TallyGenicom T2150 Manual de usuario

Reference manual Matrix printer

T2250

T2150

BACK QUIT

Table of contents

Printer at a glance 1

Paperways 3

Installation 4

Unpacking the printer 4

Placing your printer 5

Checking the printer voltage 7

Connecting the printer 9

Switching on the printer 11

The control panel 12

The LC display 13

Online mode 14

Offline mode 15

Setup mode 16

Messages in the LC display 17

Key functions when turning on the printer 18

Changing the ribbon cassette 19

Settings (I) 24

Paper path quick selection 24

Selecting character density and font temporarily 26

BACK QUIT

Reference manualTable of contents

BACK QUIT

Reference manualTable of contents

Loading paper 28

Fanfold paper 28

Sin

le sheets 34

Handling 37

Paper transport 37

Movin

the paper to the tear position 38

Settings (II) 39

Settin

the print head

ap 39

Settin

the tear position 41

Settin

the first printin

line (TOF) 42

The Menu 44

Pro

rammin

via the control panel 44

Enablin

access to menu mode 45

Callin

up the menu 45

Menu confi

urations 46

Status pa

e46

Menu handlin

Save settin

s49

Selectin

the LC display lan

e50

Terminatin

Setup mode 52

Menu structure 53

Menu description table 54

Extended settings 68

Test functions 68

Functions and Adjustments 69

Printer self-test (Rolling ASCII) 71

Exiting Rolling ASCII test mode 73

Interface test (Hex-Dump) 74

Printout in Hex-Dump 74

Terminating Hex-Dump 76

Mechanical adjustments to the printer 77

Setting the Formlen function 78

Setting the AGA function 80

Setting the Paphand function 81

Increasing the print head gap (Head up) 82

Paper width (Pagewid) 83

Left-hand area (Leftzon) 84

Right-hand area (Rightzo) 85

Physical left margin (Physlm) 86

Bidirectional parallel interface (CX-bid) 87

Line wrap (Wrap) / Beep at paper end (Sound) 88

Settings for paper with dark back (Pap.back) 89

Deactivate single sheet feeder (Single) 90

Setting for printing copy paper (HvyForm) 91

Reduced power consumption (SleepMod) 92

BACK QUIT

Reference manualTable of contents

Loading firmware 93

Troubleshooting 94

Troubleshooting 95

The display remains dark 96

The display is lit, but the printer does not print 97

Problems with the paper feed 98

Paper jam (fanfold paper) 99

Paper jam (single sheets) 100

Paper does not move to tear off position 100

Problems with the print quality 101

Print is too pale 101

Smudged print 101

Prints undefined characters 102

The first line is not completely printed out at the top 102

Dots within characters are missing 102

Error messages via the display 103

Load paper from ... 103

Printhead hot 103

Cover open 103

Parity Error 103

Frame Error 104

Hardware Alarm 104

Overrun Error 104

BACK QUIT

Reference manualTable of contents

Eject Error 105

Load paper from …105

Additional display messa

es 106

Press any key 106

Loadin

Default 106

Only available in Epson mode 106

Park position 106

Tear paper off 106

Load paper from …106

Care and maintenance 107

Replacin

the fuse 108

Cleanin

the housin

109

Cleanin

the interior 109

Platen 110

Ribbon 111

Upper friction 111

Carria

e shafts 111

BACK QUIT

Reference manualTable of contents

Emulations 112

General 112

Escape sequences 112

What are escape sequences? 113

MTPL sequences 113

What are control codes? 113

The $$ procedure 114

How are escape sequences used? 115

MTPL 116

Example in BASIC 116

Example in Pascal 117

List of available control codes 118

Barcode 137

List of available barcodes 137

US Postnet Barcode 139

LC printin

140

List of additional command codes 141

Confi

urin

the printer for your computer 143

BACK QUIT

Reference manualTable of contents

Character sets 144

MTPL standard character set 145

MTPL international substitution

characters 146

OCRA character set 147

OCRB character set 148

Available character sets 149

Interfaces 156

Parallel interface 157

Connector assi

nment 157

Serial interface V.24/RS232C 159

Connector assi

nment 160

Interface cable (serial interface) 161

Input si

nals 162

Output si

nals 162

Memory mode XON/XOFF 163

Memory mode Robust XON/XOFF 163

Extended menu functions with the ENQ/STX, ETX/ACK and

ACK/NAK protocols selected 164

ENQ/STX protocol 165

ETX/ACK protocol 166

ACK/NAK protocol 166

Add entry to the AUTOEXEC.BAT 168

BACK QUIT

Reference manualTable of contents

Specification 169

Printer specifications 169

Interface specifications 175

Paper specifications 177

Options and Accessories 180

Options 180

Automatic single sheet feeder, front (ASF-F) 180

Automatic single sheet feeder, rear (ASF-R) 180

Tractor 2, front 180

Tractor 3, rear 181

Others 181

Automatic single sheet feeder, front (ASF-F) 182

Preparing the printer 182

Installing the ASF-F 183

Inserting paper 185

Automatic single sheet feeder, rear (ASF-R) 187

Preparing the printer 187

Installing the ASF-R 187

Inserting paper 191

Tractor 2 193

Preparing the printer 193

Installing the tractor 2 194

BACK QUIT

Reference manualTable of contents

Tractor 3 195

Preparing the printer 195

Installing the tractor 3 195

Paper specifications 197

Accessories 201

Ribbon cassettes 201

Serial interface adapter 201

Programmer’s application manuals 201

Index 202

BACK QUIT

Reference manualTable of contents
