Targus NOTEBOOK SECURITY DEFCON SCL Manual de usuario
PA410S(EU) / 410-0014-003A
USER GUIDE
30
Visit our Website at www.targus.com/emea
Features and specifications subject to change without notice.
© 2007 Targus Group International, Inc. and Targus Group (UK) Ltd.
Notebook Security
DEFCON®SCL
Serialised
Combination Cable
Lock
Table of Contents
English
Deutsch
Español
Français
Italiano
Nederlands
Português
Targus notebook security DEFCON ® SCL serialised
combination cable .................................................................2
Serieel DEFCON ® SCL combinatie-kabelslot van Targus voor de
veiligheid van uw Notebook ..............................................................14
Targus notebook security DEFCON ® SCL serialised
combination cable ..............................................................26
Targus notebook security DEFCON ® SCL serialised
combination cable ...............................................................37
Targus notebook lucchetto da cavo a combinazione
serializzata DEFCON ® SCL ...............................................50
Serieel DEFCON ® SCL combinatie-kabelslot van Targus
voor de veiligheid van uw Notebook ...................................62
Trava a cabo com combinação em série DEFCON ® SCL da
Targus Notebook Security ..................................................74
1
TARGUS NOTEBOOK
SECURITY DEFCON®
SCL SERIALISED
COMBINATION CABLE
LOCK
Thank you for purchasing the Targus Notebook Security DEFCON®
SCL Serialised Combination Cable Lock. The DEFCON SCL helps
protect your valuable notebook computer from theft using a serialised
four-digit combination lock. The preset combination lock eliminates the
need for keys and makes it impossible to reset your combination.
Introduction
In addition to this user’s guide, this package contains:
• DEFCON ® SCL Serialised Combination Cable Lock
• DEFCON SecureSpacers
• DEFCON Security BasePlate
WARNING: TO USE THE DEFCON SCL YOU MUST RECORD THE PRESET COMBINA-
TION PRIOR USE.
2
Targus notebook security DEFCON®SCL serialised combination cable lock
Combination windows Reset screw
Combination dials
Locking button
Serialised combination
1. Locate the combination dials and windows on the lock.
DEFCON SCL
2. The preset combination appears on a sticker that is attached at
the back of this user guide.
NOTE: ALTERNATIVELY, YOU MAY RECORD THE COMBINATION IN ANOTHER
SECURE, EASY-TO-FIND PLACE, AND KEEP IT AWAY FROM THE NOTEBOOK
COMPUTER.
3. Turn the dials to disguise the combination.
3
Testing the Combination
Before attaching the lock to your notebook computer:
1. Turn the dials to return to the serialised combination.
2. Check that the locking button depresses completely.
Securing the DEFCON SCL
Select an object in the room to which you will secure your notebook
computer with the DEFCON SCL. Choose a large, heavy piece of
furniture such as a table or desk.
1. Take the looped end of the cable and wrap it around the selected
object.
NOTE: WRAP THE CABLE AROUND A PART OF THE OBJECT THAT WILL DETER AN
INTRUDER FROM SLIPPING THE CABLE OFF (FOR EXAMPLE, A TABLE OR DESK LEG
WITH A CROSS BAR OR A DRAWER HANDLE).
2. Feed the lock through the looped end of the cable as shown.
Targus notebook security DEFCON®SCL serialised combination cable lock
4
Locking the DEFCON SCL to your
Notebook Computer
NOTE: HOLD THE DEFCON SCL WITH BOTH HANDS FOR ADDITIONAL STABILITY
WHILE INSERTING OR REMOVING THE LOCK.
1. Using the dials, enter the correct combination.The combination
appears in the windows.
Securing the DEFCON SCL to an object
Targus notebook security DEFCON®SCL serialised combination cable lock
5
Locking button
Locking teeth
SecureSpacer
DEFCON SCL
2. Press and hold the locking button to align the locking teeth.
NOTE: FOR THE LOCKING BUTTON TO DEPRESS COMPLETELY YOU MUST ENTER
THE CORRECT COMBINATION.
