Tecno T473 Manual de usuario

Mobile Explode picture

Item

Descripition

Item

Descripition

LCD Lens

Front Housing

LCD

Front Camera

PCBA

SPK

CAM Frame

Rear Housing

CAM Lens

Screw

Battery Cover

Battery Label

Back CAM

Mot coin

Fraglle Label

IMEI Label

Water-proof Label

Done

Main key

Label

Foreword

Valuable mobile phone user, thank you for choosing our

mobile phone!

Our mobile phones reply to the People's Republic of

China communication industry standards and the

European standards and are approved for GSM networks.

Your phone may be used internationally with various

networks depending on your roaming arrangements with

your service provider.

To use this phone you must subscribe to a GSM service

from a provider. We have included many features in this

device but their function depends on the features

available on your subscribed wireless network. Please

contact your service provider for more information.

We strongly recommend you to carefully read and

understand this manual before using your phone in order

to keep it under best conditions for your effective usage

and utmost satisfaction.

1. Quick start

Install SIM card

This phone supports two GSM SIM cards. Find SIM card’s

groove in the back of the phone and slide it completely

there. During installation, please make sure insert the SIM

card into slot completely and pay attention to slot

direction.

Installing T-flash card

1. First switch off the phone and remove the battery.

2. Place the memory card into the SD card slot with the

metal contacts facing down.

Installing Battery

Align the battery chip with the metallic salient point in

battery jar; insert the battery until it is inserted into the

battery jar. Install the back cover into the back of the

phone until it is locked.

Battery Charging

Check the model number of any charger before use with

the device. Connect the charger to a wall outlet, and

connect the plug from the charger into the USB port on the

bottom of your phone. If we charge it with electricity, the

phone’s battery icon will move. After charging is finished,

just pull out the plug.

Switching on/off

Long press the power on/off key to switch on or off.

2. Call function

Dialing

1. Direct dial

In standby mode, press the corresponding numeric keys

to enter the phone number that you want to dial, including

necessary area codes. Short press the right soft key to

delete one character, and long press to delete all inputs, if

only one SIM card is inserted, press the dial/receive key to

dial, if two SIM cards are inserted, the phone displays

select SIM card page, if you select SIM1 then use SIM1 to

dial, you select SIM2, then use SIM2 to dial.

2. Making an international call

To make an international call, long press 0 key until the

prefix symbol "＋" of international call displays in screen.

3. Dialing from Contacts

Enter the contacts via the menu, use the up/down

navigator keys to scroll to the desired contact, or press the

first letter of the name of the desired contact as saved in

your contacts for quick access to names beginning with

the letter then scroll to the desired, press the dial/receive

key to dial.

4. Dialing from call history

Enter the call center (press the dial/receive key from

standby or via the menu), use the up/down navigator keys

to scroll to the desired contact, press the dial/receive key

to dial.

5. Dial emergency service

You can directly dial the emergency service number

without SIM card. Different networks use different

emergency service numbers, so for details please inquire

the network operation company.

Receiving calls

When there is an incoming call, the phone will give

corresponding alert, if your network supports caller ID, the

screen will display caller’s name or number (depending on

whether there is information of the caller in your

phonebook).

3. Menu functions

Contacts

You can use the phone's contacts feature to save the

contact name, number. The phone can save contacts on

the phonebook, the number of contacts that can be stored

in a SIM card varies according to their capacity.

Enter the contacts screen, you can add new contact, view

contacts list and select the contacts to call or other

operations.

SMS

Message service is a network dependent function, which

allows you to send, receive and edit all kinds of messages.

Please contact the network operator for more details.

Write message

Edit a new message, save or send it to the recipient.

Inbox

Received messages can be stored either in phone or in

SIM card memory, and are accessed here.

When you have received a message, the tones or

vibration will alert you and message mark will also be

shown on the screen. you can also access the inbox to

read the new message.

If the message memory is full, the indication “Memory full”

and the message icon will be shown and flashed on the

screen. Before you receive new messages, delete some

of your old messages in the inbox folder. If the capacity of

new messages is beyond the capacity of the inbox, the

information will be lost and incomplete.

Outbox

The SMS that failed to be sent, will be stored in the

outbox, the operation is the same with inbox.

Sent messages

If SMS is sent successfully, then it will be stored in the

sent messages box. But automatically save messages

need to select, other operation is the same with inbox.

SMS Settings

SIM settings: you can choose either of modes, custom

different parameters, including set short message center

number, set delivery report, reply path, voicemail server.

Memory status: can view the memory storage status.

Save sent message: open the function, after the SMS is

successfully sent it will be automatically saved in the sent

message.

Preferred storage: you can choose to give priority to

messages stored in SIM card or mobile phone.

Calls

This phone can record received, dialed and missed as

well as their call time. Only when related function is

supported by network and phone is switched on and in

network service area. Pressing the dial/receive key from

standby or accessing through the menu may access call

records.

In the call history list, press the left/right navigation key,

switch to display list of all /dialed/received/missed calls.

Once on the call records list, press the dial/receive key to

make a call; press the OK key to view the details of

current call record; press the left soft key into the options

to operate.

Settings

Phone settings

Time and date: in this function, you can choose menu to

set the current time and date in idle screen, include set

home city, set time/date and format etc.

Language: in this function, you can choose the language

provided by the phone.

Dedicated keys: you can change the navigation keys

function corresponding to the shortcut in the idle screen.

Display: in this function, you can choose menu to set the

idle screen display, include wallpaper, screen auto lock,

power on/off display etc.

Flight mode: this optional mode in which the phone is

normal mode or flight mode, if you choose the flight mode,

the phone can only use some of the functions of

non-communications.

Power saving management: for your battery long standby,

you can turn on the power saving mode, it will

automatically switch to the lowest state in this mode.

Call settings

SIM call settings: in this function, you can choose menu to

set the SIM call function, including call waiting, call divert

etc.

Advanced settings: in this function, you can choose menu

to set the call function, include Auto redial, Answer mode

etc. Please refer to the actual function of your phone.

Security settings

SIM security: PIN code can prevent your SIM card from

unauthorized use, you can turn on or off this feature, but

you need to enter the correct PIN code. After the function

is enabled, the phone will prompt you to enter the PIN

code, when turned on every time. You can also change

the PIN, PIN2. But the original password is required to

support your network operator.

Phone security: you can on or off the phone password,

phone password on or off are required to enter the correct

password. Once opened this feature, the phone will

prompt you to enter password, when turned on every time.

You can make changes on the phone password.

Network settings

You can automatically or manually select the network, the

phone SIM card will be based on the network where the

first selection was done, select manual, you need to select

the SIM card registered with the network operator that can

use the same network.

Connectivity

Data accounts: you can choose the Internet account. You

can add Internet accounts by yourself.

Restore settings

Restore settings password is 1234, when you enter the

password and confirm, the phone will restore to the

factory settings.


This feature is convenient for users to view the photos

stored in albums, you can view image information, send

images by BT, set the image use as wallpaper, delete and

more operations.

Camera

Your phone fitted with camera allows you to take photos

whenever possible. You can store the pictures in phone or

memory card.

Into the camera preview screen, press the OK key to take
