MC-DV610

Features...............................................................................2

For your Attention..................................................................3

Accessories..........................................................................4

Panel.................................................................................5-6

Connection.........................................................................7-8

System Setup...................................................................9-12

Play................................................................................13-17

Troubleshooting...................................................................18

Specification........................................................................19

Contents

-1-

Remote control

Instruction book

Power cord

Thank you for purchasing our product. Please go through this

manual carefully before connection and operation. Please keep

this manual for future reference.

DVD player is a new generation home player which can produce

high quality video and audio. Its performance is much better than

that of any previous home video playing equipment. As the best

signal source of home theatre system, it will give you the

uppermost enjoyment!

Built in Dolby Digital, LPCM, etc. digital audio output

Hi-fi, 96kHz/24bi audio digital processor.

Software intelligent upgrade * High-resolution picture,

support the future video equipment

Coaxial digital audio output

Super compatible with DVD/VCD/CD/KODAK PICTURE CD

Latest the fourth generation servo, decoding single-wafer

technology, reliable stability and super error correction.

Full function remote control

AM/FM stereo radio tuner

Built-in high sensitivity amplifier

t or 48kHz/24bit

Features

-2-

To reduce the risk of electric shock or fire, do not open

the cover. Refer servicing to qualified service personnel.

This mark indicates this unit belongs to class 1 laser

product. The laser beam may produce radiation harm

to the directly touching human body.

IMPORTANTNOTESIMPORTANTNOTES

Please read through the manual carefully before connection

and operation.

Do not open the cover or touch any internal components for

non-professional

Turn off the power when the unit is not being used. (Unplug

the power cord if the unit is not used for a long time) And keep

the unit' plug in easy-to-plug/unplug status in daily life for

convenient use.

Don't expose this unit to direct sunlight. Keep away the

heating sources or equipments

Don't expose this unit to the rain or moisture.

Place the unit on a horizontal level. Keep the unit ventilated.

Don't block the heat hole. Overheat may cause malfunction.

C lean the cabinet with soft cloth. Detergent or alcohol is

forbidden.

This book is only a guide for user`s operation, not a criterion

for configuration.

The apparatus shall not be exposed to dripping or splashing

and that no object filled with liquids, such as vases, shall be

placed on the apparatus.

For Your Attention

The lightning flash is intended to alert the user to the

presence of dangerous voltage within the product's

enclosure, and touching the inner parts may result in a

risk of electric shock to persons.

The exclamatory mark is intended to alert the user to

the presence of important operating instructions.

CLASS 1

LASER PRODUCT

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

WarningWarning

-3-

-4-

Accessories

Accessories

A/V Cable

Remote controller

AM Antenna Speaker Connect Cable

FM Antenna

User Manual

User manual

Remote Controller Operation

Insert the batteries into the cell box. The remote controller

would work within 8 meters if facing the obverse face of the

unit /within 6 meters if facing the side of the unit and within 30

degrees at left or right side.

Take the battery out of the controller if it is not used for a long

time

This unit can play the following types of discs

Symbol Contents

Audio + Video

Audio + Video

Audio

DVD

Video-CD

VCD

CD-DA

COMPACT

DIGITAL VIDEO

VIDEO CD

Disc types

Electronic Photo

Kodak

Picture CD

Panel

-5-

FRONT PANEL

1 POWER BUTTON

2 DISPLAY WINDOW

3 DISC TRAY

4 OPEN/CLOSE BUTTON

5 PLAY/PAUSE BUTTON

6 PREV

7 NEXT

8 STOP BUTTON

9 VOLUME+/-

10 USB PORT

REAR PANEL

Panel

-6-

1 SPEAKER OUTPUT TERMINAL

2 LINE IN TERMINAL

3 VIDEO OUTPUT TERMINAL

4 S-VIDEO OUTPUT TERMINAL

5 COMPONENT VIDEO OUTPUT TERMINAL

6 R/ L Audio Output

7 COAXIAL DIGITAL AUDIO OUTPUT

8 FM ANTENNAJACK

9 AM ANTENNAJACK