3. Insert the DEFCON SCL into your notebook computer’s lock slot
and release the locking button.
NOTE: DUE TO THE VARIATION IN THE SIZE OF THE SECURITY SLOTS ON VARIOUS
NOTEBOOK MODELS, YOU MAY FIND THAT THERE IS SOME SLACK BETWEEN THE
LOCK AND THE COMPUTER. THE SUPPLIED DEFCON SECURESPACERS ARE THE
BEST SOLUTION FOR OPTIMAL FIT AND SECURITY.
4. Turn the dials to conceal your combination.
Due to differences in the size of the security slots on various
notebook computers, you may find that there is some slack
between the DEFCON SCL and the computer. The DEFCON
SecureSpacers provide optimal fit and security.
Targus notebook security DEFCON®SCL serialised combination cable lock
6
Using the DEFCON SecureSpacers
1. Insert your DEFCON SCL into the computer’s lock slot.
2. Pull the DEFCON SCL away from the computer and check
whether the gap is excessive.
3. If so, try each of the SecureSpacers to determine which one fits the
gap.The SecureSpacers come in three sizes: 1.6 mm, 0.8 mm, and
0.4 mm.
NOTE: DO NOT REMOVE THE ADHESIVE STRIP FROM ANY OF THE SECURESPACERS
UNTIL YOU DECIDE WHICH ONE TO USE.
4. Once you know which SecureSpacer you are going to use, remove
the locking device from the computer.Then remove the adhesive
strip from the back of the SecureSpacer and attach the spacer to the
DEFCON SCL.
Targus notebook security DEFCON®SCL serialised combination cable lock
7
Unlocking the DEFCON SCL
WARNING: DO NOT ATTEMPT TO REMOVE THE DEFCON SCL WITHOUT USING THE
COMBINATION. TO DO SO WILL PHYSICALLY DAMAGE YOUR NOTEBOOK
COMPUTER.
1. Using the dials, enter the correct combination.
2. The combination appears in the windows.
3. Press and hold the locking button to realign the locking teeth.
4. Remove the DEFCON SCL from your notebook computer’s
lock slot.
DEFCON Security Base Plate
Included with your DEFCON SCL is the Security Base Plate for the
security of desktop computers.
Using the DEFCON Security Base
Plate
1. Choose a solid location to attach the DEFCON Security Base Plate:
a piece of furniture, or metal cabinet. If you plan to use the two
screws, you can use the base plate as a template to pre-drill the
holes.
2. Use the abrasive pad, then the alcohol wipe to prepare the area
where you will attach the DEFCON Security Base Plate.
Targus notebook security DEFCON®SCL serialised combination cable lock
8
3. After the alcohol dries, remove the backing on the base plate to
expose the adhesive and place it on the prepared location. If desired,
secure the base with the two screws.
NOTE: WHEN USING THE ADHESIVE BACKING, APPLY AT ROOM TEMPERATURE
-60°F (16°C), AND ALLOW IT TO BOND FOR MORE THAN 24 HOURS. NOT
RECOMMENDED FOR USE OUTDOORS OR IN A HIGH HUMIDITY ENVIRONMENT.
BONDING TO GLASS, CERAMIC TILE, WATER-ABSORBENT MATERIALS, COPPER,
BRASS, OR PLASTICIZED VINYL WITHOUT PRIMER SURFACE ARE NOT
RECOMMENDED. TARGUS RECOMMENDS USING BOTH ADHESIVE AND SCREWS TO
PROVIDE MAXIMUM SECURITY. USING ONLY THE ADHESIVE PROVIDES MARGINAL
SECURITY.
4. Place the DEFCON Security Base Plate cover as shown and slide it
to the left or right to secure it in place.
5. Insert your DEFCON SCL.
Targus notebook security DEFCON®SCL serialised combination cable lock
9
