Teac PR-300 Manual de usuario
PR-300
PORTABLE FM/AM RADIO
Thanks for buying a TEAC. Read this manual carefully to get the best performance
from this unit.
OWNER'S MANUAL
Teac PR300 (NZ).p65 2008/7/29, ¤U¤È 04:281
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
DISCONNECT THE MAINS PLUG FROM THE SUPPLY SOCKET WHENNOT IN USE.
WHERE THE MAINS PLUG OR AN APPLIANCE COUPLER IS USED AS THE
DISCONNECT DEVICE, THE DISCONNECT DEVICE SHALL REMAIN READLY
OPERABLE.
NO NAKED FLAME SOURCE, SUCH AS LIGHTED CANDLES, SHOULD BE PLACED
ON THEAPPARATUS.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNINGSIGN
ALERTING YOU OF
DANGEROUS
VOLTAGEINSIDETHE
PRODUCT.
THE EXCLAMATIONPOINT
WITHIN THE TRIANGLE IS A
WARNINGSIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYINGTHE
PRODUCT.
WARNING : TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
RISK OF ELECTRIC SHOCK
DONOTOPEN
CAUTION
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRONIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
Dripping warning :
"The product shall not be exposed to dripping of splashing and that no objects filled with
liquids, such as vases, shall be placed on the product."
Ventilation warning :
"The normal ventilation of the product shall not be impeded for intended use."
Teac PR300 (NZ).p65 2008/7/29, ¤U¤È 04:282
1. Radio On Indicator
2. AC Socket
3. Battery Compartment Door.
4. Handle
5. Rod Antenna
6. Dial Scale
7. TuningKnob
8. Band Switch
9. Phone Jack
10. Volume Knob / On/Off knob
11. Speaker
12. AUX In Jack
CONTROL AND THEIR FUNCTIONS
9
3
1
8
6
5
2
10
7
11
4
12
POWER SOURCE
BATTERYPOWEROPERATION
1. Open the battery compartment door by pushing the catches downwards.
2. Install 4 x UM2 batteries carefully as indicated in battery compartment.
3. Close the battery compartment.
AC POWER OPERATION
Connect receptacle end of the mains lead to the AC socket and the plug to an AC outlet.
OPERATION
1. Turn the Volume Knob / On/Off knob clockwise until you listen a click sound, the
radio will be turn on.
The Radio On Indicator will light on.
2. Select the desired radio band with the Band Switch.
3. Tune in a desired station by tuning the Tuning Knob.
4. For FM reception, pull out the antenna and adjust the direction, lenght and angle to
give the best reception.
5. Adjust the Volume Knob / On/Off knob for your desired listening level.
6. To turn off the radio, turn the Volume Knob / On/Off knob anti-clockwise until you
listen a click sound.
The Radio On Indicator will light off.
PHONE JACK
For private listening connect an headphone (not included) with a 3.5mm plug to the Phone
Jack. The built-in speaker will be automatically disconnected.
Teac PR300 (NZ).p65 2008/7/29, ¤U¤È 04:283
AUX IN JACK
To listen to an external audio source, you need a stereo 3.5mm plug cable (Not inclued)
1) Connect one end of the 3.5mm plug into the output of the audio source, and the other
end of the 3.5mm plug into the AUX IN Jack.
2) Play the audio source.
3) Turn the Volume Knob / On/Off knob clockwise until you listen a click sound, the unit
turns on and the On Indicator will light on.
You can now listen to the audio playing from the audio source through the unit (Speaker /
earphone).
Note: Remeber always unplug the 3.5mm plug cable from the unit after used.
NOMINAL SPECIFICATIONS
Power Supply : AC 240V 50Hz
Batteries 4 x R14/C/SUM-2
Power Output : 500 mW RMS
Frequency Range : FM 87.5-108 MHz
AM 522 - 1620 kHz
Frequency Response : 125 Hz-6kHz
Dimensions : 215(L)x69(W)x162(H) mm
Weight : 0.55 kg
Weight and dimensions are approximate because we continually strive to improve our
products, specifications may change without prior notice.
Teac PR300 (NZ).p65 2008/7/29, ¤U¤È 04:284
TEAC CORPORATION
1-47, Ochiai, Tama-shi, Tokyo 206-8530, Japan
Teac PR300 (NZ).p65 2008/7/29, ¤U¤È 04:285
