TAB e.module L5.1
Li-ion Energy Storage System
OPERATION MANUAL
Contents
1. Symbol in label, manual and product 5
2. Safety Precautions 6
2.1 Before Connecting 6
2.2 In Using 7
3. Introduction 7
3.1 Features 7
3.2 Specication 8
3.3 Equipment interface instruction 10
4. Safe handling of lithium batteries guide 13
4.1 Schematic diagram of solution 13
4.2 Danger label 13
4.3 Tools 14
4.4 Safety Gear 14
5. Installation and operation 15
5.1 Package items 15
5.2 Installation location 16
5.3 Installation Direction 17
5.4 Grounding 18
5.5 Put into cabinet or rack 18
5.6 Suitable disconnection device 19
5.7 Power on 20
5.8 Power off 20
6. Trouble shooting 21
7. Emergency Situations 24
8. Remarks 25
This manual introduces L5.1 e.module from TAB. Please read this manual before using
and follow the instruction carefully during the installation process. Any confusion, please
contact TAB for advice and clarication.
1. Symbol in label, manual and product
Caution! Warning! Reminding. Safety related information.
Risk of battery system failure or life cycle reduces.
Do not reverse connection the positive and negative.
Do not place near open ame.
Do not place at the children and pet touchable area.
Warning electric shock.
Warning Fire.
Do not place near ammable material
Read the product and operation manual before operating the
battery system!
Grounding.
Recycle label.
The certicate label for EMC.
Label for Waste Electrical and Electronic Equipment (WEEE)
Directive (2012/19/EU).
The certicate label for Safety by SiQ
5
2. Safety Precautions
Reminding
1. It is important and necessary to read the user manual carefully before installing or
using battery. Failure to do so or to follow any of the instructions or warnings in this
document can result in electrical shock, serious injury, or death, or can damage bat-
tery, potentially rendering it inoperable.
2. If the battery is stored for long time, it is required to charge every six months, and the
SOC should be no less than 90%.
3. Battery needs to be recharged within 12 hours after fully discharged.
4. Do not install the product in outdoor environment, or an environment out of the oper-
ation temperature or humidity range listed in manual.
5. Do not expose cable outside.
6. Do not connect power terminal reversely.
7. All the battery terminals must be disconnected for maintenance.
8. Please contact the supplier within 24 hours if there is something abnormal.
9. Do not use cleaning solvents to clean battery.
10. Do not expose battery to ammable or harsh chemicals or vapors.
11. Do not paint any part of battery, include any internal or external components.
12. Do not connect battery with PV solar wiring directly.
13. Any foreign object is prohibited to insert into any part of battery.
14. The warranty claims are excluded for direct or indirect damage due to items above.
Warning
2.1 Before Connecting
1. After unpacking, please check product and packing list rst, if product is damaged or
lack of parts, please contact with the local retailer.
2. Before installation, be sure to cut off the grid power and make sure the battery is in
the turned-off mode.
3. Wiring must be correct, do not mistake the positive and negative cables, and ensure
no short circuit with the external device.
4. It is prohibited to connect the battery and AC power directly.
5. The embedded BMS in the battery is designed for 48VDC, please DO NOT connect
battery in series.
6. Battery must connect to ground and the resistance must be less than 0.1Ω
6
7. Please ensured the electrical parameters of battery system are compatible to related
equipment
8. Keep the battery away from water and re.
2.2 In Using
1. If the battery system needs to be moved or repaired, the power must be cut off and
the battery is completely shutdown.
2. It is prohibited to connect the battery with different type of battery.
3. It is prohibited to connect batteries with faulty or incompatible inverter.
4. It is prohibited to disassemble the battery (QC tab removed or damaged);
5. In case of re, dry powder re extinguisher or vast amount of water can be used.
6. Please do not open, repair or disassemble the battery except staffs from TAB or
authorized by TAB. We do not undertake any consequences or related responsibility
which because of violation of safety operation or violating of design, production and
equipment safety standards.
3. Introduction
L5.1 lithium iron phosphate battery is the new energy storage product developed and pro-
duced under TAB’s quality requirements, it can be used to support reliable high power for
various types of equipment and systems.
3.1 Features
1. Built-in soft-start function able to reduce current strike when inverter need to start
from battery.
2. Active protection on BMS level.
3. Automatic address setting when connect in parallel.
4. Enable 97% depth of discharge, available for the inverter which completely follow
TAB latest protocol to operate.
5. The module is non-toxic, non-pollution and environmentally friendly.
6. Cathode material is made from LiFePO4 with safety performance and long cycle life.
7. Battery management system (BMS) has protection functions including over-dis- char-
ge, over-charge, over-current and high/low temperature.
8. The system can automatically manage charge and discharge state and balance vol-
tage of each cell.
9. Flexible conguration, multiple battery modules can be in parallel for expanding capa-
7
city and power.
10. Adopted self-cooling mode rapidly reduced system entire noise.
11. The module has less self-discharge, up to 6 months without charging it on shelf, no
memory effect, excellent performance of shallow charge and discharge.
12. Small size and light weight, standard of 19-inch embedded designed module is
13. comfortable for installation and maintenance.
14. Compatible with the 48V e.module series battery of TAB.
3.2 Specication
8
Basic Parameters L5.1
Nominal Voltage (Vdc) 51.2
Nominal Capacity (Wh) 5120
Usable Capacity (Wh) 5000
Depth of discharge (%) 97
Dimension (mm) 459*482*160
Weight (Kg) 47.5
Discharge Voltage (Vdc) 44.8
Charge Voltage (Vdc) 58.4
Recommended Charge Current 50
Normal Charge/Discharge Current (A) 75*
Max. continuous Charge/Discharge Current (A) 100*
Peak Charge/Discharge Current (A) 140@15sec
Communication RS485, CAN
Conguration (max. in 1 battery group) 32pcs
Working Temperature 0°C ~55°C Charge
-20°C ~55°C Discharge
Shelf Temperature -20°C ~35°C
Short current/duration time <2000A/1ms
Cooling type Natural
IP rating of enclosure IP20
Humidity 5% ~ 95%(RH) No Condensation
Altitude(m) ≤3000
Certication IEC62619/CE/UN38.3
Design life 10+ Years (25°C /77°F)
Reference standards IEC62619, IEC63056, IEC61000-6-2,
IEC61000-6-3, UN38.3
*: The normal and max. continuous operation current is for a battery cell temperature within
10~35°C to consider, out of such temp. range will cause a derating on operation current.
9
3.3 Equipment interface instruction
L5.1 front panel
Start (SW)
Turn on: press the button for 1s to start the battery.
Turn off: press the button for 1s to turn off the battery.
RUN
Green LED ashing or lighting to show the battery running status.
Alarm (ALM)
Red LED ashing to show the battery has alarm; lighting to show the battery is under pro-
tection.
Warning: In case of a warning ALM LED starts blinking yellow.
Alarm: In case of an alarm ALM LED starts blinking red. The module disconnects itself from
the system, other modules in a string continue working.
Critical Alarm: In case of a critical error all leds start blinking. Color led starts blinking red.
The whole system stops operating for safety reasons.
SOC
LEDs to show the battery’s current capacity.
