CCDD--PP11445500

SERVICE MANUAL

COMPACT DISC PLAYER

Effective : April, 2002 S-0060A

CONTENTS

1 SPECIFICATIONS ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・2

2 EXPLODED VIEWS AND PARTS LIST

・・・・・・・・・・・・・・・・・3

3 PC BOARDS AND PARTS LIST

・・・・・・・・・・・・・・・・・・・・・・・・8

4 INCLUDED ACCESSORIES

・・・・・・・・・・・・・・・・・・・・・・・・・・・13

NOTES

●PC boards shown are viewed from parts side.

●The parts with no reference number or no parts number in the

exploded views are not supplied.

●As regards the resistors and capacitors, refer to the circuit diagrams

contained in this manual.

●£Parts marked with this sign are safety critical components. They

must be replaced with identical components - refer to the appropriate

parts list and ensure exact replacement.

●Parts of [ ] mark can be used only with the version designated.

[US]:U.S.A.[C]:CANADA[E]:EUROPE[UK]:U.K.[NZ]:NEWZEALAND

1 SPECIFICATIONS

−2−CD PLAYER

Pickup:

3-beam, semiconductor laser

D/A Converter:

1 bit DAC

Digital filter:

8-times oversampling

Frequency Response:

20 Hz ~ 20 kHz ±1.5dB

Total Harmonic Distortion:

< 0.02 % (1 kHz)

Signal-to-Noise Ratio (S/N):

>85 dB (1 kHz)

Channel Separation:

>80 dB (1 kHz)

Output:

Analog; 2.0 Vrms (RCA)

Digital; COAXIAL

Wow and Flutter:

Below measurable limit

GENERAL

Power Requirements:

120 V AC, 60Hz (U.S.A./Canada Model)

230 V AC, 50Hz (Europe/U.K. Model)

240 V AC, 50Hz (New Zealand Model)

Power Consumption:

12 Watts (AC)

Dimensions (W x H x D):

435 x 104 x 290mm

Net Weight:

3.6 kg

Standard Accessories:

Wireless Remote Control Unit (RC-681)

RCA pin-plug cord

Battery (SUM-3, "AA", "R6" type) x 2

(Europe/U.K./New Zealand Model)

•Design and specifications are subject to change without notice.

SAFETY INFORMATION

This product has been designed and manufactured according to FDA

regulations "title 21, CFR, chapter 1, subchapter J, based on the Radiation

Control for Health and Safety Act of 1968", and is classified as a class 1

laser product. There is no hazardous invisible laser radiation during

operation because invisible laser radiation emitted inside of this product

is completely confined in the protective housings.

The label required in this regulation is shown 1.

OCAUTION

USE OF CONTROLS OR ADJUSTMENT OR PERFORMANCE OF

PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN

HAZARDOUS RADIATION EXPOSURE.

Optical pickup:

TYPE : SFP101NXR

MANUFACTURER : Sanyo Electric Co., Ltd.

LASER OUTPUT : Continuous Wave max. 5mW

WAVE LENGTH : 765-815nm

1For U.S.A.

2 EXPLODED VIEWS AND PARTS LIST

EXPLODED VIEW-1

−3−

51SC2

45-1

5142

5108

5140

45-4

5118

5104

51SB3

5116

−4−EXPLODED VIEW-1

REF.NO.PARTSNO.DESCRIPTIONREMARKS31‑009A09092400MECHA,CD93F8NDTCEC099100480045‑19A09157400MAINPCBASSYCEC0B1003230045‑29A09157500DISPLAYPCBASSYCEC0B1003240045‑39A09187200KEYSWPCBASSYCEC0B1003241045‑49A09187300PITCHCONPCBASSYCEC0B1003242045‑59A09187400H.P.PCBASSY[US,C]CEC0B100329009A09187420H.P.PCBASSY[E,UK,NZ]CEC0B1003290145‑69A09187510POWERPCBASSY,120V[US,C]CEC0B100325009A09187520POWERPCBASSY,230V[E]CEC0B100325019A09187530POWERPCBASSY,230V[UK]CEC0B100325039A09187540POWERPCBASSY,240V[NZ]CEC0B1003250451019A09263800ESCUTCHEONCEC214100332751029A07077400PANEL,TRAYCEC215500081051039A08667500BADGECEC216300400051049A07077500WINDOWCEC216400612051059A07078000BUTTON,PLAYCEC217501201051069A07077900BUTTON,FUNCTIONCEC217501190051079A07079200FILTER,IRCEC243100120051089A07079300FILTER,LEDCEC243100160051109A07077200DECORATION,TRAYCEC214400391151119A07077700KNOB,ROTARYCEC217100180051129A07077800KNOB,PUSHCEC217400520051139A07077600KNOB,ROTARY,PITCHCONT.CEC217100170051149A07078100BUTTON,12KEYCEC217501210051159A07078200BUTTON,PITCHCONT.CEC217501220051169A07079800SHEET,IRCEC246201130051179A07079000LUGCEC237700160051189A07079900SHEET,LEDCEC246201140051209A07077000COVER,TOPCEC212100390051219A09263900PANEL,REAR[US,C]CEC21530023409A09264300PANEL,REAR[E,UK]CEC21530023419A09264700PANEL,REAR[NZ]CEC215300234251229A07078400CHASSISCEC231100690051249A07078300LEGCEC225100350051259A07080000FELTCEC257100170051309A07078800JOINTCEC235100190051319A07078900POSTCEC23730011005134£9A06846200BUSHING,NIFCO2271CEC244600020051409A07078500BRACKET‑E,JACKCEC232100080051419A07078700BRACKET‑M,TOPCEC232200180051429A07274200FELT,PLCEC2571002200CN2029A09195600HOUSING,2P[US,C]43‑791002031‑00PC120£9A08660100POWERCORD[US,C]CEC4W10006400£9A09196200POWERCORD[E]CEC4W10006300£9A07258200POWERCORD[UK]CEC4W10004700£9A07089300POWERCORD[NZ]CEC4W100048009A07508700CORE,BP53RB120070060MCEC4Z210007009A07508800CORE,E04RA120070060CEC4Z21000800

