2
4Front Gear-box
3Diff
差速器
前齿轮箱
Bag-B
Bag-B
......................8
M3x8螺丝
M3x8 Screw
FS308
M3x12螺丝
M3x12 Screw
曲面
Surface
FS312
齿轮-16T
Gear-16T
T04041
5x8x0.2垫片
5x8x0.2 Washer
W5802
5x10x4轴承
5x10x4 Ball Bearing
B051004
前齿轮箱-上盖
Front Gear-box-Cover
T04138
前齿轮箱-底座
Front Gear-box-Lower
T04138
M3x10螺丝
M3x10 Screw
BS310
M2.5x6螺丝
M2.5x6 Screw
T04040
差速轴
Diff Shaft
TS4039
齿轮-10T
Gear-10T
TS4039
摆臂固定座-FR
Arm Mount-FR
T04128
85中CVD
85mm Center CVD
T04116
.........................1
M3x8螺丝
FS308 M3x8 Screw
.....................2
M3x12螺丝
FS312 M3x12 Screw
.....................2
M3x10螺丝
BS310 M3x10 Screw
5x8x0.2垫片
W5802 5x8x0.2 Washer
..................................2
5x10x4轴承
B051004 5x10x4 Ball Bearing
........…………..2
Oil
5000#用於前差速器，2000#
用於後差速器。
高抓地力：
前面建議使用7000#差速油，
後面建議使用3000#差速油；
低抓地力：
前面建議使用3000#差速油，
後面建議使用1000#差速油。
5000# for Front diff，
2000# for Rear diff．
High grip:
Suggest using 7000#
differential oil for front,
Suggest using 3000#
differential oil for rear;
Low grip:
Suggest using 3000#
differential oil for front,
Suggest using 1000#
differential oil for rear.
.....................4
差速轴
TS4039 Diff Shaft
x2
M2.5x6螺丝
T04040 M2.5x6 Screw
