TECHNICAL BULLETIN 26-May-

2000

Page 1of 1

MODEL: CT-M685

PROBLEM:

No color via RF or AV inputs

File: CTM685 color tb.doc

This problem affects both RF and for AV inputs either for PAL or NTSC formats.

Instructions

Replace the capacitor C363.

Replacement Information

Position C363

Value 10 nF (0.01 uF)

Voltage 50V

Type Ceramic

Tolerance +80% -20%

Connected to Pin 14 of IC037, TDA4650

Part number 12310337090

Regards,

Alcides Berta

TEAC Australia Pty Ltd.

TECHNICAL BULLETIN 3-Aug-2000

Page 1of 1

MODEL: CT-M685

PROBLEM: Picture problems

File: CTM685 neg-blank-lines tb.doc

A faulty ceramic capacitor produces any of these effects on the picture:

•Negative picture

•Blank picture

•Horizontal lines

Instructions

Replace the capacitor C330.

Replacement Information

Position C330

Value 10 nF (0.01 uF)

Voltage 50V

Type Ceramic

Tolerance +80% -20%

Connected to Pin 5 of IC303, TA8628

Part number 12310337090

Regards,

Alcides Berta

TEAC Australia Pty Ltd.

Acknowledgments

Paul Everding supplied the primary information presented here based on technical observations by

John Srnka and Tony Wynne.

TECHNICAL BULLETIN 3-Aug-2000

Page 1of 1

MODEL: CT-M685

PROBLEM: Picture problems

File: CTM685 neg-blank-lines tb.doc

A faulty ceramic capacitor produces any of these effects on the picture:

•Negative picture

•Blank picture

•Horizontal lines

Instructions

Replace the capacitor C330.

Replacement Information

Position C330

Value 10 nF (0.01 uF)

Voltage 50V

Type Ceramic

Tolerance +80% -20%

Connected to Pin 5 of IC303, TA8628

Part number 12310337090

Regards,

Alcides Berta

TEAC Australia Pty Ltd.

Acknowledgments

Paul Everding supplied the primary information presented here based on technical observations by

John Srnka and Tony Wynne.
