard usermenu (until 200codes are available).Theuser codesareprogrammed bythe

holderof the mastercode.

Operations executable by the master code

Programming

- Clock setting

- Association of chime to the zones (acoustic signaling for zone opening)

- Creationandmodificationofprograms

- Programmingof64timersforautomaticarming

- Programmingof 8 access periods during which codesand keysare enabled

- ProgrammingoftheGSM section

- ProgrammingoftheexternalGSMcommunicator

- Programmingof8telephonechannels

- Enabling of the call back function

- Programming of the master code and its attributes

- Programmingofthestandardusercodesandtheirattributes

- Programmingofthetranspondersandtheirattributess

- Programmingof the wireless keys and their attributes

- Programmingof theconsoles

- Programmingofthekeypoints

- Access to the exclusion menu

- Accesso to the test menu

- Access to the option menu

Operations executable through the console

- Activation/deactivationoftheremotecontrols

- Armingoftheprograms

- Totaldisarmingofthecontrolpanel(allprograms)

- Partialdisarmingofthecontrol panel

- Directarming/disarmingofallprogramsofthecontrolpanel

- Readingoftheeventbuffer

- Resetofalarmmemorysignaling

- Abortofthe active telephonecalls

1-8 User manual Ver.1.0 - 03/11 TP8-96 VIDEO

Operations executable by the standard user codes

Programming

Thestandardusercodesdonotpermitprogramming.

Operations executable through the console (many of these functions are only available if the code has been

enabledfor)

-Activation/deactivationoftheremotecontrols

-Armingofthe programs

-Totaldisarmingoftheprograms

-Partialdisarmingoftheprograms

-Direct arming/disarming of allthe programs

-Readingoftheeventbuffer

-Resetof alarm memorysignaling

-Comunicatorblock(abortoftheactivetelephonecalls)

Control by telephone

Someoperations can be executed by telephone, calling the controlpanel whichanswers emitting a confirmation beep.

Enter the master code or one of the standard user codes to enter telephone menu.

Functioning

The control panel can be armed through the programs (1 to 8) which can be set up by the installer and by the holder of

the master code.

Theprogramsgroupthezones which are enabledforthedetection of the alarmswhentheprogramis armed.

Theprogramscanbearmed one at time (single arming) orseveralsimultaneously.

1-9

Ver.1.0 - 03/11 User manualTP8-96 VIDEO

Signaling of the LCD300/S console

TheLCD300/S console permits arming/disarming of the programs, it alsopermits interactionwith theremote controls,

moreoveruserswhoareenabledcanentertheprogrammingmenus.

Theconsoleprovides two groupsofLED; the first,belowthe display, represents generalsignalingof the controlpanel;

the second, below the keypad, is composed of 15 pairs of LED for viewing of the status of the associated programs.

General alarm LED -

The system constantly checks its functions, any trouble is immediately signaled. The LED is

blinking while the alarm is active. As soon as the alarm stops, the LED becomes lit to signal alarm

memory.

The signaling of alarm memory continues until it is reset. The general alarms are stored in the event

buffer.

If the LED is blinking slowly, it signals a general alarm. If it is blinking quickly, it signals a GSM

trouble.

1-10 User manual Ver.1.0 - 03/11 TP8-96 VIDEO

CM LED

As soon as the user starts pressing the keys, the CM (comand mode) LED is lit signaling that the

console is in use. All the other consoles of the system are automatically inhibited.

It is switched off 10 seconds after stroke the last key and all the other consoles are enabled again.

Tamper alarm LED

TheLED signals tamper alarm. The anti-tamper protectionof the system is always active evenif the

programsaredisarmed.

ThetamperalarmLEDcan be:

OFF - notamper alarm

Blinking-tamper alarmactive

ON - alarm memory. The signaling of alarm memory contiunes until it reset. The tamper alarms are

storedintheeventbuffer.

Low battery alarm LED

TheLED signalslow batteryalarm.

The low battery alarm LED can be:

OFF-batteryvoltage is OK

Blinking - batteryvoltage islow (low batteryalarm active)

ON - battery failure. The battery is not able to support the system anymore.

Power failure alarm LED

TheLEDsignalspower(230VAC)failure.

ThepowerfailurealarmLEDcanbe:

OFF - mains power is OK.

Blinking-powerfailurealarmactive

ON - alarm memory. Mains power has been missing.

Mains power LED

TheLEDsignals the presenceofmains power (230VAC).

ThemainspowerLED can be:

OFF - mains power is missing

ON - mains power is present
