Tanaka THT-2000 Guía de configuración

IllustrIllustr

Illustraa

ated Pted P

ted Pted P

ted Parar

arar

arts Mants Man

ts Mants Man

ts Manualual

ualual

ual

Model Number:

THT-2000

21cc, 20” HEDGETRIMMER

P/N 32826

Rev 000

Date 04-09-08

Nikko Tanaka Engineering U.S.A.,Ltd.• 1028 4th Street SW, Bldg B • Auburn, WA 98001 • Phone: (253) 333-1200 • Fax: (253) 333-1212

www.tanakapowerequipment.com [email protected]

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

Page 1

THT-2000

CYLINDER, PISTON, CRANKSHAFT • FIGURE 1

ITEM PART NUMBER DESCRIPTION QTY COMMENTS

1-1 1570650091 CAP,SPARK PLUG ASS'Y 1

1-2 0181166021 PLUG,SPARK 1

1-3 0010650A90 CYLINDER SET 1 Includes gasket

1-4 99461050184 BOLT,HEX,5X18,S 2

1-7 0170650020 GASKET,CYLINDER 1

1-8 04100601210 RING,PISTON 1

1-9 0300007090 SET,PISTON 1 Includes rings and circlips

1-10 03706500200 PIN,PISTON 1

1-11 03901620200 CIRCLIP 2

1-12 0460662080 CRANKSHAFT 1 Units prior to S/N ~D070201

1-12 0460662180 CRANKSHAFT 1 Units after S/N D070202~

1-13 99962081277 BEARING,NEEDLE,HK0810B 1 Units prior to S/N ~D070201

1-27 1532153390 COIL,IGNITION 1

1-28 99464040184 BOLT,HEXT 4X18WS 2

1-36 25006500200 TUBE,INSULATOR 1

1-37 1780650080 CORD,STOP 1

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

Page 2

THT-2000

CRANKCASE & FLYWHEEL • FIGURE 2

See Figure 1

ITEM PART NUMBE

DESCRIPTION QTY COMMENTS

2-21 0720650090 CRANKCASE ASS'Y 1 Includes bearings, seals and gasket

2-22 09006500200 GASKET,CRANKCASE 1

2-23 99966122240 SEAL,OIL,#12227 2

2-24 99961600115 BEARING,BALL,6001 C3 2

2-25 33000200210 SHIM,12.2X19X.10 V Shims are as needed

2-25 33000200220 SHIM,12.2X19X.15 V

2-25 33000200230 SHIM,12.2X19X.20 V

2-25 33000200240 SHIM,12.2X19X.30 V

2-26 59900601200 CUSHION 1

2-30 99461050304 BOLT,HEX,5X30S 3

2-31 1552154980 ROTOR,MAGNETO 1

2-34 99101080011 NUT,8 1

2-35 10002100200 BOLT,STUD,6X22 2

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

Page 3

THT-2000

FUEL SYSTEM • FIGURE 3

Asmallretainer(560-02170-

20), has been added to this

modelafterserial # A099801

to prevent the barrel end of the

throttlewirefrom coming

detachedfromthe carburetor.

