Technica Engineering USB-100BASE-T1 Manual de usuario
USB-100BASE-T1
CONVERTER
Hardware-Version: 2.2
USER MANUAL
Manual-Version: 2.1.2.
March 2019
USB-100BASE-T1 Converter User Manual
2
Content
1GENERAL INFORMATION .................................................................................... 3
1.1 Functionality and Features of the USB-100BASE-T1 Converter .................... 3
1.2 Warranty and Safety Information .................................................................. 4
2HARDWARE INTERFACES ................................................................................... 5
2.1 Connectors.................................................................................................... 5
2.1.1 Black MQS Connector............................................................................. 5
2.1.2 Universal Serial Bus Connector .............................................................. 6
2.2 Other Interfaces ............................................................................................ 6
2.2.1 Status LED .............................................................................................. 6
3INSTALLATION.................................................................................................... 7
3.1 Driver Installation .......................................................................................... 7
4CONFIGURATION .............................................................................................. 14
4.1 NIC settings (information)........................................................................... 16
5ADDITIONAL INFORMATION............................................................................. 20
6LIST OF FIGURES............................................................................................... 21
7CHANGELOG ..................................................................................................... 22
8CONTACT.......................................................................................................... 23
USB-100BASE-T1 Converter User Manual
3
1GENERAL INFORMATION
1.1 Functionality and Features of the USB-100BASE-T1
Converter
Figure 1-1: USB-100BASE-T1 Converter
The Technica Engineering USB-100BASE-T1 Converter transmits data frames from
the physical layer BroadR-Reach (100BASE-T1) to USB 2.0-LAN.
Features:
•1 port 100BASE-T1 with Broadcom BroadR-Reach Technology
•1 port USB 2.0 mini B
•1 Status LED
USB-100BASE-T1 Converter User Manual
4
General Information:
Power requirement:
5V
Power consumption:
2,5 Watt
LINKS:
The User can download the latest firmware and documentation for the USB-100BASE-
T1 Converter here:
https://technica-engineering.de/en/produkt/usb-100base-t1-converter/
1.2 Warranty and Safety Information
Before operating the device, read this manual thoroughly and retain
it for your reference.
The latest documentation for the USB-100BASE-T1 Converter here:
https://technica-engineering.de/en/produkt/usb-100base-t1-
converter/
Use the device only as described in this manual.
Use only in dry conditions.
Do not apply power to a damaged device.
Do not open the device. Otherwise warranty will be lost.
This device is designed for engineering purpose only.
Special care has to be taken for operation.
Do not use this device in a series production car.
As this device is likely to be used under rough conditions, warranty
is limited to 1 year.
Manufacturer liability for damage caused by using the device is
excluded.
USB-100BASE-T1 Converter User Manual
5
2HARDWARE INTERFACES
2.1 Connectors
On the label on top of the device you can see an overview about all HW-Interfaces of
the USB-100BASE-T1 Converter.
2.1.1 Black MQS Connector
The pinning of the ECU connectors is listed on the label on top of the device as well.
(See FIGURE 2-1)
The Connector color is black.
Figure 2-1: Label of USB-100BASE-T1 Converter with pinning information
USB-100BASE-T1 Converter User Manual
6
The Tyco Electronics (TE) Micro Quad Lock System (MQS) is used.
Name
Part Number
Tyco, MQS Buchsengehäuse 3 Pol
4-1718346-1
Tyco crimp contact
928999-1
Table 2-1: Parts of black MQS connector
Note: You can use the official Tyco tool for these crimp contacts. A cheap variant is
the crimp tool for “PSK” contacts.
Pin
Function
1
n.c.
2
100BASE-T1 port, positive
3
100BASE-T1 port, negative
Table 2-2: Pinning of black MQS connector
2.1.2 Universal Serial Bus Connector
There is one USB 2.0 mini B Port for connection to a laptop or PC. Since the chip used
is a USB-LAN chip, your PC will identify a new Ethernet Network Interface Card.
2.2 Other Interfaces
2.2.1 Status LED
The USB-100BASE-T1 Converter has one status LED at the frontside of the case for
the 100BASE-T1 Port.
It is lit when there is linkup. It is toggling when there is communication.
Note: There is a bug in the used BroadR-Reach PHY. When the BR Plus and Minus
lines are swapped, and the 100BASE-T1 port is set to Slave then the Link LED is lit,
but there is no data transmission possible. So please ensure that the 100BASE-T1
lines (positive/positive and negative/negative) are connected correctly.
USB-100BASE-T1 Converter User Manual
7
3INSTALLATION
3.1 Driver Installation
A driver is available for following operating Systems (version 1.4):
•Linux x64
•Windows x32
•Windows x64
Download-link
https://technica-engineering.de/en/produkt/usb-100base-t1-converter/
For Windows, please follow the described steps for installation:
1) Connect your USB-100BASE-T1 Converter device to your computer
2) browse your driver installation data folder and double click on the setup called
“USB-BR_1.4”
Figure 3-1: Driver Installation Data Folder
Accept the prompt to install the application.
3) Follow through the Wizard menus as shown below:
USB-100BASE-T1 Converter User Manual
8
Figure 3-2: Driver Installation Start Up screen
USB-100BASE-T1 Converter User Manual
9
Figure 3-3: Driver Installation Terms and Conditions
USB-100BASE-T1 Converter User Manual
10
Figure 3-4: Driver Installation