−5−EXPLODED VIEW-1

REF.NO.PARTSNO.DESCRIPTIONREMARKS51SA19A06855600SCREW,S‑TPGBIN2.6X6SFBDN266R0SE‑51SA29A06855600SCREW,S‑TPGBIN2.6X6SFBDN266R0SE‑51SB19A00768400SCREW,S‑TPGBRZM2.6X8SFBAN268R0SE‑51SB29A00768400SCREW,S‑TPGBRZM2.6X8SFBAN268R0SE‑51SB39A00768400SCREW,S‑TPGBRZM2.6X8SFBAN268R0SE‑51SC19A01589800SCREW,S‑TPGBINM3X6SFBDN306R0SE‑51SC29A01589800SCREW,S‑TPGBINM3X6SFBDN306R0SE‑51SD19A01041200SCREW,S‑TPGBINM3X8SFBDN308R0SM‑51SD29A01041200SCREW,S‑TPGBINM3X8SFBDN308R0SM‑51SD39A01041200SCREW,S‑TPGBINM3X8SFBDN308R0SM‑51SD49A01041200SCREW,S‑TPGBINM3X8SFBDN308R0SM‑51SD59A01041200SCREW,S‑TPGBINM3X8SFBDN308R0SM‑51SD69A01041200SCREW,S‑TPGBINM3X8SFBDN308R0SM‑51SD89A01041200SCREW,S‑TPGBINM3X8SFBDN308R0SM‑51SE19A07086400SCREW,S‑TPGBIN3X14SFBDN30140SE‑51SF19A07086500SCREW,S‑TPGBIN3X25SFBDN30250SE‑51SG19A06856000SCREW,S‑TPGTRS4X6SFSTN406R0SE‑51SI19A06855700SCREW,S‑TPGBIN3X4SFBDN304R0SE‑

EXPLODED VIEW-2

−6−

−7−EXPLODED VIEW-2 (CD93F8NDT)

REF.NO.PARTSNO.DESCRIPTIONREMARKS19A07071300SWITCHPCBASSY1EA0B10A9810039A07072300CHASSIS,FRAME1EA2311A0660049A07071400PLATE,MAGNET1EA2336A0530059A07071500LEFTRAILASSY1EA0363A0010069A07071600RAIL,RIGHT1EA2363A0030089A07071800SUPPORT,MAGNET1EA2413A0170099A08438700CUSHION,RUBBERCEC2443000100109A08438800CUSHION,RUBBERCEC2443000101119A07072100HOLDER,MAGNET1EA2451A09000129A07072200SHEET1EA2462A13200139A07072400GEAR,LOADING1EA2511A10900149A07072500GEAR,LIFTER1EA2511A11000159A07072600GEAR,IDLER,A1EA2511A11100169A07072700GEAR,IDLER,B1EA2511A11200179A07072800PULLEY,MOTOR1EA2523A01700189A07072900PULLEY,GEAR1EA2524A01600199A07073000BELT,SQUARE1EA2563A02200209A02677600MAGNET,DISCCLAMP1EA2641A01300219A08438600LIFTER,MECHACEC2713000700229A07073200SLIDE,LIFTER1EA2741A01300239A07073300TABLE,LOADING1EA2761A00700249A03303300MOTOR,3.0V1EA4M10A02100305760707700SCREW,B‑TITESEMSM3X1013124201283000319A07073500SCREW,S‑TPGBIN2.6X8SFBDN268R0SE‑31‑029A09093000MECHASSY,DA11T3CN1393310231‑409A07070800BRACKETCEC232200130031‑419A07070900SHEET,MECHACEC246201120031SA19A07071100SCREW,S‑TPGBIN3X8SFBDN308R0SE‑329A07073600SCREW,S‑TPGPAN+FLG2X6SFBPY206R0SE‑339A07073700SCREW,PAN+SW1.7X3.5SM2PS173R5SE‑349A07073800SCREW,SPECIALSGXEA00201‑‑‑359A07071100SCREW,S‑TPGBIN3X8SFBDN308R0SE‑9A08632700WIRE,JUMPER,16PCEC4W30009700