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

Page 4

THT-2000

FUEL SYSTEM • FIGURE 3

ITEM PART NUMBE

DESCRIPTION QTY COMMENTS

3-25 40306500200 GASKET,INTAKE 1

3-26 4040650090 SET,CARB INSULATOR 1 Includes gasket

3-27 99464050254 BOLT,HEX HOLE,5X25WS 2

3-30 4020602K21 GASKET,CARBURETOR 1

3-35 4230072Z81 BODY,CLEANER 1

3-36 47000025200 COLLAR 2

3-37 5280635A200 PLATE,CHOKE 1

3-38 4530602K200 COLLAR 1

3-40 99210050012 WASHER,S,5 2

3-41 99011050652 SCREW,5x65 2

3-42 99201050011 WASHER,5 2

3-43 4460602K200 ELEMENT 1

3-44 4240602K201 CAP,CLEANER 1

3-45 4550662290 CARBURETOR 1 Includes gasket

3-46 8780662020 PLATE,THROTTLE WIRE 1

3-47 40206500200 GASKET,CARBURETOR 1

3-48 43106020200 GASKET,CLEANER 1

3-50 2230650090 PIPE,FUEL,ASS'Y 1

3-51 68000731201 CLIP 6.3 1

3-52 6750404280 FILTER,FUEL 1

3-53 5910650U21 TANK,FUEL 1

3-54 5950007390 CAP,TANK 1

3-55 65900801200 COLLAR 2

3-58 99463050185 BOLT,HEX 5X18PS 2

3-59 61425137200 ADJUSTER,CABLE 1

3-60 99101060013 NUT,6 1

3-78 7000300507 PIPE,FUEL,3X5X75 1

3-79 53432710200 GROMMET,FUEL PIPE 1

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]m

Page 5

THT-2000

MUFFLER, STARTER, FAN CASE & ENGINE COVER •FIGURE 4

Recoil Starter Assy

#762-06500-90

Incl. items 11-15

and 17-19

ITEM PART NUMBE

DESCRIPTION QTY COMMENTS

4-37380650020 PROTECTOR,MUFFLER 1

4-473706500200 GASKET,MUFFLER 1

1TAEH,DLEIHS002005603315-4 1TESRELFFUM19C15604076-4 25,REHSAW110050102997-4 205X5,XEH,TLOB305050150998-4 1NAF,ESAC080056021111-4 1LIOCER,GNIRPS0027906008721-4

4-13 77406097200 PULLEY,STARTER 1

1TES,WERCS020102093851-4

4-16 79806500900 PULLEY,STARTER,ASS'Y 1

1TEMMORG202A406030271-4 1RETRATS,EPOR0027906038781-4

4-19 78506410200 HANDLE,STARTER 1

4-20 99463040154 BOLT,HEX,4X15,PS 1

4-21 75106500200 GASKET,MUFFLER 1 rots

errakrapssedulcnI1TESLIAT,EPIP190056012722-4 2S/8X4,WERCS1800404349942-4 1YSSA,HCTULC109F436077274-4

4-6199072045164 SCREW,TAPPING,4.5X16 1

221X4,SP,TLOB8210405249926-4

4-65 79006097200 SPRING,STARTER PAWL 1

1RETRATS,LWAP020056088766-4

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

Page 6

THT-2000

CARBURETOR • FIGURE 5

ITEM PART NUMBE

DESCRIPTION QTY COMMENTS

5-0 4550662290 CARBURETOR SET 1 Includes gasket

5-2 5752515780 BODY,PUMP 1

5-3 4422515180 PUMP,PRIMING 1

5-4 4762515120 COVER,DIAPHRAGM 1

5-5 44725108200 BULB,PRIMING 1

5-6 ~ ~ ~ DIAPHRAGM,METERING 1 ~ Included in 650.25124.900 Carb Kit

5-7 ~ ~ ~ GASKET,DIAPHRAGM 1 (not available individually)

5-8 5992000W410 JET,MAIN,#41 1

5-9 48925100200 RING,STOP 1

5-10 53925120200 SWIVEL 1

5-11 48825145800 VALVE,THROTTLE 1

5-12 55025100200 O-RING 1

5-13 ~ ~ ~ GASKET,PUMP 1

5-14 ~ ~ ~ DIAPHRAGM,PUMP 1

5-15 54825140200 SCREW,THROTTLE SET 2

5-17 5482515120 SCREW,SET 1

5-201 57825007200 SCREEN,INLET 1

Asmall retainer(560-02170-

20), has been added to this

modelafterserial # A099801

to prevent the barrel end of the

throttlewirefrom coming

detachedfromthe carburetor.

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

Page 7

THT-2000

HANDLES • FIGURE 6

See Figure 7

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

Page 8

THT-2000

HANDLES • FIGURE 6

ITEM PART NUMBE

DESCRIPTION QTY COMMENTS

6-25 05033150010 HANDLE,REAR,ASSY 1 Includes #25 & #33 only

6-26 1703317A80 SWITCH,STOP 1

6-27 2581165020 BUTTON,STOP 1

6-28 99011030101 SCREW,3x10 1

6-29 2303315020 LEVER,THROTTLE 1

6-30 23133150200 LEVER,SAFETY 1

6-31 23233150200 SPRING,THROTTLE LEVER 1

6-33 ~ ~ ~ HANDLE 1 Included in #25 - Rear Handle Ass'y

6-35 7653212020 CAP 1

6-36 99311041812 SCREW,TAPPING,4X18 7

6-47 8850662080 WIRE,THROTTLE 1

6-48 9253253020 DECAL,STOP BUTTON 1

6-50 99051050453 BOLT,HEX,5X45 1

6-51 99178050010 NUT,LOCK 5 1

6-53 99461060184 BOLT,HEX,6x18S 1

6-54 99210050012 WASHER,S,5 1

6-55 99200050011 WASHER,SMALL,5 1

6-57 99201060011 WASHER,6 1

6-61 2103324720 HANDLE,FRONT 1

6-63 36832057200 WASHER,BRAKE SHAFT 2

6-64 99210050062 WASHER,S,5 2

6-65 99051050403 BOLT,HEX,5X40 2

6-73 1641001500 TUBE,PROTECTION,10X150 1

6-82 65900801200 COLLAR 2

www.tanakapowerequipment.com

PARTSINFORMATION

[email protected]

Page 9

THT-2000

GEAR CASE & BLADES • FIGURE 7
